RAV4 – OUTLINE OF NEW FEATURES

RAV4

OUTLINE OF NEW FEATURES

The following changes are made for the 2009 model year.

1. Model Line-up

DThe following models with the 2AZ-FE engine have been discontinued:

Model Code Engine Transaxle Drive Type Grade

ACA33L-ANPXKA

2AZ-FE

U140F 4-speed Automatic 4WD

— (Standard)

ACA33L-ANPGKA Limited

ACA33L-ANPSKA Sport

ACA38L-ANPXKA

U241E 4-speed Automatic 2WD

— (Standard)

ACA38L-ANPGKA Limited

ACA38L-ANPSKA Sport

ACA33L-ANPXKK

U140F 4-speed Automatic 4WD

— (Standard)

ACA33L-ANPGKK Limited

ACA33L-ANPSKK Sport

DThe following models with the 2AR-FE engine have been introduced:

Model Code Engine Transaxle Drive Type Grade

ASA33L-A(C)NPXKA

2AR-FE

U140F 4-speed Automatic 4WD

— (Standard)

ASA33L-A(C)NPGKA Limited

ASA33L-A(C)NPSKA Sport

ASA38L-A(C)NPXKA

U241E 4-speed Automatic 2WD

— (Standard)

ASA38L-A(C)NPGKA Limited

ASA38L-A(C)NPSKA Sport

ASA33L-A(C)NPXKK

U140F 4-speed Automatic 4WD

— (Standard)

ASA33L-A(C)NPGKK Limited

ASA33L-A(C)NPSKK Sport

2. Exterior

DThe design of the headlights, radiator grille, and front bumper has been changed. For details, see page 9.

DThe design of the rear combination lights and rear bumper has been changed. For details, see page 11.

DModels with run-flat tires, on which the back door has no spare tire, are optional on the Sport grade of the

4WD models with the 2GR-FE engine. For details, see page 11.

DA large rear spoiler is provided on the Sport grade. For details, see page 12.

DThe antenna has been relocated from the front fender to the rear area of the roof. For details, see page 12.

DOutside rear view mirrors with attached side turn signal lights are provided. For details, see page 12.

DThe design of the 17-inch aluminum disc wheel has been changed. For details, see page 13.

DThe offset of the 18-inch aluminum disc wheel has been changed. For details, see page 13.

RAV4 – OUTLINE OF NEW FEATURES

10SMO18Y

Side Register Fin

’09 RAV4 ’08 RAV4

Escutcheon

Side Register

Console Garnish

Console Pocket

DThe following exterior colors are available, including 4 new colors:

Color No. Color Name Note

040 Super White II Carryover

070 White Pearl Crystal Shine Carryover

1F7 Silver Metallic Carryover

1G3 Gray Metallic New

202 Black Carryover

3R3 Red Mica Metallic Carryover

4T3 Bronze Mica Metallic New

4T8 Beige Metallic New

6T3 Dark Green Mica Carryover

8R3 Grayish Blue Metallic Carryover

9AF Dark Violet Mica Metallic New

3. Interior

DThe fawn interior color has been changed to sand beige.

DThe ornament color of the door trim has been changed to gray metallic paint color.

DPlated knobs are provided on the models with run-flat tires to give a luxurious impression.

DThe number of fins in the side register has been changed from 2 to 3.

DThe side registers, escutcheons, and console garnish have been changed from a light gray metallic color

to a dark gray metallic color.

DThe capacity of the console pocket has been increased in order to provide a space for storing a music player

or similar.

DThe ornament of the leather type shift knob has been changed to gray metallic paint and hairline grain.

RAV4 – OUTLINE OF NEW FEATURES 3

4. 2AR-FE Engine

A newly developed 2AR-FE engine has been added instead of the 2AZ-FE engine. For details, see page 14.

5. 2GR-FE Engine

A permanent DTC is used for the DTCs associated with the illumination of the MIL. The permanent DTCs

can not be cleared by using the Techstream, disconnecting the battery terminal, or removing the EFI fuse.

For details of the method to clear the DTCs, refer to the 2009 RAV4 Repair Manual (Pub No. RM10S0U).

6. U140F and U241E Automatic Transaxles

DU140F and U241E automatic transaxles are used on models with the 2AR-FE engine.

DA compact and lightweight ATF warmer is used.

DA permanent DTC is used for the DTCs associated with the illumination of the MIL. The permanent DTCs

can not be cleared by using the Techstream, disconnecting the battery terminal, or removing the EFI fuse.

For details of the method to clear the DTCs, refer to the 2009 RAV4 Repair Manual (Pub No. RM10S0U).

