Bluetooth™ SD card User's Manual Rev. 1.1 (April 26, 2001) 1

Bluetooth™ SD card

User's Manual

Rev. 1.2 (May 16, 2001)

TOSHIBA CORPORATION

Digital Media Network Company

Confidential

Bluetooth™ SD card User's Manual Rev. 1.1 (April 26, 2001) 2

Revision History

Revision Date Comments

1.0 2001-04-25 Initial Revision

1.1 2001-04-26 Page5: Added Mode name (Palm™Bluetooth™Card) and Model

No.(SD-BT00P) for OEM

1.2 2001-05-16 Page3: Added a sentence in “Feature” section.

Confidential

Bluetooth™ SD card User's Manual Rev. 1.1 (April 26, 2001) 3

Feature

Bluetooth™ SD card is an ultra small and thin card with has built-in antenna and SD/IO interface

compliant with SDIO-spec issue by SD Association. Also, as data transmitter/receiver ,CSR’s

BlueCore01, which covers Baseband protocol and Link manager protocol, is incorporated into this card

to enable any kind of devices which incorporate SDIO-spec SD card slot and the driver software for

Bluetooth™ SD card to communicate with each other through this card.

Bluetooth™ SD card can be used with any kind of devices which have SDIO card slot and software for

Bluetooth SD card, i.e. PDAs, portable PCs, desktop PCs, digital still cameras, cellular phones.

Appearance

Direction of insertion

Indication lamp (green)

It lights on during communication.

Installation

When inserting this card into SD card slot, check the form of the connector and insert it surely.

PDA supporting the SD/IO Card

• Connect the Bluetooth™ SD Card to a PDA.

This drawing is an example.

As for the position where the

Bluetooth™ SD card is

connected, refer to the User’s

Manual of PDA.

Confidential

Bluetooth™ SD card User's Manual Rev. 1.1 (April 26, 2001) 4

What you can do with the Bluetooth™ SD Card

(1) Mobile communication with cellular phones

PDA Cellular phone

(2) Data communication between digital still cameras and PCs

Digital still camera

PC with Bluetooth

Confidential

Bluetooth™ SD card User's Manual Rev. 1.1 (April 26, 2001) 5

Specifications

Model name BluetoothTM SD Card *1

Palm™ Bluetooth™ Card *1

Model No. SD-BT00A, SD-BT00U, SD-BT00P *1

Bluetooth™

specification Bluetooth™ Ver.1.0b*2 + critical errata

Specification of

electric Operating voltage : 3.1 to 3.6V

At initializing the card, the voltage of 1.6V to 3.6V is

supplied and some parts of SD-IO controller operate.

Ripple voltage :

50mVp-p or less

RF specification In conformity with Bluetooth radio specification

Transmission electric power class : Power class 3

[ maximum output : 1mW (0dBm)]

Sensitivity of receiving : –70dBm

Power management: No

Dimension 49mm-high x 24mm-wide x 2.1mm-thick

A part of protrusion is 2.8mm-thick.

Indication

function LED : green (It lights during communication.)

No light can be selected on by user.

*1 : SD-BT00A, SD-BT00U (for Toshiba product)

SD-BT00P ( for OEM product )

There is no difference among product with the number in hardware and firmware.

*2 : Bluetooth Special Interest Group, Document No. 1.C.47/1.0B, December 1, 1999

Confidential

Bluetooth™ SD card User's Manual Rev. 1.1 (April 26, 2001) 6

Ohme, April 25 , 2001

Place, Date Sign Hiroshi Hamada
