Tews Technologies TA900 Manuel utilisateur

The Embedded I/O Compan

TA900

Program and Debug Box

Version 1.0

User Manual

Issue 1.0.1

July 2012

TEWS TECHNOLOGIES GmbH

Am Bahnhof 7 25469 Halstenbek, Germany

Phone: +49 (0) 4101 4058 0 Fax: +49 (0) 4101 4058 19

e-mail: [email protected] www.tews.com

TA900 User Manual Issue 1.0.1 Page 2 of 12

TA900-10R

Program and Debug Box, USB and JTAG

Connectors, extended temperature range

(RoHS compliant)

This document contains information, which is

proprietary to TEWS TECHNOLOGIES GmbH. Any

reproduction without written permission is forbidden.

TEWS TECHNOLOGIES GmbH has made any

effort to ensure that this manual is accurate and

complete. However TEWS TECHNOLOGIES GmbH

reserves the right to change the product described

in this document at any time without notice.

TEWS TECHNOLOGIES GmbH is not liable for any

damage arising out of the application or use of the

device described herein.

Style Conventions

Hexadecimal characters are specified with prefix 0x,

i.e. 0x029E (that means hexadecimal value 029E).

For signals on hardware products, an ‚Active Low’ is

represented by the signal name with # following, i.e.

IP_RESET#.

Access terms are described as:

W Write Only

R Read Only

R/W Read/Write

R/C Read/Clear

R/S Read/Set

¤2011-2012 by TEWS TECHNOLOGIES GmbH

All trademarks mentioned are property of their respective owners.

TA900 User Manual Issue 1.0.1 Page 3 of 12

Issue Description Date

1.0.0 Initial issue June 2011

1.0.1 General revision July 2012

TA900 User Manual Issue 1.0.1 Page 4 of 12

Table of Contents

1 PRODUCT DESCRIPTION ........................................................................................... 6

2 TECHNICAL SPECIFICATION ..................................................................................... 7

3 CONFIGURATION ........................................................................................................ 8

3.1 JTAG Configuration........................................................................................................................8

3.2 LED Configuration ..........................................................................................................................9

4 DRIVERS.......................................................................................................................9

5 PIN ASSIGNMENT – I/O CONNECTOR ..................................................................... 10

5.1 Front I/O .........................................................................................................................................10

5.1.1 USB B-type Receptacle ..........................................................................................................10

5.1.1.1 Pin Assignment..................................................................................................................10

5.1.2 JTAG Header ..........................................................................................................................11

5.1.2.1 Pin Assignment..................................................................................................................11

5.2 FPC Connector ..............................................................................................................................12

5.2.1 Pin Assignment .......................................................................................................................12

TA900 User Manual Issue 1.0.1 Page 5 of 12

List of Figures

FIGURE 1-1 : BLOCK DIAGRAM......................................................................................................................6

FIGURE 5-1 : TA900 FRONT I/O....................................................................................................................10

FIGURE 5-2 : USB B-TYPE RECEPTACLE VIEW.........................................................................................10

FIGURE 5-3 : JTAG HEADER VIEW ..............................................................................................................11

FIGURE 5-4 : FPC CONNECTOR VIEW ........................................................................................................12

List of Tables

TABLE 2-1 : TECHNICAL SPECIFICATION.....................................................................................................7

TABLE 5-1 : USB B-TYPE RECEPTACLE DETAILS .....................................................................................10

TABLE 5-2 : PIN ASSIGNMENT USB B-TYPE RECEPTACLE .....................................................................10

TABLE 5-3 : JTAG HEADER DETAILS...........................................................................................................11

TABLE 5-4 : PIN ASSIGNMENT JTAG HEADER...........................................................................................11

TABLE 5-5 : FPC CONNECTOR DETAILS ....................................................................................................12

TABLE 5-6 : PIN ASSIGNMENT FPC CONNECTOR ....................................................................................12

TA900 User Manual Issue 1.0.1 Page 6 of 12

1 Product Description

The TA900 is an Interface Box which can be used to program and debug hardware modules providing a

corresponding connector.

The Interface Box connects to compatible modules via a 20-pin Flexible Printed Circuit (FPC) Connector

which can provide access to the module's JTAG Chain and the additional interfaces A and B. The TA900 can

be accessed by USB 2.0 and by a 14-pin JTAG Header, and is equipped with a Pushbutton Switch which is

offering the possibility to send an impulse to one of the connected module's I/O pins. A green LED indicates

the assertion of this impulse by interrupting illumination.

