Instruction Manual
testo 206
pH/Temperature Measuring Instrument
99 Washington Street
Melrose, MA 02176
Phone 781-665-1400
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com
General Information
2
General Information
Please read this document through carefully and familiarise
yourself with the operation of the product before putting it to use.
Keep this documentation to hand so that you can refer to it when
necessary.
Symbols and what they mean
Symbol Meaning Remarks
Warning text: Warning! Please read warning
Serious physical injuries could occur carefully and take the
if the precautionary measures precautionary measures
specified are not taken. specified.
Warning text: Caution! Please read warning
Light physical injuries could occur carefully and take the
if the precautionary measures precautionary measures
specified are not taken. specified.
Note Pay particular attention
to Notes.
Button name Press button.
Text, Display content Text or symbol is shown
on the display.
Button
Contents 3
Contents
General Information ..........................................................2
Contents ..........................................................................3
1. Safety Information ............................................................4
2. Intended Purpose ............................................................5
3. Product Description ..........................................................6
3.1 Display and control elements ..............................................................6
3.2 Probe/BNC modules ..........................................................................6
3.3 Power..................................................................................................7
3.4 TopSafe ..............................................................................................7
3.5 Storage cap ........................................................................................7
3.5 Wall/Transport bracket ........................................................................7
4. Initial Operation ................................................................8
4.1 Insert battery ......................................................................................8
4.2 Connect external probe (BNC module pH3 only) ................................8
5. Operation ........................................................................8
5.1 Switching on/off ..................................................................................8
5.2 Setting instrument ..............................................................................8
5.3 Measuring ........................................................................................10
5.4 Calibrating instrument........................................................................11
6. Service and Maintenance................................................12
6.1 Checking electrolyte gel ....................................................................12
6.2 Cleaning housing/TopSafe ................................................................12
6.3 Changing the module ........................................................................13
6.4 Changing battery ..............................................................................13
7. Questions and Answers..................................................14
8. Technical data ................................................................15
9. Accessories and Spare Parts..........................................15
en
1. Safety Information
4
1. Safety Information
Avoid electrical hazards:
Do not measure on or near live parts!
Preserving product safety/warranty claims:
Operate the instrument properly and according to its intended
purpose and within the parameters specified. Do not use
force.
Do not store together with solvents (e.g. acetone).
Temperature data on probes/sensors refer only to the
measurement area of the sensors. Do not expose handles and
cables to temperatures greater than 70°C if they are not
specifically designed for higher temperatures.
Open the instrument only when this is expressly described in
the documentation for maintenance purposes.
Only the maintenance and service work described in the
documentation should be carried out. Please adhere to the
steps specified. For safety reasons, only original spare parts
from Testo should be used.
Ensure correct disposal:
Disposal of defective rechargeable batteries and spent
batteries at the collection points provided.
Send the instrument directly to us at the end of its life cycle.
We will ensure that it is disposed of in an environmentally
friendly manner.
2. Intended Purpose 5
2. Intended Purpose
testo 206 is a practical instrument for spot check measurements
of pH value and temperature.
It has different applications depending on the probe/BNC module
used.
testo 206 with pH1 immersion probe
Measurement of liquid substances in the following sectors:
· Food companies (e.g. fruit juices)
· Industry (e.g. refrigerant, electroplating, chip production, paints
and varnish, print products)
· Chemistry (e.g. cleaning agents)
· Environmental protection (e.g. drinking water/waste water)
· Swimming pools, aquaria
· Agriculture
· Fish farming
· Pharmaceuticals and biotechnology
testo 206 with pH2 penetration probe
Measurement of semi-solid substances in food production and
processing: e.g. marmelades, marzipan, pastes, ready-to-serve
salad, gelling agents, fruit, milk products, bakery and
confectionery products. Laboratory measurements in companies
involved in the processing of food.
testo 206 with pH3 BNC module
The BNC socket is used to connect external pH probes. Ranges
of application depend on the probe attached.
testo 2206 iisnnot ssuitable ffor ddiagnostic mmeasurements iintthe
medical ssector.
en
Test Equipment Depot - 800.517.8431
99 Washington Street,Melrose, MA 02176
TestEquipmentDepot.com
3. Product Description
3.1 Display and control elements
3.2 Probe/BNC modules
MMOODDEE::
Changes function,
calls up “manual temperature
compensation” (pH3 BNC-
module only with non-
temperature compensated
probe)
OONN//HHOOLLDD::
On/Off switch,
holds readings
BBaatttteerryy
ccoommppaarrttmmeenntt
(rear side) CCAALL::Calls up “calibration”
mode
DDiissppllaayy
BBNNCCmmoodduullee((ppHH33))
PPeenneettrraattiioonnpprroobbee((ppHH22))
IImmmmeerrssiioonnpprroobbee((ppHH11))
3. Product Description
6
3. Product Description 7
3.3 Power
Power is via a button cell (Typ CR2032, 3V; included with
delivery).
3.4 TopSafe
TopSafe protects the instrument from
moisture and mechanical strain (impact).
We recommend you always use TopSafe.
The IP68 protection class is achieved if
the instrument is placed inside the
TopSafe and is closed.
3.5 Storage cap
The storage cap filled with electrolyte gel is
used to store the probe between
measurements.
The probe is only immediately ready to
operate if stored in electrolyte gel.
If the probe has been out of the electrolyte gel for a longer period
of time, it must be stored in the electrolyte gel for approx. 12
hours to regenerate.
The storage cap can also be attached to the wall/transport
bracket.
