CC864-DUAL Hardware User Guide

80pppSTzzzzza Rev. 0.4 - dd/mm/yy

Notice

OEM integrators and installers are instructed that the phrase. This device contains

transmitter FCC ID: RI7CC864-DUAL must be placed on the outside of the host.

Warning: Exposure to Radio Frequency Radiation The radiated output

power of this device is far below the FCC radio frequency exposure

limits. Nevertheless, the device should be used in such a manner that

the potential for human contact during normal operation is minimized.

In order to avoid the possibility of exceeding the FCC radio

frequency exposure limits, human proximity to the antenna should

not be less than 20cm during normal operation. The gain of the

antenna for Cellular band must not exceed-2.0 dBi.

The gain of the antenna for PCS band must not exceed -3.0dBi.

CC864-DUAL Hardware User Guide

80pppSTzzzzza Rev. 0.4 - dd/mm/yy

Disclaimer

The information contained in this document is the proprietary information of Telit

Communications S.p.A. and its affiliates (“TELIT”).

The contents are confidential and any disclosure to persons other than the officers,

employees, agents or subcontractors of the owner or licensee of this document,

without the prior written consent of Telit, is strictly prohibited.

Telit makes every effort to ensure the quality of the information it makes available.

Notwithstanding the foregoing, Telit does not make any warranty as to the

information contained herein, and does not accept any liability for any injury, loss or

damage of any kind incurred by use of or reliance upon the information.

Telit disclaims any and all responsibility for the application of the devices

characterized in this document, and notes that the application of the device must

comply with the safety standards of the applicable country, and where applicable,

with the relevant wiring rules.

Telit reserves the right to make modifications, additions and deletions to this

document due to typographical errors, inaccurate information, or improvements to

programs and/or equipment at any time and without notice.

Such changes will, nevertheless be incorporated into new editions of this document.

Printed in the US

CC864-DUAL Hardware User Guide

80pppSTzzzzza Rev. 0.4 - dd/mm/yy

Contents

1. Introduction...................................................................................................................6

1.1. Scope.......................................................................................................................6

1.2. Audience ..................................................................................................................6

1.3. Contact Information, Support ...................................................................................6

1.4. Product Overview.....................................................................................................6

1.4.1. General Specifications .................................................................................................. 6

1.4.2. Receiver Specifications ................................................................................................. 7

1.4.3. Transmitter Specifications ............................................................................................. 7

1.4.4. gpsOne Receiver Specifications ................................................................................... 7

1.5. Safety Recommendations ........................................................................................7

1.5.1. Local regulations ........................................................................................................... 7

1.5.2. Wiring and Installation ................................................................................................... 8

1.5.3. Electrostatic Discharge.................................................................................................. 8

1.5.4. R-UIM Card ................................................................................................................... 8

1.5.5. Antennas ....................................................................................................................... 8

1.5.6. Disassembly .................................................................................................................. 8

1.6. Document Organization ........................................................................................... 8

1.7. Text Conventions .....................................................................................................9

1.8. Related Documents..................................................................................................9

1.9. Document History.....................................................................................................9

2. Mechanical Specifications.........................................................................................10

2.1. Module Dimensions................................................................................................ 10

2.2. Interface Connector Specifications.........................................................................11

2.3. RF Connector Specifications..................................................................................12

2.4. Mounting ................................................................................................................13

3. Hardware Interface Description.................................................................................14

3.1. Overview ................................................................................................................14

3.2. Functions for Turning On and Off the Module ........................................................15

3.2.1. Turning On the CC864-Dual Module........................................................................... 15

3.2.2. Turning Off the CC864-Dual Module........................................................................... 16

3.2.2.1. Hardware Shutdown............................................................................................. 16

3.2.2.2. Software Shutdown .............................................................................................. 16

3.2.3. Hardware Reset .......................................................................................................... 16

CC864-DUAL Hardware User Guide

80pppSTzzzzza Rev. 0.4 - dd/mm/yy

3.3. Power Supply .........................................................................................................17

3.3.1. +5V Input Source Power Supply Design Guidelines ................................................... 18

3.3.2. +12V Input Source Power Supply Design Guidelines ................................................. 18

3.3.3. Battery Source Power Supply Design Guidelines ....................................................... 19

3.3.4. Battery Charge Control Circuitry Design Guideline ..................................................... 20

3.3.4.1. Trickle Charging ................................................................................................... 21

3.3.4.2. Constant Current Charging .................................................................................. 22

3.3.4.3. Constant Voltage Charging .................................................................................. 22

3.3.4.4. Pulse Charging..................................................................................................... 22

3.3.5. Thermal Design Guidelines ......................................................................................... 23

3.3.6. Power Supply PCB Layout Guidelines ........................................................................ 23

3.4. Antenna Requirements .......................................................................................... 25

3.4.1. Antenna Installation Guideline..................................................................................... 25

3.5. Logic level Specification.........................................................................................25

