Instruction manual

testo 810

99 Washington Street

Melrose, MA 02176

Phone 781-665-1400

Toll Free 1-800-517-8431

Visit us at www.TestEquipmentDepot.com

Short manual testo 810 13

Short manual testo 810

Protection cap: Park position

Infrared sensor

Air/temperature sensor

Display

Control keys

Battery compartment (on rear)

Basic ssettings

Instrument off >press and hold 2s > select with ( ),

confirm with ( ):

Unit of temperature: °C,°F > Differential temperature ∆t:OFF,ON >

Emissonsfaktor: ε > Auto off-Funktion: OFF,ON

Switching tthe iinstrument oon

Press .

Switching tthe ddisplay llight oon((for 110s)

Instrument on > press .

IR mmeasurements

Press and hold .

Select ddisplay mmode

Instrument on > select with :

Hold: Readings are held > Max: Maximum values > Min: Minimum values

Switching tthe iinstrument ooff:

Instrument on >press and hold 2s.

de

enfresitptsvnl????

Safety and the enviroment14

Safety and the environment

About this document

iPlease read this documentation through carefully and

familiarise yourself with the product before putting it to use.

Keep this document to hand so that you can refer to it when

necessary. Hand this documentation on to any subsequent

users of the product.

iPay particular attention to information emphasised by the

following symbols:

Important.

Avoid personal injury/damage to equipment

iOnly operate the measuring instrument properly, for its

intended purpose and within the parameters specified in the

technical data. Do not use force.

iNever store the product together with solvents, acids or other

aggressive substances.

iOnly carry out the maintenance and repair work that is

described in the documentation. Follow the prescribed steps

when doing so. Use only OEM spare parts from Testo.

Protecting the environment

iTake faulty rechargeable batteries as well as spent batteries to

the collection points provided for them.

iSend the product back to Testo at the end of its useful life. We

will ensure that it is disposed of in an environmentally friendly

manner.

Specifications 15

Specifications

Functions and use

The testo 810 is an infrared measuring instrument. It is normally

used to measure surface temperature, e.g. on heaters and

radiators, and to measure the ambient temperature at the same

time.

Technical data

Measurement data

· Sensors:

Infrared sensor,

NTC temperature sensor

· Parameters:

°C, °F

· Measuring ranges:

IR: -30...300 °C, -20...575 °F,

Air probe: -10...50 °C, 14...122 °F

· Resolutions:

0.1 °C, 0.1 °F,

· Accuracies

(Nenntemperatur 22 °C, ±1 Digit):

Infrared: ±2 °C (-30...+100 °C),

±3.6 °F (-22...212 °C),

±2 % of reading (rest of range)

Air probe: ±0.5 °C, ±0.9 °F

· Measuring rate:

0.5 s

· Optics:

6 : 1

Further instrument data

· Protection class: IP40

· Ambient conditions:

-10...50 °C, 14...122 °F

· Storage/transport conditions:

-40...70 °C, -40...158 °F

· Voltage supply:

2x 1.5 V type AAA

· Battery life:

50 h (without display light)

· Dimensions:

119x46x25 mm (inc. protection cap)

· Weight: 90 g (inc. batteries and

protection cap)

Directives, standards and tests

· EC Directive: 89/336/EEC

Warranty

· Duration: 2 years

· Warranty conditions: see guarantee

card

de

enfresitptsvnl????

Test Equipment Depot - 800.517.8431

99 Washington Street,Melrose, MA 02176

TestEquipmentDepot.com

Product description16

Product description

At a glance

Protection cap: Park position

Infrared sensor

Air/temperature sensor

Display

Control keys

Battery compartment (on rear)

First steps

²Inserting bbatteries:

1To open the battery compartment, push the battery cover

down.

2Insert batteries (2x 1.5 V type AAA). Observe the polarity!

3To close the battery compartment, push the battery cover

back on.

²Basic ssettings ((configuration mmode):

Adjustable functions

· Unit of temperature: °C,°F

· Differential temperature ∆t:OFF,ON

· Emission factor: ε

· Auto off function: OFF,ON (instrument switches off automatically if no key is

pressed for 10 minutes)

The emission factor has a default setting of 0.95. This is

ideal for the measurement of non-metals (paper, ceramic,

gypsum, wood, paints and varnishes), plastics and

foodstuffs.

