TOSHIBA REMOTE RECEIPT PRINTER

TRST-A10 SERIES

Document No. EO10-13009A

Original Nov., 2007

(Revised Feb., 2008)

Product Descri

tion

EO10-13009A

TABLE OF CONTENTS

Page

1. OUTLINE -------------------------------------------------------------------------------------------------1- 1

1.1 FEATURES OF THE PRINTER -----------------------------------------------------------------------1- 1

1.2 DESCRIPTION OF MODEL NUMBER --------------------------------------------------------------1- 2

1.3 OVERVIEW AND DIMENSIONS ----------------------------------------------------------------------1- 3

1.3.1 Front View/Rear View --------------------------------------------------------------------------------1- 3

1.3.2 Connectors ----------------------------------------------------------------------------------------------1- 3

1.3.3 LED and Feed Button ---------------------------------------------------------------------------------1- 4

1.3.4 Datascope Mode ---------------------------------------------------------------------------------------1- 6

1.4 SYSTEM CONFIGURATION ---------------------------------------------------------------------------1- 7

1.5 BASIC SPECIFICATION --------------------------------------------------------------------------------1- 8

1.6 ELECTRONIC SPECIFICATIONS --------------------------------------------------------------------1- 9

1.7 DRAWER INTERFACE ---------------------------------------------------------------------------------1-21

1.7.1 Drawer Kick Drive Signal ---------------------------------------------------------------------------1-21

1.7.2 Electronic Characteristics ---------------------------------------------------------------------------1-21

1.7.3 Connector Description -------------------------------------------------------------------------------1-21

1.7.4 Drive Circuit --------------------------------------------------------------------------------------------1-22

1.8 DC POWER CONNECTOR ----------------------------------------------------------------------------------1-23

1.9 POSITION OF CUTTER --------------------------------------------------------------------------------------1-23

1.10 SENSORS --------------------------------------------------------------------------------------------------------1-24

2. SUPPLY SPECIFICATIONS ------------------------------------------------------------------------2- 1

2.1 EFFECTIVE PRINTING AREA ------------------------------------------------------------------------2- 1

2.2 DESIGN OF PAPER ROLL -----------------------------------------------------------------------------2- 3

CAUTION!

1. This manual may not be copied in whole or in part without prior written permission of TOSHIBA

TEC.

2. The contents of this manual may be changed without notification.

3. Please refer to your local Authorised Service representative with regard to any queries you

may have in this manual.

by TOSHIBA TEC CORPORATION

570 Ohito, Izunokuni-shi, Shizuoka-ken, JAPAN

1. OUTLINE EO10-13009A

1.1 FEATURES OF THE PRINTER

1-1

1. OUTLINE

1.1 FEATURES OF THE PRINTER

1) This printer is a single station printer for 80 mm width receipt and is equipped with the RS-232C

serial interface, USB interface or parallel interface (option), conforming to the ESC/POS

commands.

2) Paper drop-in mechanism realizes easy paper loading and head cleaning. When setting or

replacing the paper roll, only load it into the printer and close the cover.

3) This printer performs in thermal direct method at high speed (max. 225 mm/s) with less noise.

4) Since the paper outlet is provided at front side of the printer, the receipt can be taken out easily

and flexible installation is possible.

5) The cover closed tightly prevents any foreign material and liquid from getting into the printer.

6) This printer performs barcode printing with special commands.

7) Print layout can be variously arranged.

8) User-defined characters and logos can be stored into the flash memory.

9) An automatic cutter is provided as standard. (Partial cut)

10) The body color is selectable from Fair White (FW) and Cool Black (CB) as standard to color

coordinate with the POS terminal to be connected.

11) The AC adapter can be used in every country.

NOTE: Every size is written in millimeter (mm) in this manual. To obtain the size in inch, divide by 25.4.

1. OUTLINE EO10-13009A

(Revision Date: Feb. 06, 2008)

1.2 DESCRIPTION OF MODEL NUMBER

1-2

1.2 DESCRIPTION OF MODEL NUMBER

Model name description

TRST-A1 - - -

NOTE: Some combinations of the above specifications are not developed as products. For

details, please refer to your nearest authorized TOSHIBA TEC representative.

