1. Introduction

1.1. Scope

Scope of this document is to give an overview of the fonts, styles and general structure -- first

chapter included -- to use when writing Telit documents. The aim of this document is to

present the features and the application of the LE50-868 radio module. After the introduction,

the characteristics of the LE50-868 radio module will be described within the following

distinct chapters:

Requirements

General Characteristics

Technical description

Process information

Board Mounting Recommendations

Antenna Considerations

1.2. Audience

This document is intended for developers using Telit LE50-868 Module..

1.3. Contact Information, Support

For general contact, technical support, to report documentation errors and to order manuals,

contact Telit Technical Support Center (TTSC) at:

[email protected]

Alternatively, use:

http://www.telit.com/en/products/technical-support-center/contact.php

For detailed information about where you can buy the Telit modules or for recommendations

on accessories and components visit:

http://www.telit.com

LE50-868 RF Module User Guide

1VV0300905 rev.1 – 2011-05-18

To register for product news and announcements or for product questions contact Telit

Technical Support Center (TTSC).

Our aim is to make this guide as helpful as possible. Keep us informed of your comments and

suggestions for improvements.

Telit appreciates feedback from the users of our information.

1.4. Document Organization

This document contains the following chapters

“Chapter 1: “Introduction” provides a scope for this document, target audience, contact and

support information, and text conventions.

“Chapter 2: “General Requirement” gives an overview of the limitations imposed by

Reference standards.

“Chapter 3: “General Characteristics” describes in details the characteristics of the product.

“Chapter 4: “Technical Description” describes in details the signals and pin-out of the

product.

“Chapter 5: “Process information” describes in details the delivery, storage, soldering and

placement of the product.

“Chapter 6: “Board Mounting Recommendations” describes in details the interface and

coupling of the product.

“Chapter 7: “Annexes” describe examples of propagation attenuation.

“Chapter 8: “Safety Recommendations” describes recommendation for proper usage.

“Chapter 39: “Document history” describes the revision history of the product.

1.5. Text Conventions

Danger – This information MUST be followed or catastrophic equipment failure or bodily

injury may occur.

Caution or Warning – Alerts the user to important points about integrating the module, if

these points are not followed, the module and end user equipment may fail or malfunction.

Tip or Information – Provides advice and suggestions that may be useful when

integrating the module.

All dates are in ISO 8601 format, i.e. YYYY-MM-DD.

LE50-868 RF Module User Guide

1VV0300905 rev.1 – 2011-05-18

1.6. Related Documents

[1] EN 300 220-2 v2.3.1, ETSI Standards for SRD , February 2010

[2] ERC Rec 70-03, ERC Recommendation for SRD, June 2010

[3] 2002/95/EC, Directive of the European Parliament and of the Council, 27 January 2003

[4] Tools : User Manual, 1VV300873 Short Range Tool User Guide

[5] Star Network User Guide, 1vv0300899 M-ONE Protocol Stack User Guide

[6] 2006/771/EC, Harmonization of the radio spectrum for use by short-range devices

[7] 2009/381/EC, Amending Decision 2006/771/EC on harmonization of the radio

spectrum for use by short-range devices

LE50-868 RF Module User Guide

1VV0300905 rev.1 – 2011-05-18

2. Requirements

2.1. General Requirements

The LE50-868 module is a multi-band radio board, delivering up to 25 mW in the 868 MHz

ISM band (unlicensed frequency band). It is dedicated to low power applications that require

mesh network structure.

LE50-868 is also pin-to-pin compatible with Telit ZE Family (ZigBee 2007 and PRO stack),

ME Family (Wireless M-bus) and LE Family (basic point to point, broadcast stack).

The “ERC recommendation 70-03” describes the different usable sub-bands in the 868 MHz

license free band, in terms of bandwidth, maximum power, duty cycle and channel spacing. It

gives the following limitations:

ERC recommendation 70-03

Band Frequency band

(MHz) Maximum radiated

power (mW) Channel spacing

(kHz) Duty cycle

(%)

Annex1 g 863.0 – 870.0 25 =< 100 for 47 or more channels 100

Annex1 g1 868.0 – 868.6 25 No channel spacing specified 1

Annex7 a 868.6 - 868.7 10 25 1

Annex1 g2 868.7 - 869.2 25 No channel spacing specified 0,1

Annex7 d 869.2 – 869.25 10 25 0.1

Annex7 b 869.25 – 869.3 10 25 0.1

Annex7 e 869.3 – 869.4 10 25 1

Annex1 g3 869.4 - 869.65 500 25 (for 1 or more channels) 10

Annex7 c 869.65 – 869.7 25 25 10

Annex1 g4 869.7 – 870.0 5 No channel spacing specified 100

These bands are free to use but the module and the user must respect some limitations. Most

of these restrictions are integrated in the conception of the module, except the duty cycle. For

example, the 869.400 to 869.650 MHz band is limited to a 10% duty cycle. This means that

each module is limited to a total transmit time of 6 minutes per hour. It is the responsibility of

the user to respect the duty cycle.

Finally, the module complies with the new European Directive 2002/95/EC concerning the

Restrictive Usage of Hazardous Substances (RoHS).

Autres manuels pour LE50-868

Table des matières

Autres manuels Telit Wireless Solutions Unité de contrôle

Telit Wireless Solutions

Telit Wireless Solutions GE864 Series Caractéristiques techniques

Telit Wireless Solutions

Telit Wireless Solutions GE864 DUAL V2 Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions LM940 Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions GE910 Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions LE940B6-NA AUTO Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions SL869-V3 EVK Fiche technique

Telit Wireless Solutions

Telit Wireless Solutions GL865-DUAL V3 Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions GE864-AUTO Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions GM862GPS Series Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions GC864-QUAD V2 Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions ZE50-2.4 Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions GC864-QUAD-C9 Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions LE910C series Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions GE864-QUAD V2 Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions GE866-QUAD Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions GC864 Series Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions NL865H2 Series Mode d’emploi

Telit Wireless Solutions

Telit Wireless Solutions LE51-868S DemoUnit Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions WE866E4-P Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions BlueMod+S42M Manuel d'utilisation

Telit Wireless Solutions

Telit Wireless Solutions LE51-868S DemoUnit Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions UC864-E Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions FN980m TLB Mode d’emploi

Telit Wireless Solutions

Telit Wireless Solutions HE920-NA Manuel d'installation

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