In case of the user programmable FPGA boards TAMC631 and TAMC640/641, Interface A provides access

to the UART of the onboard Module Management Controller (MMC), and Interface B connects to two user

pins of the module's onboard FPGA. If a UART core is implemented in the module's FPGA, serial

communication via Interface B is possible. By setting DIP Switches, the provided yellow LEDs located in the

TA900 front panel can either indicate the logic level of the Interface's lines or can be configured to visualize

serial communication on the Rx and Tx lines, if they are connected to the UART interfaces of the USB

Controller. Level Shifters can handle I/O voltages between 1.2V and 3.3V at the FPC Connector which offers

a wide range of possible configurations for Interface A, B and the JTAG Chain of the connected hardware

module.

The JTAG Chain of the connected hardware module which is useful to program and debug onboard devices

can be accessed in two different ways: If it is accessed via the 14-pin Header, which must be the case when

communicating with Xilinx Devices, a "Xilinx Platform Cable USB II" (which is required) can be connected

without any adaption. If the JTAG Chain is accessed via the USB interface, Channel A of the USB Controller

is not used to communicate with Interface A, but to generate JTAG signals for debugging or programming

reasons. In this configuration, Lattice Devices for example can directly be programmed without the necessity

of an additional Programming Cable, as the TA900 is directly supported by Lattice's Software Tool "ispVM".

The TA900 is self-powered by the FPC Connector which means that it is not necessary to connect the

Interface Box to USB to provide a supply voltage. The Interface Box meets the requirements to operate in

extended temperature range from -30° to +75°C and comes with a USB A to USB B Cable and an FPC

Flexcable.

Figure 1-1 : Block Diagram

TA900 User Manual Issue 1.0.1 Page 7 of 12

2 Technical Specification

FPC Connector Interface

Mechanical Interface 20-pin Flexible Printed Circuit (FPC) Connector

(Tyco 2-84953-0 or compatible)

Electrical Interface JTAG Interface

Interface A

Interface B

User I/O pin BUTTON

I/O Voltages 1.2V to 3.3V

On Board Devices

USB to UART/JTAG Controller FT2232H (FTDI Chip)

USB Interface

Mechanical Interface USB B Receptacle

(Kycon KUSBX-BS1N-W or compatible)

Electrical Interface USB 2.0 High Speed (480Mb/s) and Full Speed (12Mb/s)

(Self-Powered)

0x0403

Vendor ID

Product ID 0x6010

Interface A UART / MPSSE Mode JTAG

Supported by "Lattice ispVM"

Interface B UART

JTAG Header Interface

Mechanical Interface 14-pin Shrouded Header

(Molex 87833-1420 or compatible)

Electrical Interface VREF, GND, TCK, TMS, TDI, TDO

Matches the "Xilinx Platform Cable USB II" pinout

Physical Data

Power Requirements 120mA maximum @ +3.3V DC

Temperature Range Operating

Storage

-30°C to +75°C

MTBF 639000 h

MTBF values shown are based on calculation according to MIL-HDBK-217F and

MIL-HDBK-217F Notice 2; Environment: GB 20°C.

The MTBF calculation is based on component FIT rates provided by the

component suppliers. If FIT rates are not available, MIL-HDBK-217F and

MIL-HDBK-217F Notice 2 formulas are used for FIT rate calculation.

5 – 95 % non-condensing

Humidity

132 g

Weight

139.7mm x 82.6mm x 26.2mm

Size

Table 2-1 : Technical Specification

TA900 User Manual Issue 1.0.1 Page 8 of 12

3 Configuration

To modify the LED Configuration and the JTAG Configuration remove the PCB Compartment

Door and set the DIP Switches and the Rotary Selector Switch accordingly.

3.1 JTAG Configuration

The JTAG Chain of the connected hardware module which is useful to program and debug onboard devices

can be accessed in two different ways:

If it is accessed via the 14-pin Header, which must be the case when communicating with Xilinx Devices, a

"Xilinx Platform Cable USB II" (which is required) can be connected without any adaption.

If the JTAG Chain is accessed via the USB interface, Channel A of the USB Controller is not used to

communicate with Interface A, but to generate JTAG signals for debugging or programming reasons. In this

configuration, Lattice Devices for example can directly be programmed without the necessity of an additional

Programming Cable, as the TA900 is directly supported by Lattice's Software Tool "ispVM".

