TomTom XL

Installation1.

Installation

2 SEC

1 2

180°

What’s in the box2.

What’s in the box aYour TomTom XL bEasyPortTM holder

cCar charger dUSB cable

eDocumentation pack

Before you start3.

Before you start

Switching on and off

Install your TomTom XL navigation device in your car following the

instructions in the installation section at the start of this book.

To switch on your navigation device, press and hold the On/Off button until

you see the start-up screen. The first time you switch on your device, it may

take a short time to start.

To set up your device you need to answer a few questions by tapping the

screen.

Device not starting

In rare cases, your TomTom XL navigation device may not start correctly or

may stop responding to your taps.

First, check that the battery is properly charged. To charge the battery,

connect your device to the car charger. It can takeup to 2 hours to fully charge

the battery.

If this does not solve the problem, you can reset the device. To do this, press

and hold the On/Off button for 15 seconds and release the button when your

device begins to restart.

Charging your TomTom XL

Before you use your XL for the first time, it’s a good idea to charge it fully.

The battery in your TomTom XL navigation device chargeswhen you connect

it to the car charger or to your computer.

There is no charging light on your XL. To check the battery status and see

when your XL is charging, switch on your device and tap the bottom right-

hand corner of the screen in the Driving View. The battery status is shown on

the next page.

When you connect your device to a computer, you are asked if you want to

connect to the computer. If you select No and then do not tap the screen

within three minutes, the devicewill automatically switch off. This happens so

that the battery can charge faster.

Note: You should plug the USB connector directly into a USB port on your

computer and not into a USB hub or USB port on a keyboard or monitor.

Battery notes

The battery in your TomTom XL navigation device chargeswhen you connect

it to the car charger or to your computer.

When you connect your device to a computer, you are asked if you want to

connect to the computer. If you select No and then do not tap the screen

within three minutes, the devicewill automatically switch off. This happens so

that the battery can charge faster.

Note: You should plug the USB connector directly into a USB port on your

computer and not into a USB hub or USB port on a keyboard or monitor.

GPS reception

When you first start yourTomTom XL navigation device, the device may need

a few minutes to determine your GPS position and show your current position

on the map. In future, your position will be found much faster, usually within

a few seconds.

To ensure reception of a strong GPS signal, you should use your device

outdoors. Large objects such as tall buildings can sometimes interfere with

reception.

Take care of your device

Never leave your TomTom XL navigation device or accessories on view when

you leave the car or they may become an easy target for thieves.

Youcan seta passwordfor yourdevicewhich mustbe entered every timeyou

start it.

It is important to take care of your device.

• Your device is not designed for use in extreme temperatures and any such

exposure may cause permanent damage.

• Do not open the casing of your device under any circumstances. Doing so

may be dangerous and will invalidate the warranty.

• Wipe or dry the screen of your device using a soft cloth. Do not use any

liquid cleaners.

Safety4.

Safety

Positioning the dock

Consider carefully where to attach the dock in your car. The dock should not

block or interfere in any way with the following:

• Your view of the road

• Any of the controls in your car

• Any of your mirrors

• The airbag

You should be able to reach your navigation device easily when it is in the

dock without leaning or stretching. The diagrams show where you can safely

attach the dock.

You can attach the dock to the windscreen, side window or use a Dashboard

Mount Disk to attach the dock to your dashboard. TomTom also offers

alternative mounting solutions for yourTomTom navigation device. For more

information about Dashboard Mount Disks and alternative mounting

solutions, go to www.tomtom.com/accessories.

Installing the dock

Make sure that both the holder and your window are clean and dry.

1. Press the suction cup firmly against the window onan area where the glass

is flat.

2. Twist the base of the EasyPort holder in a clockwise direction to lock the

holder in place.

For detailed instructions, check the installation section at the start of this

manual.

Safety preferences

We recommend using the safety preferences to make your driving as safe as

possible. The safety preferences include, for example, the following options:

• Hide most menu options when driving

• Show safety reminders

• Warn when driving faster than allowed

TomTom Safety Alerts

The TomTom Safety Alerts service warns you about a variety of locations

including:

• Safety camera locations.

• Accident blackspot locations.

• Mobile safety camera locations.

• Average speed camera locations.

• Toll road camera locations.

• Traffic light camera locations.

Important: Regularly connect your navigation device to TomTom HOME to

update the list of locations for all Safety Alerts. If a wireless connection is

available for your device, mobile safety camera locations can be sent to your

device using a wireless connection.

When a safety camera location is shown on the map, a warning sound is

played to warn you that you are approaching an area where a safety camera

is located.

If you discover a location that has a safety camera but you receive no warning,

you can report the new location to TomTom using your XL.

Making your first journey5.

Making your first journey Planning a route with your TomTom XL navigation device is easy. To plan a

route, follow the steps below.

Important: For safety reasons, you should always plan a route before you

start your journey.

1. Tap the screen to bring up the Main Menu.

Note: The buttons on your navigation device are shown in full colour unless

a button is currently unavailable. For example, the button named Find

alternative in the Main Menu is not available until you have planned a route.

2. Tap Navigate to...

3. Tap Address.

When you enter an address, you can choose from the following options:

•City centre - tap this button to set your destination as the centre of a city

or town.

•Street and house number -tapthisbuttontoset anexactaddress as your

destination.

•Postcode - tap this button to enter a postcode as your destination.

Note: You can enter a postcode for any country. In some countries, postcodes

are detailed enough to identify a house on their own. In other countries you

can enter a postcode to identify a town or area. You will then have to enter a

street and house number.