7. U151E and U151F Automatic Transaxles

A permanent DTC is used for the DTCs associated with the illumination of the MIL. The permanent DTCs

can not be cleared by using the Techstream, disconnecting the battery terminal, or removing the EFI fuse.

For details of the method to clear the DTCs, refer to the 2009 RAV4 Repair Manual (Pub No. RM10SU).

8. Suspension and Axle

A separate input construction type upper support is used in the front suspension of all models. For details of

the separate input construction type upper support, refer to the 2006 RAV4 New Car Features (NM01M0U).

9. Brake Control System

DA compact and lightweight brake actuator is used.

DA VSC OFF switch is used.

For details, see page 103.

10. EPS (Electric Power Steering)

Battery voltage drop suppression control is used in the EPS (Electric Power Steering) system. For details,

see page 106.

RAV4 – OUTLINE OF NEW FEATURES

10SBO001Y

Front Spat Approx. 10 mm

(0.4 in.)

Approx. 20 mm

(0.8 in.)

Previous Spat

New Spat

11. Body Structure

DA sound absorption structure is used for the dash inner insulator. Thus, it achieves a high level of sound

insulation and damping performance in terms of engine noise, combustion sound, gear noise, and road

noise.

DIn the dash inner insulator, the diameter of the passage hole for the heater pipe has been decreased to reduce

the noise entering from the engine compartment.

DThe steering column hole cover has been pressed against the dash panel. This improves sealing

performance and sound insulation.

DThe size of the front spat has been increased to attain favorable aerodynamic performance and fuel

economy.

DAn active headrest mechanism is used. For details, see page 107.

12. Lighting

An automatic light control system is provided as standard equipment for the Limited grade, and is available

as optional equipment for the Sport grade. For details, see page 108.

13. Meter

The following changes have been made to the ’09 RAV4.

DThe design of the combination meter has been changed.

DInstant fuel consumption and average fuel consumption are now shown on the multi-information display.

DThe indication size of the shift position indicator has been increased.

DA parking brake unreleased warning function has been added.

DThe design of the indicator lights has been partially changed.

For details, see page 110.

14. Air Conditioning

DA TSE17 type A/C compressor is used for models with 2AR-FE engine.

DThe design of the switches on the automatic control type heater control panel has been changed.

For details, see page 113.

15. Navigation System with AV System

A navigation system with AV system is available as optional equipment for the Limited and Sport grades.

For details, see page 114.

RAV4 – OUTLINE OF NEW FEATURES

10SBE38Y

Sliding Roof Switch

16. Rear View Monitor System

A rear view monitor system is available as optional equipment for the Limited and Sport grades. For details,

see page 120.

17. Wireless Door Lock Control System

In the customized body electronics system, the setting of the automatic lock time function has been changed

as follows:

System Techstream

Display Content Content Model Default

Setting

Available

Setting

Wireless Door

Lock Control

System

Auto Lock Time

Function to change the time

until relocking after

unlocking with the wireless

door lock.

’09 RAV4 60

30,

60,

120

or OFF

’08 RAV4 30 30 or 60

For details, refer to the 2009 RAV4 Repair Manual (Pub. No. RM10S0U).

18. Smart Key System

A smart key system is used for the Limited grade. For details, see page 123.

19. Sliding Roof System

The shape of the sliding roof switch on the overhead console has been changed.

20. Audio System

DNew audio head units are used.

DAn SDARS (Satellite Digital Audio Radio Service) antenna is used for all models.

DThe AUX adapter has been relocated.

DA DISP switch has been added for the steering pad switch. The DISP switch is provided as standard

equipment for all models.

For details, see page 159.

RAV4 – OUTLINE OF NEW FEATURES

10SBE37Y

Power Outlet Main Switch

Power Outlet Socket

(For AC Power Supply)

21. Power Outlet

DThe design of the power outlet main switch and power outlet socket (for AC power supply) has been

changed.

DThe power outlet socket (for AC power supply) is available as optional equipment for the Limited grade.

RAV4 – MODEL CODE

ASA33 L – A N P X K A

12345678

BASIC MODEL CODE

CODE

2STEERING WHEEL POSITION

L: Left-hand Drive

4BODY TYPE

N: 5-door Wagon

GEAR SHIFT TYPE

P: 4-speed Automatic, Floor

A: 5-speed Automatic, Floor

GRADE

X: — (Standard)

G: Limited

S: Sport

DESTINATION

A: U.S.A.

K: Canada

MODEL NAME

A: RAV4 (Produced by TMC*1)

C: RAV4 (Produced by TMMC*2)

7ENGINE SPECIFICATION

K: DOHC and SFI

ASA33

ASA38

GSA33

GSA38

ENGINE

2AR-FE

2GR-FE

DRIVE TYPE

4WD

2WD

4WD

2WD

MODEL CODE

*1: TMC: Toyota Motor Corporation

*2: TMMC: Toyota Motor Manufacturing Canada, Inc.