3.6. UART1 - Serial Interfaces ......................................................................................26

3.6.1. RS232C Interface and Level Translation .................................................................... 27

3.6.2. 5V UART Level Translation......................................................................................... 28

3.7. External R-UIM Interface........................................................................................ 29

3.7.1. R-UIM Design Guidelines............................................................................................ 29

3.8. USB Interface......................................................................................................... 30

3.9. Audio Interface .......................................................................................................30

3.9.1. General Design Rules ................................................................................................. 31

3.9.2. Handset Interface ........................................................................................................ 31

3.9.3. Headset Interface ........................................................................................................ 32

3.9.4. Car Kit Speakerphone Interface .................................................................................. 33

3.10. I2C Bus Interface ................................................................................................35

3.11. ADC/DAC Interface.............................................................................................35

3.11.1. ADC Converter ........................................................................................................ 35

3.11.1.1. Description ........................................................................................................... 35

3.11.1.2. Using ADC Converter........................................................................................... 36

3.11.2. DAC Converter ........................................................................................................ 36

3.11.2.1. Description ........................................................................................................... 36

3.11.2.2. Enabling the DAC................................................................................................. 36

3.11.2.3. Low Pass Filter Example...................................................................................... 37

3.12. General Purpose I/O........................................................................................... 37

3.12.1. Using a GPIO pin as Input ....................................................................................... 38

3.12.2. Using a GPIO pin as Output .................................................................................... 38

3.12.3. TGPIO_03/AUDIO MUTE ........................................................................................ 38

CC864-DUAL Hardware User Guide

80pppSTzzzzza Rev. 0.4 - dd/mm/yy

3.12.4. TGPIO_04/RF Transmission Control....................................................................... 38

3.12.5. TGPIO_05/RFTXMON............................................................................................. 38

3.12.6. TGPIO_06/ALARM .................................................................................................. 39

3.12.7. TGPIO_07/BUZZER ................................................................................................ 39

3.12.8. TGPIO_08/POWER_SAVING ................................................................................. 40

3.12.9. TGPIO_11/VIBRATOR ............................................................................................ 40

3.12.10. TGPIO_12/CALL_KEY ............................................................................................ 40

3.12.11. TGPIO_13/ACTIVE.................................................................................................. 40

3.13. Miscellaneous Interface Signals ......................................................................... 41

3.13.1. VAUX1 ..................................................................................................................... 41

3.13.2. VRTC ....................................................................................................................... 41

3.13.3. STAT_LED............................................................................................................... 42

3.13.4. PWRMON ................................................................................................................ 42

3.13.5. AXE.......................................................................................................................... 42

4. Development and Testing..........................................................................................44

5. Acronyms and Abbreviations....................................................................................45

6. Appendix: Pin Allocation...........................................................................................46

CC864-DUAL Hardware User Guide

80pppSTzzzzza Rev. 0.4 - dd/mm/yy

1. Introduction

1.1. Scope

This document describes hardware solutions you can use to develop a product

containing the Telit CC864-Dual module, as follows:

•Describing the basic functions of the module

•Suggesting a proper hardware solution for each function

•Describing the wrong solutions and most common errors to be avoided

This document is not intended to provide an overall description of all hardware

solutions and all the products that may be designed.

The solutions suggested serve as a guide or starting point for you to be able to

correctly develop a product with the Telit CC864-Dual module.

However, avoiding the wrong solutions and most common errors described here

should be regarded as mandatory.

1.2. Audience

This manual is intended for hardware developers who design products that integrate

the CC864-DUAL module.

1.3. Contact Information, Support

For detailed information about where you can buy the Telit modules or for

recommendations on accessories and components visit http://www.telit.com

To register for product news and announcements or for product questions contact

Telit's Technical Support Center (TTSC).

1.4. Product Overview

The CC864-Dual module is a CDMA-1XRTT wireless module designed to have the

same form, fit and function as its GSM/GPRS counterpart product family, the GC864-

Dual.

This enables integrators and developers to design their applications once and take

advantage of the global coverage and service flexibility allowed by the combination of

the most prevalent cellular technologies worldwide.

With its ultra-compact design and extended operating temperature range, the Telit

CC864-Dual module is the perfect platform for m2m applications, mobile data and

computing devices. It also incorporates gpsOne capability for applications in mobile

environments such as telematics, personal and asset tracking.