Whether the JTAG Chain of the module connected to the FPC Connector is accessed by the JTAG Header

or by USB is determined by the configuration of the Rotary Selector Switch:

Position Function

0 The JTAG Chain can be accessed via JTAG Header

1 The JTAG Chain can be accessed via JTAG Header [default]

Software Controlled:

o Outputting HIGH level at GPIOH7 Pin when Interface A is configured to

MPSSE-Mode enables JTAG over USB.

o Outputting LOW level enables JTAG over JTAG Header

The JTAG Chain can be accessed via USB-Controller if Interface A is configured to

MPSSE-Mode

TA900 User Manual Issue 1.0.1 Page 9 of 12

3.2 LED Configuration

The yellow LEDs for Interface A and Interface B in the TA900 Front Panel can be configured to operate in

two different ways by setting DIP Switches:

o Set to Logic, the LEDs indicate the logic level of the corresponding interface pins.

o Set to UART, they indicate UART traffic on the Rx Line and Tx Line of the corresponding interface. [default]

4 Drivers

FTDI provides Virtual COM Port (VCP) drivers which cause the USB device to appear as two additional COM

ports available on the PC. These COM ports can be accessed like standard COM ports by the operating

system. The following operating systems are supported:

x Windows 2000, Windows XP, Windows Server 2003, Windows Vista, Windows Server 2008,

Windows 7, Windows Server 2008 R2 (32-bit and 64-bit)

x Linux (32-bit and 64-bit)

x Mac OS X (32-bit, 64-bit and PPC)

x Windows CE 4.2-5.2 (32-bit, ARM, MIPSII, MIPSIV, SH4)

x Windows CE 6.0 (32-bit, ARM, MIPSII, MIPSIV, SH4)

Additionally, FTDI provides D2XX drivers which allow direct access to the USB device through a DLL. This

offers the user to design application software which can access the USB device through a series of DLL

function calls. The project FTCJTAG DLL can be downloaded at the FTDI homepage to handle all Multi-

Protocol Synchronous Serial Engine (MPSSE) commands necessary to create a USB to JTAG interface. The

following operating systems are supported:

x Windows 2000, Windows XP, Windows Server 2003, Windows Vista, Windows Server 2008,

Windows 7, Windows Server 2008 R2 (32-bit and 64-bit)

x Linux (32-bit and 64-bit)

x Mac OS X (32-bit, 64-bit and PPC)

x Windows CE 4.2-5.2 (32-bit, ARM, MIPSII, MIPSIV, SH4)

x Windows CE 6.0 (32-bit, ARM, MIPSII, MIPSIV, SH4)

TA900 User Manual Issue 1.0.1 Page 10 of 12

5 Pin Assignment – I/O Connector

5.1 Front I/O

The following figure shows the Front I/O Interface of the TA900.

Figure 5-1 : TA900 Front I/O

5.1.1 USB B-type Receptacle

Pin-Count

USB B-type Receptacle

Connector Type

Kycon KUSBX-BS1N-W or compatible

Source & Order Info

Table 5-1 : USB B-type Receptacle details

Figure 5-2 : USB B-type Receptacle view

The TA900 comes with a USB A to USB B Cable

(Reichelt AK 672/2-3,0 or compatible)

5.1.1.1 Pin Assignment

Pin Signal Description Driven by

1 VBUS +5V PC

2 D- Data - PC, TA900

3 D+ Data + PC, TA900

4 GND Ground

Table 5-2 : Pin Assignment USB B-type Receptacle

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Tews Technologies Matériel informatique

Tews Technologies

Tews Technologies TPMC463 Manuel utilisateur

Tews Technologies

Tews Technologies TPCE261-10R Manuel utilisateur

Tews Technologies

Tews Technologies TPMC551-SW-95 Manuel utilisateur

Tews Technologies

Tews Technologies TVME201 Manuel utilisateur

Tews Technologies

Tews Technologies TCP270 Manuel utilisateur

Tews Technologies

Tews Technologies TXMC638 Manuel utilisateur

Tews Technologies

Tews Technologies TAMC020-TM Manuel utilisateur

Tews Technologies

Tews Technologies TPMC321 Manuel utilisateur

Tews Technologies

Tews Technologies TIP815-SW-12 Manuel utilisateur

Tews Technologies

Tews Technologies TMPE633 Manuel utilisateur

Tews Technologies

Tews Technologies TDRV003-SW-65 Manuel utilisateur

Tews Technologies

Tews Technologies TMPE627 Manuel utilisateur

Tews Technologies

Tews Technologies TAMC261 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