Product description 17

Because of their low or non-uniform emission factor, bright

metals and metal oxides are of only limited use for infrared

measurement. Coatings that increase the emission factor,

e.g. paint or emission adhesive (0554 0051) must be

applied to the object being measured.

Emission factors of various materials (typical values):

Material (temperature) ε

Aluminium, bright rolled (170 °C) 0.04

Cotton (20 °C) 0.77

Concrete (25 °C) 0.93

Ice, smooth (0 °C) 0.97

Iron, emery ground (20 °C) 0.24

Iron with casting skin (100 °C) 0.80

Iron with rolling skin (20 °C) 0.77

Gypsum (20 °C) 0.90

Glass (90 °C) 0.94

Rubber, hard (23 °C) 0.94

Rubber, soft grey (23 °C) 0.89

Wood (70 °C) 0.94

Cork (20 °C) 0.70

Radiator, black anodised (50 °C) 0.98

Copper, slightly tarnished (20 °C) 0.04

Copper, oxidised (130 °C) 0.76

Plastics: PE, PP, PVC (20 °C) 0.94

Brass, oxidised (200 °C) 0.61

Paper (20 °C) 0.97

Porcelain (20 °C) 0.92

Black paint, matt (80 °C) 0.97

Steel, heat-treated surface (200 °C) 0.52

Steel, oxidised (200 °C) 0.79

Clay, burnt (70 °C) 0.91

Transformer paint (70 °C) 0.94

Brick, mortar, plaster (20 °C) 0.93

1When switching the instrument on, press and hold until

and appear on the display (configuration mode).

- The adjustable function is displayed. The current setting

flashes.

2Press ( ) several times until the desired setting flashes.

3Press ( ) to confirm the input.

4Repeat steps 2and 3for all functions.

- The instrument changes to measuring mode.

de

enfresitptsvnl????

Using the product18

Using the product

²Switching tthe iinstrument oon:

iPress .

- Measuring mode is opened.

²Switching tthe ddisplay llight oon:

The instrument is switched on.

iPress .

- The display light goes out automatically if no key is

pressed for 10 seconds.

²IR mmeasurements:

Laser radiation! Do not look into the laser beam.

Laser class 2.

To ensure correct readings:

· Keep temperature and humidity sources which may falsify the

measurement (e.g. hands) away from the sensor.

· Keep the lens clean and do not measure with foggy lenses.

· Keep the measuring range (the range between the instrument and the

object being measured) and the surface of the object free of obstacles.

There must be no particles of dust or dirt, no humidity (rain, steam) and

no gases.

· If the ambient temperature changes (change of location, e.g.

measurement indoors/outdoors), the instrument must be allowed to

equalise for aprox. 15 minutes.

· The instrument has a lens (90 % value) of 6:1 (distance : measuring

surface) + Opening diameter of the sensor (10mm / 0.39 in):

Distance Diameter of meas. surface Distance Diameter of meas. surface

10cm 3cm 4in 1.06in

60cm 11cm 25in 4.56in

100cm 18cm 40in 7.06in

200cm 35cm 80in 13.72in

iPress and hold .

- flashes in the display. The laser dot marks the centre

of the measuring surface.

-

When IR measurement has been completed (release ),

the instrument changes to the Hold display view and

the

readings are held.

Using the product 19

²Changing tthe ddisplay vview:

Adjustable views

·Hold: Readings are held.

·Max: Maximum values since the instrument was last switched on or last reset.

·Min: Minimum values since the instrument was last switched on or last reset.

iPress several times until the desired view appears.

²Resetting MMax/Min vvalues:

1Press several times until the desired view appears.

2Press and hold until ---- appears.

3Repeat steps 1and 2for all values that are to be reset.

²Switching tthe iinstrument ooff:

iPress and hold until the display goes out.

de

enfresitptsvnl????

Maintaining the product20

Maintaining the product

±Changing bbatteries:

1To open the battery compartment, push the battery cover

down.

2Remove used batteries and insert new batteries

(2x 1.5 V type AAA). Observe the polarity!

3To close the battery compartment, push the battery cover

back on.

±Cleaning tthe hhousing:

iClean the housing with a moist cloth (soap suds) if it is dirty.

Do not use aggressive cleaning agents or solvents!

Tips and assistance 21

Tips and assistance

Questions and answers

Question Possible causes/solutions

Hi or Lo · Readings outside the measuring range (too high, too

low): Keep to the permitted measuring range.

· Residual capacity <10 min: Change batteries.