Destination Code

QM: Standard for Worldwide

CN: China

RoHS compliance

R: RoHS-Compliant model

Body Color

F: Fair White

C: Cool Black

AC Adaptor & Power Cable

Blank : Without AC adapter and power cable

1 : With AC adapter, without power cable

Interface Type

S: Standard Interface (Serial & USB)

P: Parallel Interface

Printer Type

5: Dual Side Printer

0: Single Side Printer

1. OUTLINE EO10-13009A

1.3 OVERVIEW AND DIMENSIONS

1-3

1.3 OVERVIEW AND DIMENSIONS

1.3.1 Front View/Rear View

1.3.2 Connectors

1 [DC24V] (Socket connector)

The built-in AC adapter supplies +24V power to the printer through this connector. Do not

connect anything other than the Toshiba TEC Specified AC adapter.

2 [Serial interface connector]

An interface cable which connects the printer to a POS terminal or Personal Computer is

connected to this connector. A RS-232C interface cable (Serial I/F model)

Front View Rear View

Feed Button

LED Printer Cover

Cover Top

Power Switch

4 1 23

5 1

1. OUTLINE EO10-13009A

1.3 OVERVIEW AND DIMENSIONS

1-4

3 [USB interface connector]

An interface cable which connects the printer to a POS terminal or Personal Computer is

connected to this connector, a USB I/F (V2.0 Full Speed) is needed for this connector.

4 [Drawer interface Connector] [CDKO] (6 pin modular connector)

A drawer cable which connects the printer to a drawer is connected to this connector. To this

connector, a Toshiba drawer can be connected. Do not connect anything other than the

connectable drawer.

5 [Parallel interface connector]

An interface cable which connects the printer to a POS terminal or Personal Computer is

connected to this connector. A Parallel interface cable (Parallel I/F model) is needed for this

connector.

1.3.3 LED and Feed Button

POWER LED (Green)

Lights when the power is turned on.

ERROR LED (Blinking Green)

The Error LED indicates an error by

blinking.

FEED Button

Used to feed receipt paper. A touch

of this button causes one line feed.

Pressing and holding it feeds the

paper continuously. When the power

switch is turned on while the [FEED]

button is pressed and held, the

printer will perform a self test print.

1. OUTLINE EO10-13009A

1.3 OVERVIEW AND DIMENSIONS

1-5

Error Status Table

Green LED Blinking (Slow)

Problem What to Do Where to Go

Receipt paper is low* There are about 4 ½ meters, ±3 meters, (15 feet,

±10 feet) of paper left. Change the paper soon to

avoid running out of paper part way through a

transaction.

Green LED Blinking (Fast)

Problem What to Do Where to Go

Receipt paper is out Change the paper now. Do not run a transaction

without paper as the data may be lost.

Receipt cover is open Close the cover. The printer will not operate with

the cover open.

Knife failure Open the receipt cover and check the knife. Clear

any jammed paper you can see. Tear off any

excess paper against the tear-off blade.

NOTE:If other LED status except for the above occurs, turn the power off, and then on. If this does

not restore the LEDs, contact your nearest TOSHIBA TEC representative for assistance.

1. OUTLINE EO10-13009A

1.3 OVERVIEW AND DIMENSIONS

1-6

1.3.4 Datascope Mode

Datascope Mode allows the user to test the printer’s communications. When in Datascope Mode

the printer receives all communications, but instead of executing the commands it prints them

out on receipt paper as hexadecimal numbers in the order received. For example, the ASCII

character “A” is printed as the hexadecimal number 41 an so on.

To run the Datascope Mode:

After you have enabled the Data scope Mode through the Configuration Menu, exit the

Configuration Menu.

1. Run a transaction from the host computer.

All commands and data sent from the host computer will be printed as hexadecimal numbers as

shown in the illustration.

30 31 32 33 34 35 36 37 38 39 40 41 : 0 1 2 3 4 5 6 7 8 9 @ A

41 42 43 44 45 46 47 48 49 50 51 52 : A B C D E F G H I J K L

To exit the Datascope Mode:

1. Enter the Configuration Menu again

2. Disable the Data scope Mode

3. Exit the Configuration Menu

The printer is in Normal Mode and can communicate with the host computer.

1. OUTLINE EO10-13009A

1.4 SYSTEM CONFIGURATION

1-7

1.4 SYSTEM CONFIGURATION

Serial or Parallel

Interface

Drawer Interface

(Drawer Kick Specification)

DC 24V

TOSHIBA TEC DRAWER

(DRWST-51A-8MVG-QM-R,etc.)

POS Terminal

(ST-A10 series, etc.)