3.5 Wall/Transport bracket
The wall/transport bracket with belt holder
and attachment unit for the storage cap is
used for the safe storage of the
measurement instrument at a fixed point or
during transport.
en
4. Initial Operation
8
4. Initial Operation
4.1 Insert battery
1Open the TopSafe sealing cap and remove instrument.
2Open battery compartment on rear of instrument.
3Insert button cell (Type CR2032, 3V). The (+) sign must be
visible.
4Close battery compartment.
5Remove protection strip on the storage cap.
4.2 Connect external probe(BNC module pH3 only)
Attach BNC plug from the external probe to the BNC socket
and seal with the aid of a bayonet coupling.
5. Operation
5.1 Switching on/off
Switch on instrument: .
- All segments light up briefly and the instrument changes to the
measurement mode.
Switch off instrument: Keep pressed.
5.2 Setting instrument
The following functions can be set:
Function Description Setting options
Temperature unit Sets unit °C or °F
Auto Hold (AUTO HOLD) Automatically holds reading, On (switched on) or
as soon as it is stable* OFF (switched off)
Gradient/ Offset Displays gradient and offset None
values stored in the instrument (Information only)
(amount)
Calibration method (CAL) Sets 1, 2 or 3 point 1P,2P or 3P
calibration
Calibration points (CAL pH) Sets calibration points 1P: 4,7or 10
2P: 47or 710
ON/HOLD
ON/HOLD
5. Operation 9
Function Description Setting options
Auto Off (AUTO OFF) Instrument switches off On (switched on) or
automatically after 10 minutes OFF (switched off)
if no button has been pressed
Beeper (bP) Warning sound (button pressed, On (switched on) or
stable reading reached with OFF (switched off)
Auto Hold function switched on)
* Modification less than 0.02pH in 20s
The setting procedure can be interrupted by switching off the
instrument. The modifications are then not saved.
The instrument is switched off.
1Opening the setting mode: is kept pressed + .
2Select temperature unit (°C or °F): .
Confirm selection: .
3Switch Hold on (On) or off (OFF): .
Confirm selection: .
- The gradient and offset values stored in the instrument are
displayed as information.
4Change view: .
5Select calibration method (1P, 2P or 3P): .
Confirm selection: .
If 1 or 2 point calibration has been set:
Select calibration points (4, 7or 10, and 477or 7110): .
Confirm selection: .
6Switch Auto Off on (On) or off (OFF): .
Confirm selection: .
7Switch beeper on (On) or off (OFF): .
Confirm selection and save settings: .
- All of the segments light up briefly and the instrument changes
to the measurement mode.
MODE
CAL
MODE
CAL
MODE
CAL
MODE
CAL
MODE
MODE
CAL
MODE
CAL
ON/HOLDMODE
en
5. Operation
10
5.3 Measuring
Setting up the instrument
If large quantities of the electrolyte gel are stuck to the probe
when removed from the storage cap, it is a sign that the gel is
spent.
A new storage cap is needed.
Clean off the pH probe before and after each measurement
with low concentration soap water followed by tap water
(water temperature should be below 40°C). Dab dry with a
paper towel. Do not rub.
When using the BNC module, please note the application
information included with the external probe.
1Carefully remove storage cap.
2Switch on instrument: .
Carry out measurement
Measurement tip made of glass, risk of breakage!
Risk of injury on account of glass parts which remain in the
measurement medium.
Check measurement tip of pH probe after each
measurement for damage.
Immerse/penetrate probe in the medium to be measured.
- The measured pH and temperature values are displayed. The
readings are updated twice a second.
Hold readings manually: .
Restart measurement: .
- If Auto-Hold is switched on, AUTO HOLD flashes until the
instrument has found a stable pH reading. The readings are
then frozen (AUTO HOLD lights up). If no stable pH readings
have been found within 300s, the measurement is stopped
( and AUTO HOLD light up).
Restart measurement: .
ON/HOLD
ON/HOLD
ON/HOLD
ON/HOLD
Autres manuels pour 206
2
Table des matières
Autres manuels TESTO Instrument de mesure
TESTO
TESTO 320 Manuel utilisateur
TESTO
TESTO 325-3 Manuel utilisateur
TESTO
TESTO Smart Probes 805i Manuel d'installation
TESTO
TESTO 112 Manuel utilisateur
TESTO
TESTO 416 Manuel utilisateur
TESTO
TESTO 511 Manuel utilisateur
TESTO
TESTO 350 Maritime V2 Manuel utilisateur
TESTO
TESTO 816-1 Manuel utilisateur
TESTO
TESTO 425 Manuel utilisateur
TESTO
TESTO Smart Probes 905i Manuel utilisateur
TESTO
TESTO 320 Manuel utilisateur
TESTO
TESTO 350 M/XL Manuel utilisateur
TESTO
TESTO 511 Manuel utilisateur
TESTO
TESTO 300 XXL Manuel utilisateur
TESTO
TESTO 605-H1 Manuel utilisateur
TESTO
TESTO 616 Manuel utilisateur
TESTO
TESTO Smart Probes 510i Manuel utilisateur
TESTO
TESTO 410-2 Manuel utilisateur
TESTO
TESTO 557 Manuel utilisateur
TESTO
TESTO 435 Manuel utilisateur
Manuels Instrument de mesure populaires d'autres marques
Endress+Hauser
Endress+Hauser Proline Promag 50 Caractéristiques techniques
Siemens
Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces
KLINGER
KLINGER CMF V Series Manuel utilisateur
EXFO
EXFO FTB-2 Manuel d'exploitation et d'entretien
Keysight
Keysight M8290A Manuel utilisateur
ADTEK
ADTEK MW-5 Manuel utilisateur