RAV4 – MODEL LINE-UP

MODEL LINE-UP

: New

DESTI-

NATION ENGINE BODY

TYPE GRADE

TRANSAXLE

4-speed Automatic 5-speed Automatic

2WD 4WD 2WD 4WD

U241E U140F U151E U151F

U.S.A.

2AR-FE

5-door

Wagon

—ASA38L-

A(C)NPXKA

ASA33L-

A(C)NPXKA — —

Limited ASA38L-

A(C)NPGKA

ASA33L-

A(C)NPGKA — —

Sport ASA38L-

A(C)NPSKA

ASA33L-

A(C)NPSKA — —

2GR-FE

— — — GSA38L-

A(C)NAXKA

GSA33L-

A(C)NAXKA

Limited — — GSA38L-

A(C)NAGKA

GSA33L-

A(C)NAGKA

Sport — — GSA38L-

A(C)NASKA

GSA33L-

A(C)NASKA

Canada

2AR-FE

— — ASA33L-

A(C)NPXKK — —

Limited — ASA33L-

A(C)NPGKK — —

Sport — ASA33L-

A(C)NPSKK — —

2GR-FE

— — — — GSA33L-

A(C)NAXKK

Limited — — — GSA33L-

A(C)NAGKK

Sport — — — GSA33L-

A(C)NASKK

RAV4 – NEW FEATURES

10SMO04Y10SMO02Y

10SMO03Y

’09 RAV4

Standard and Sport Grades

’08 RAV4

’09 RAV4 Limited Grade

NEW FEATURES

JEXTERIOR

1. Front Design

D2 types of design are provided for the front bumper and radiator grille. The front design of the Limited

grade consists of a large-size radiator grille and an underguard in order to differentiate it from the standard

and Sport grades.

DA newly designed headlight incorporating a front side turn signal light and a side marker within the same

lens is used.

DThe models with fog lights use plated rings for a luxurious look.

RAV4 – NEW FEATURES

10SMO06Y

10SMO05Y

Headlight (High Beam)

Turn Signal Light and

Side Marker

Headlight (Low Beam)

’09 RAV4

Headlight (High Beam)

Side Marker

Headlight (Low Beam) Turn Signal Light

’08 RAV4

10SMO09Y

10SMO07Y

10SMO08Y

’09 RAV4

Standard and Sport Grades

Plated Ring

’08 RAV4

Underguard

Plated Ring

’09 RAV4 Limited Grade

"Headlight A

"Radiator Grille and Front Bumper A

Autres manuels pour RAV4 2009

Table des matières

Autres manuels Toyota Automobile

Toyota

Toyota Matrix 2012 Manuel d'utilisation

Toyota

Toyota BZ4X 2023 Manuel utilisateur

Toyota

Toyota COROLLA MATRIX 2009 Manuel d'utilisation

Toyota

Toyota 2005 Yaris Manuel utilisateur

Toyota

Toyota 2005 SEQUOIA Manuel utilisateur

Toyota

Toyota 4Runner 2020 Manuel utilisateur

Toyota

Toyota CAMRY HYBRID 2019 Manuel utilisateur

Toyota

Toyota Prius 2007 Manuel utilisateur

Toyota

Toyota Prius 2007 Manuel utilisateur

Toyota

Toyota 2014 Sienna Guide d'installation

Toyota

Toyota 2010 Camry Hybrid Manuel utilisateur

Toyota

Toyota MIrai 2021 Manuel utilisateur

Toyota

Toyota 2007 Highlander Manuel utilisateur

Toyota

Toyota Camry Hybrid 2012 Manuel d'utilisation

Toyota

Toyota Land Cruiser 70 2017 Series Manuel utilisateur

Toyota

Toyota 2011 Camry Hybrid Manuel utilisateur

Toyota

Toyota Avalon 2007 Manuel utilisateur

Toyota

Toyota Prius 2023 Manuel utilisateur

Toyota

Toyota 2008 Camry Manuel utilisateur

Toyota

Toyota AVALON - 2011 Manuel utilisateur

Toyota

Toyota 2006 HIGHLANDER Manuel utilisateur

Toyota

Toyota Yaris 2016 Manuel utilisateur

Toyota

Toyota CAMRY CNG Manuel utilisateur

Toyota

Toyota RAV4 Hybrid 2020 Manuel utilisateur

Manuels Automobile populaires d'autres marques

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur

Skoda

Skoda FABIA RS - ANNEXE 118 Manuel utilisateur
