Toastmaster XO-1STM Tabletop Steam Oven

LABORATORY CERTIFICATION AND APPROVAL

XO-1STM Tabletop Steam Oven

Tabletop Oven

XO-1STM Tabletop Steam Oven

STANDARD FEATURES:

•Stainless steel construction

•Magnetic door handle

•4” legs

•Silicone rubber gasket

•Tempered glass door

•Solid state controls

•Internally generated steam

•2 speed fan

OPTIONS:

•Wire Shelf Racks each (98-0125-B)

•Cart with Panslides (98-9890-PS)

•Cart without Panslides (98-9890-NP)

•Stand with Panslides (98-9970-PS)

•Stand withoust Panslides (98-9970-NP)

•Stacking Kit

•Solid Door

Note: Units cannot be stacked when using

cart or stand.

SIZE:

XO-1STM - 20” High, 27-1/8” Wide, 28-1/8” Deep

508 mm High, 689 mm Wide, 714 mm Deep

Toastmaster’s XO-1STM offers the capability to

steam, dry bake or bake with steam. Steam is

generated internally by using the same elements

that generate the heat. This eliminates the need

for a boiler or reservoir. Maintenance is at a

minimum since there is no need to de-lime as

usually required in other steam units.

When producing product in the cook mode, simply

set the controls to the desired temperature. If

steam is desired, simply set the steam timer to the

desired setting.

These countertop units are constructed of long life,

heavy duty stainless steel. Our unique Moving Air

system ensures that your product will be heated

evenly, producing consistent quality results. These

units feature solid state controls which are both

durable and user friendly.

CONSTRUCTION:

•Welded stainless steel

•Fully insulated

•Control panel accessible through front of unit

•Heating elements accessible inside of cabinet

and through side

CONTROLS:

•Solid state controls

•Indicator light for thermostat

•Two speed fan

Toastmaster XO-1STM Tabletop Steam Oven

Toastmaster ®5600 13th Street, Menominee, MI 49858 • www.toastmastercorp.com

Toll Free: 1-800-338-9886 • Telephone: 1-906-863-4401 • Fax: 1-906-863-5889

INTENDED FOR COMMERCIAL USE ONLY NOT FOR HOUSEHOLD USE

Toastmaster, in line with its policy to continually improve its product,

reserves the right to change materials or specifications without notice. Such

revisions do not entitle the buyer to corresponding changes, improvements,

additions, or replacements for previously purchased equipment.

XO-1STM Tabletop Steam Oven

101/8”

123/4”

281/8”

20”16”

271/8”

237/8”

STEAM

VENT

CONNECTION

1/4” WATER INLET

FRONT

TOP SIDE BACK

POWER CORD

INLET

63/4”51/2”

21/2”

31/2”

120 Volt, 20 Amp

(NEMA 5-20 P)

SPECIFICATIONS:

ELECTRICAL:

• 120/1 at 16.5 Amps.

SERVICE CONNECTIONS:

• Unit is shipped from factory with cord and plug.

• 120-Volt single phase is standard.

LISTINGS:

The XO-1STM has C-ETL-US & NSF listings.

INSTALLATION:

Allow four inches on each side and back of unit for

ventilation of oven.

DOOR SWING: Oven - 17” (432 mm)

PACKING SIZE:

24” High, 36” Wide, 36” Deep

(610 mm High, 914 mm Wide, 914 mm Deep)

SHIPPING WEIGHT:

140 Pounds (64 Kg), FOB Menominee, MI 49858

Amp Draw 208/1 208/3 240/1 240/3

L1 14.5 n/a 13 n/a

ELECTRICAL:

DIMENSIONS:

Height Width Depth

Exterior 20” 27-1/8” 28-1/8”

Interior 11-3/4” 15-3/4” 21-1/2”

CAPACITY:

13”x18”

Sheet Pans Spacing

Oven 33-

3/4”

42”