AC Adapter

1. OUTLINE EO10-13009A

(Revision Date: Feb. 06, 2008)

1.5 BASIC SPECIFICATIONS

1-8

1.5 BASIC SPECIFICATIONS

Item Description

Printing method Line thermal dot printing method

Printing width (Font Size 1)

80 mm (576 dots)

58 mm (432 dots)

(Font Size 2)

80 mm (560 dots)

58 mm (424 dots)

Resolution 203.2 dpi x 203.2dpi

Printing speed Max. 9 ips max (225 mm/sec) for 75W, 55W mode

2 color printing Max 50 mm/sec

(Font Size 1)

80 mm Paper

48 Column (at 16.9 cpi Standard Character)

64 Column (at 22.6 cpi Compress Character)

24 Column (Double bytes Font)

58 mm Paper

36 Column (at 16.9 cpi Standard Character)

48 Column (at 22.6 cpi Compress Character)

16 Column (Double bytes Font)

Printing columns

(Font Size 2)

80 mm Paper

42 Column (at 15.6 cpi Standard Character)

56 Column (at 20.3 cpi Compress Character)

58 mm Paper

32 Column (at 15.6 cpi Standard Character)

42 Column (at 20.3 cpi Compress Character)

Character size Font A: 1.5 x 3.00 mm

Font B: 1.125 x 3.00 mm

Character types Code pages PC437, PC850, PC852, PC857, PC858, PC860,

PC863, PC865, PC866 PC949(STD Model only),

PC54936(China model only) and PC1252

Logo registration and print User defined characters and logos are downloadable in the

flash

memory.

Line spacing 7.52 (default) and variable lines per inch.

Printable bar codes UPC-A, UPC-E, JAN13 (EAN), JAN8 (EAN), Code 39, Code

128, Interleaf 2 of 5, Codabar, PDF417, Code 93

Cut method Partial Cut

Paper Thermal paper roll: 80 mm x dia. 83 mm (Max)

Thermal paper roll: 58 mm x dia. 83 mm (Max)

Interface RS232C I/F or USB I/F (V2.0 Full Speed). Parallel as Option.

Input buffer 4K bytes/128 bytes

Printer supply input voltage Rated output: DC 24V, 3.15A (75W)

Power consumption 3.15A (75W Power Supply), 2.29A (55W Power Supply)

AC adapter specification Rated input: AC 100 – 240V, 50/60Hz, 2.0A max

Rated output: DC 24V, 3.15A (75W)

Body color Fair White (FW) or Cool Black (CB)

Operating temperature 5ºC to 50ºC

Operating humidity 10% to 90% RH (no condensation)

Storage temperature -20ºC to 60ºC

Storage humidity 10% to 90% RH (no condensation)

Weight 1.7 Kg

Dimension 145.5 mm (W) x 185.5 mm (D) x 141.0 mm (H)

Autres manuels pour TRST-A10 SERIES

Table des matières

Autres manuels Toshiba Imprimante

Toshiba

Toshiba B-EX4 SERIES Caractéristiques techniques

Toshiba

Toshiba B-SA4TM-GS12 Manuel utilisateur

Toshiba

Toshiba B-SX4T Series Manuel utilisateur

Toshiba

Toshiba B-SX5T Series Caractéristiques techniques

Toshiba

Toshiba TEC B 452 Manuel de la liste des pièces

Toshiba

Toshiba B-852 Advance Manuel utilisateur

Toshiba

Toshiba E-STUDIO E-Studio 3511 Manuel de service

Toshiba

Toshiba SureMark 4610 Manuel utilisateur

Toshiba

Toshiba B-SX6T Series Manuel utilisateur

Toshiba

Toshiba e-STUDIO 305CP Manuel utilisateur

Toshiba

Toshiba B-EP Series Manuel utilisateur

Toshiba

Toshiba e-STUDIO2010AC Manuel utilisateur

Toshiba

Toshiba TEC B B-SX5T SERIES Manuel utilisateur

Toshiba

Toshiba e-STUDIO 16P Manuel utilisateur

Toshiba

Toshiba B-SA4T Manuel utilisateur

Toshiba

Toshiba e-STUDIO222CP Manuel utilisateur

Toshiba

Toshiba B-672-QP Manuel utilisateur

Toshiba

Toshiba B-FP3D-GH30-QM-R Manuel utilisateur

Toshiba

Toshiba e-STUDIO2010AC Manuel de programmation

Toshiba

Toshiba E-STUDIO 282 Manuel utilisateur

Toshiba

Toshiba TEC B-SP2D Series Manuel utilisateur

Toshiba

Toshiba SureMark 4610 1NR Instructions d'installation

Toshiba

Toshiba B-480-QQ Manuel utilisateur

Toshiba

Toshiba B-SV4D Series Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
