Totally Wicked Buzz Manuel utilisateur

USER MANUAL BEDIENUNGSANLEITUNG

CONGRATULATIONS ON PURCHASING YOUR

TOTALLY WICKED BUZZ

ELECTRONIC CIGARETTE KIT

Using your Buzz Kit

510 Connector

Power Button

OLED Display

Adjustment Buttons

Micro-USB Port

Battery Cover

Mouthpiece

Top Cap

Glass Tube

Atomizer Head

Atomizer Base

Using your Buzz Kit

Installing an 18650 battery:

To insert the battery, turn the Buzz

body upside down, locate the

battery door and use a ﬁnger to slide

open the battery door to release

it from the locking mechanism.

Insert the battery into the battery

compartment ensuring the battery’s

positive connection is inserted ﬁrst.

Finally, push the battery door closed

then slide to lock, ensure the battery

door is fully locked into place.

Note: Ensure only a high drain cell

with a continual discharge rate of

25 amperes or above is installed

into the Buzz kit. Do not use any

batteries that have torn battery

wraps.

Using your Buzz Kit

Powering On and Off:

The Buzz kit uses a 5 click on/off

function. To switch the Buzz on,

press the power button ﬁve times in

quick succession, the OLED display

will illuminate to indicate the Buzz

has been switched on. Similarly,

when the device is powered on,

press the power button ﬁve times in

quick succession to turn the Buzz

off, the OLED display will deactivate

to indicate the Buzz has been

switched off.

Charging the Battery:

The Buzz is recharged by inserting

the micro USB cable into the micro

USB port located directly beneath

the left and right adjustment buttons,

insert the other end of the USB cable

into a powered USB port or suitable

USB wall adaptor. The battery status

symbol on the OLED display will

initially ﬂash to indicate charging

activity, the battery status symbol

will then rise and fall while charging.

Once fully charged, the OLED

display will deactivate. Charging with

Using your Buzz Kit

a QC2.0 Wall Adaptor will be around

30% faster than charging with a

standard 1.0A USB adaptor.

Alternatively, the 18650 battery

can be removed from the Buzz

and charged in an external battery

charger.

Installing/Replacing an Atomizer

Head:

To install a new atomizer head, turn

the Hornet tank upside down so the

mouthpiece points toward the ﬂoor,

hold the Hornet tank ﬁrmly, then

unscrew the base to fully dismantle

the tank. Place the upper section

of the tank to one side, ensuring it

remains upside down to prevent ﬂuid

spillage. Unscrew the atomizer head

from the tank base. Screw the new

atomizer head into the tank base,

and reassemble the tank using the

reverse of the above procedure.

Note: Be sure to “prime” the

atomizer head before ﬁrst use by

dripping in a few drops of e-liquid,

then allowing it to sit in a tank

full of E-liquid for a few minutes

before vaping. This ensures the

atomizer head is fully saturated

with E-liquid.

Using your Buzz Kit

Filling with E-liquid:

To ﬁll the Hornet tank, locate for

the ﬁll symbol located on top of the

Hornet tank, grasp the mouthpiece

ﬁrmly and push/slide in the direction

pictured below to open the tank.

The entire hinged top cap assembly

will open up to reveal two E-liquid

ﬁll holes. Carefully ﬁll the Hornet

tank with E-liquid until the tank is

full. Take care to avoid ﬁlling down

the large, central chimney hole, only

ﬁll with E-liquid using either of the

designated ﬁll holes located either

side of the central chimney hole.

Once ﬁlled with E-liquid, close the

hinged top cap assembly then ﬁrmly

slide it shut in the opposite direction,

an audible click will be heard once

the locking mechanism is fully

engaged.

Using your Buzz Kit

Hornet Tank Airﬂow Adjustment:

To adjust the amount of airﬂow

the Hornet tank provides, slowly

rotate the airﬂow control ring on the

atomizer base to expose the desired

proportion of the airﬂow slot.