1.4.1. General Specifications

Parameter Description

External access Code division multiple access

CC864-DUAL Hardware User Guide

80pppSTzzzzza Rev. 0.4 - dd/mm/yy

CDMA protocol CDMA2000 1x Rel A and Rel B

Data Rate 153.6 Kb/s (full-duplex)

GPS SGPS / standalone

Vocoder EVRC, 13kQCELP, 4GV

Operating temperature -30° ~ +80°

1.4.2. Receiver Specifications

Parameters Descriptions

Frequency range Cellular: 869~894 MHz

PCS: 1930~1990 MHz

Channel number Cellular: 832

PCS: 1200

Sensitivity Better than -104 dBm

Input dynamic range -25dBm ~ -104 dBm

1.4.3. Transmitter Specifications

Parameters Descriptions

Frequency range Cellular: 824~849 MHz

PCS: 1850~1910 MHz

Channel number Cellular: 832

PCS: 1200

Power class Cellular: Class III

PCS: Class II

Power range 0.2 W (23 dBm) ~ 0.63 W (28 dBm)

Nominal power 0.27 W (24.31 dBm)

1.4.4. gpsOne Receiver Specifications

Parameters Descriptions

Frequency range L1, 1575.42 MHz

Receiver sensitivity -151 dBm

1.5. Safety Recommendations

1.5.1. Local regulations

Make sure that the use of this product is allowed in the country and in the

environment required.

The use of this product may be dangerous and thus must be avoided where:

CC864-DUAL Hardware User Guide

80pppSTzzzzza Rev. 0.4 - dd/mm/yy

•It can interface with other electronic devices in environments such as

hospitals, airports, and so on.

•There is risk of explosion such as in the proximity of gasoline, oil refineries,

and so on.

You are responsible to enforce country and specific environment regulations on the

product. For further details refer to Chapter 1.7 for related documents.

1.5.2. Wiring and Installation

Always follow the instructions of this guide when wiring the product.

The product must be supplied with a stabilized voltage source, and the wiring must

conform to security and fire prevention regulations.

The installation of the external components of the module must be handled with care

in order to ensure the proper functioning of the product.

1.5.3. Electrostatic Discharge

The product must be handled with care, avoiding any contact with the pins because

electrostatic discharge can damage the product.

1.5.4. R-UIM Card

The R-UIM card must also be handled with care, always following the instructions for

its use.

Do not insert or remove the R-UIM when the product is in power saving mode.

1.5.5. Antennas

Every module must be equipped with a proper antenna with specific characteristics.

The antenna must be installed with care in order to avoid any interference with other

electronic devices, and it must also have a minimum distance of 20 cm from the body.

In case this requirement cannot be satisfied, the system integrator must assess the

final product against the applicable SAR regulations.

1.5.6. Disassembly

Do not disassemble the product.

Any evidence of tampering will void the warranty.

1.6. Document Organization

This manual contains the following chapters:

“Chapter 1: Introduction” provides a scope for this manual, target audience, contact

and support information, and text conventions.

CC864-DUAL Hardware User Guide

80pppSTzzzzza Rev. 0.4 - dd/mm/yy

“Chapter 2: Mechanical Specifications” contains information on the dimensions of the

module, the interface connector and the RF connector, and on how to include the

module into external applications.

“Chapter 3: Hardware Interface Description” describes the hardware interfaces of the

product and provides guidelines for using the module in various applications.

“Chapter 4: Development and Testing” provides information on how to connect the

module to the Telit Evaluation Kit (EVK).

“Chapter 5: Acronyms and Abbreviations” provides definition for all the acronyms and

abbreviations used in this guide.

“Appendix: Pin Allocation” specifies the allocation of the pins on the connector that is

used for connecting the unit with external applications.

1.7. Text Conventions

Danger – This information MUST be followed or catastrophic equipment failure or

bodily injury may occur.

Caution or Warning – Alerts the user to important points about integrating the module,

if these points are not followed, the module and end user equipment may fail or

malfunction.

Tip or Information – Provides advice and suggestions that may be useful when

integrating the module.

1.8. Related Documents

The following documents are related to this user guide:

•CC864-DUAL Product Description – (Doc No)

•CC864-DUAL Software Description – (Doc No)

1.9. Document History

Doc rev # Date Changes Location in

Guide

0.3 01.03.2008 First version for Peer review

0.4 04.03.2008 Updates after review

Autres manuels pour CC864-DUAL

Table des matières

Autres manuels Telit Wireless Solutions Unité de contrôle

Telit Wireless Solutions

Telit Wireless Solutions JF2 Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions CC864-DUAL Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions LE910C series Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions LM960 Mode d’emploi

Telit Wireless Solutions

Telit Wireless Solutions GE864-QUAD Automotive V2 Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions SL871 Fiche technique

Telit Wireless Solutions

Telit Wireless Solutions WE866C3-P Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions GM862GPS Series Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions LM940 Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions GE864 Series Caractéristiques techniques

Telit Wireless Solutions

Telit Wireless Solutions WE922-3GR Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions GC864-QUAD-C2 Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions GainSpan GS2K Series Manuel d'installation

Telit Wireless Solutions

Telit Wireless Solutions NL865B1 Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions ME50-868 Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions LE910C series Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions WL865E4-P Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions GL865-QUAD V4 Guide de sécurité

Telit Wireless Solutions

Telit Wireless Solutions LE910 Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions HE920 Series Caractéristiques techniques

Telit Wireless Solutions

Telit Wireless Solutions LE50-868 Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions LE915A P Series Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions UL865N3G Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions LE910Cx Manuel d'installation

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
