TUSB564RNQ Evaluation Module

User's Guide

SLLU288–March 2018

TUSB564RNQ Evaluation Module

This user's guide describes the characteristics and use of the TUSB564RNQ evaluation module. This

document describes how to power up the EVM and also includes schematics that can be used as

reference design for the Alternate mode implementations of the system with the TUSB564 device.

Contents

1 Introduction ................................................................................................................... 2

2 TUSB564RNQ EVM......................................................................................................... 2

3 TUSB564RNQ EVM Configuration........................................................................................ 3

3.1 TUSB564RNQ EVM Default Configuration...................................................................... 3

3.2 TUSB564 Equalization Control.................................................................................... 3

3.3 Power................................................................................................................. 4

4 TUSB564RNQ EVM Schematics and Bill of Materials.................................................................. 5

4.1 Schematics .......................................................................................................... 5

4.2 Bill of Materials...................................................................................................... 9

List of Figures

1 TUSB564RNQ EVM......................................................................................................... 2

2 Test Board Setup............................................................................................................ 2

3 TUSB564RNQ EVM Main Schematic..................................................................................... 5

4 TUSB564RNQ EVM Configuration Pins.................................................................................. 6

5 TPS65986..................................................................................................................... 7

6 TUSB564RNQ EVM Power ................................................................................................ 8

List of Tables

1 TUSB564 Configuration Pins............................................................................................... 3

2 Configuration Pin Level Definitions........................................................................................ 3

3 USB 3.1 EQ Settings........................................................................................................ 3

4 DisplayPort™ EQ Settings ................................................................................................. 4

5 Bill of Materials............................................................................................................... 9

Trademarks

USB Type-C is a trademark of USB Implementers Forum.

DisplayPort is a trademark of Video Electronics Standards Association.

VESA is a registered trademark of Video Electronics Standards Association.

All other trademarks are the property of their respective owners.

DP Source

USB Host TUSB1046EVM

USBDP

USB Type-C

USB Hub / Device

TUSB564RNQEVM

USB DP

USB Type-C

DP-Branch / Sink

Introduction

www.ti.com

2SLLU288–March 2018

Submit Documentation Feedback

TUSB564RNQ Evaluation Module

1 Introduction

The TUSB564 device is a USB Type-C™ / VESA®DisplayPort™ (DP) alternate mode redriving switch

supporting USB data rates up to 5 Gbps for a USB Type-C upstream facing port (UFP).

2 TUSB564RNQ EVM

Figure 1 shows the TUSB564RNQ EVM.

Figure 1. TUSB564RNQ EVM

The TUSB564RNQ EVM can be used with an Alternate mode USB Type-C source such as the TUSB1046

EVM and/or USB or DisplayPort USB Type-C Host system to evaluate the USB Type-C implementation.

Figure 2 shows a typical test setup.

Figure 2. Test Board Setup

The TUSB564RNQ EVM has a legacy Type-A USB receptacle to connect to a USB hub or device and a

DisplayPort receptacle to connect to DisplayPort sink. The EVM uses TI's TPS65986 device for USB

Type-C PD control and to configure the TUSB564.

www.ti.com

TUSB564RNQ EVM Configuration

SLLU288–March 2018

TUSB564RNQ Evaluation Module

3 TUSB564RNQ EVM Configuration

This section provides the configuration options available in the TUSB564RNQ EVM.

3.1 TUSB564RNQ EVM Default Configuration

Table 1 lists the default configuration pins for the TUSB564 device. Configuration settings may need to be

optimized depending on the amount of loss of each channel in the system. The EVM is configured to

GPIO mode by default. If I2C configuration is desired, JMP7 (I2C_EN) shunt must be changed to shunt

pins 2-3 (VCC).

Table 1. TUSB564 Configuration Pins

Reference

Designator JMP Control Configuration

JMP1 Downstream EQ1 SHUNT on pin 2-4 (R – 20k to GND)

JMP2 Downstream EQ0 SHUNT on pin 2-4 (R – 20k to GND)

JMP3 Downstream SSEQ1 SHUNT on pin 2-4 (R – 20k to GND)

JMP4 Downstream SSEQ0 SHUNT on pin 2-4 (R – 20k to GND)

JMP5 DP EQ1 SHUNT on pin 2-4 (R – 20k to GND)

JMP6 DP EQ0 SHUNT on pin 2-4 (R – 20k to GND)

JMP7 I2C_EN SHUNT on pin 1-2 (GND)

J1 FLIP No SHUNT

J2 CTL0 No SHUNT

J3 CTL1 No SHUNT

J4 EN SHUNT on pin 1-2 (PU)

3.2 TUSB564 Equalization Control

Equalization (EQ) can be controlled through I2C or pin-strapping (see Table 2). Each TUSB564 receiver

lane has individual controls for receiver equalization. Table 3 and Table 4 detail the gain values for each

available combination for downstream, upstream, and all DisplayPort configurations.

Table 2. Configuration Pin Level Definitions

Level Settings

0Option 1: Tie 1 kΩ5% to GND.

Option 2: Tie directly to GND.

R Tie 20 kΩ5% to GND.

F Float (leave pin open)

1Option 1: Tie 1 kΩ5% to VCC.

Option 2: Tie directly to VCC.

Table 3. USB 3.1 EQ Settings

USB 3.1 Downstream Facing Ports USB 3.1 Upstream Facing Ports

EQ1 Pin Level EQ1 Pin Level EQ Gain at 2.5 GHz

(dB) SSEQ1 Pin

Level SSEQ1 Pin

Level EQ Gain at 2.5 GHz

(dB)

0 0 –2.4 0 0 –0.9

0 R –1.3 0 R 0.2

0 F –0.4 0 F 1.2

0 1 0.7 0 1 2.2

R 0 1.5 R 0 3.1

R R 2.5 R R 4.0

R F 3.2 R F 4.8

R 1 4.0 R 1 5.6

F 0 4.8 F 0 6.3

TUSB564RNQ EVM Configuration

www.ti.com

4SLLU288–March 2018

Submit Documentation Feedback

TUSB564RNQ Evaluation Module

Table 3. USB 3.1 EQ Settings (continued)

USB 3.1 Downstream Facing Ports USB 3.1 Upstream Facing Ports

EQ1 Pin Level EQ1 Pin Level EQ Gain at 2.5 GHz

(dB) SSEQ1 Pin

Level SSEQ1 Pin

Level EQ Gain at 2.5 GHz

(dB)

F R 5.5 F R 7.0

F F 6.0 F F 7.5

F 1 6.6 F 1 8.1

1 0 7.1 1 0 8.5

1 R 7.6 1 R 9.1

1 F 8.0 1 F 9.5

1 1 8.5 1 1 9.9

Table 4. DisplayPort™ EQ Settings

All DisplayPort Lanes

DPEQ1 Pin Level DPEQ0 Pin Level EQ Gain at 5 GHz (dB)

0 0 –0.3

0 R 1.6

0 F 3.0

0 1 4.4

R 0 5.4

R R 6.5

R F 7.3

R 1 8.1

F 0 8.9

F R 9.5

F F 10.0

F 1 10.6

1 0 11.0

1 R 11.4

1 F 11.8

1 1 12.1

3.3 Power

The EVM is designed to operate off of the VBUS from a USB host connected through USB Type-C (P2). A

5-V external power is applied through J8 only if stand-alone operation is desired.

If testing DisplayPort only, or if bypassing VBUS power, the EVM must be powered through J8 (a 5-V, 1-A

input).
