TOYOTA PROACE PRODUCT GUIDE

Release of 19 April 2016

Style

Style differentiation on Proace and Proace Verso

Chrome insert in coloured

bumper

Coloured bumper, side protections, door handles

and rear view mirrors (Look Pack)

Black Bumper, side protections, door handles

and rear view mirrors

Xenon Headlamps + DRL in LED

Halogen Headlamps + DRL

Front detail ProaceFront detail Proace Verso

Style: differentiation on the wheels

4 wheel cover and rim families:

- Black hub cap on grey steel wheel in 16’’ and 17’’, on Van and Combi grade.

-Full wheel cover on black steel wheel in 16’’ on shuttles (optional on Van comfort grade).

- Full wheel cover on black steel wheel in 17’’ on Family Grade (optional on Combi and Shuttle Grade, and Van comfort grade).

-17’’ aluminium rim on VIP Grade (optional on Family and Shuttle Grade, and Van comfort grade).

Shuttle Grade Family Grade Family Grade and VIP

VAN Base & Comfort Grade

& Combi

Black hub cap on

grey steel wheel

16’’

Full wheel cover on

black steel wheel

16’’

Full wheel cover on

black steel wheel

17’’

Alloy wheel rim

17’’

Black hub cap on

grey steel wheel

17’’

Style: interior style

Differences are more marked between Proace and Proace Verso grades:

Differentiation between Proace and Proace Verso

The dashboard on Proace vans and combi has a more

functional design, with maximum directly accessible

open storage, whereas the dashboard on Proace Verso

cultivates a more opulent design, with decorative strips

and closed storage compartments for hiding the objects

they contain. This can also be found in the colour of the

lower part and the door panels: light grey on the former

and black on the latter (see next page).

In both cases, particular details are included when you

opt to upscale, depending on the versions and

equipment present (see 2 pages below)

Common across all versions

with detail variants

Common to Proace

Common across all versions

with detail variants

Proace Verso

Proace

Common to Proace Verso

with detail variants

Style: Proace vs. Proace Verso differentiation

Light grey colour scheme

Door panel with dark grey

plastic insert

Open storage

compartment

Open lower

glove box

Decorative

strip

matching

the finish

Closed

lower glove

box (open

on RHD)

Door panel with decorative

strip and reference (textile

or PVC depending on finish)

Common black upper part

of dashboard

Chromium-plated surround

on side vents

Proace Verso

Proace

Mistral black colour

scheme

Common black upper part

of dashboard

Black plastic surround on

side vents

Style: upscaled dashboards on Combi vans and PCs

Urethane steering wheel with

or without infotainment

controls

Short elephant foot on A/T

and MMT version, while long

on 5M/T and 6M/T.

Knob depending on

powertrain

Instrument panel

depending on version and

infotainment options

Stop/Start

push-

button

Proace

Closed upper

glovebox

Toyota Traction Select knob

or open storage

compartment

Depending on heating or air

conditioning

Depending on infotainment

with or without

chromium-plated surround

With or

without

overhead

display

Closed

storage

compartme

nt with

overhead

display

Style: upscaled dashboards on PCs

Instrument panel

depending on version

and infotainment options Open storage

compartment

on Business

shuttle

Decorative

strip

matching

the version

Short elephant foot on A/T

and MMT version, while

long on 5M/T and 6M/T.

Knob depending on

powertrain

Depending on heating

or air conditioning

Proace Verso

Stop/Start

push-button

Depending on infotainment

with or without chromium-

plated surround

Urethane steering wheel with

or without infotainment

controls, or leather with

controls

With or

without

Head-up

display

Closed upper

glovebox

With Toyota Traction Select

knob and decoration, or

without

Style: PC level differentiation

The following pages set out the main visual exterior and interior differences (presentation and trims) between the

PC versions. They do not recap equipment differences, they simply show relatively standard exterior and interior

configurations. Certain images include optional equipment for the standard configurations across the range.

Different lengths are possible for different grades.

Options shown may vary from Standard equipment for each grade.

Style: grade differentiation

Proace combi

Black-coloured

front and rear

bumpers

Tinted rear

windows (image

non-compliant)

Black coloureddoor

handles, mirror shells

and side strips

Black hub caps on 16’’

(STD) or 17’’ steel wheels

or 17” full cover (OPT)

grey isorel

panels

visible steel panel

Rubber floor

Halogen bulbs

Long antenna if no radio

Urethane

steering

wheel

Optional

swing

doors

Seats on fixed anchor points Passenger bench seat option

PVC trim option

Van-style dashboard
