Telit Wireless Solutions CC864-DUAL Manuel d'installation

CC864-DUAL Hardware User Guide

1vv0300791 Rev 4.4 – 2011-01-26

CC864-DUAL Hardware User Guide

1vv0300791 Rev 4.4 – 2011-01-26

Disclaimer

The information contained in this document is the proprietary information of Telit

Communications S.p.A. and its affiliates (“TELIT”).

The contents are confidential and any disclosure to persons other than the officers,

employees, agents or subcontractors of the owner or licensee of this document,

without the prior written consent of Telit, is strictly prohibited.

Telit makes every effort to ensure the quality of the information it makes available.

Notwithstanding the foregoing, Telit does not make any warranty as to the

information contained herein, and does not accept any liability for any injury, loss or

damage of any kind incurred by use of or reliance upon the information.

Telit disclaims any and all responsibility for the application of the devices

characterized in this document, and notes that the application of the device must

comply with the safety standards of the applicable country, and where applicable,

with the relevant wiring rules.

Telit reserves the right to make modifications, additions and deletions to this

document due to typographical errors, inaccurate information, or improvements to

programs and/or equipment at any time and without notice.

Such changes will, nevertheless be incorporated into new editions of this document.

CC864-DUAL Hardware User Guide

1vv0300791 Rev 4.4 – 2011-01-26

Contents

1. Introduction...................................................................................................................6

1.1. Scope.......................................................................................................................6

1.2. Audience ..................................................................................................................6

1.3. Contact Information, Support ...................................................................................6

1.4. Product Overview.....................................................................................................6

1.4.1. General Specifications .................................................................................................. 7

1.4.2. Receiver Specifications ................................................................................................. 7

1.4.3. Transmitter Specifications ............................................................................................. 7

1.4.4. gpsOne Receiver Specifications ................................................................................... 7

1.5. Safety Recommendations ........................................................................................8

1.5.1. Local regulations ........................................................................................................... 8

1.5.2. Wiring and Installation................................................................................................... 9

1.5.3. Electrostatic Discharge.................................................................................................. 9

1.5.4. Antennas ....................................................................................................................... 9

1.5.5. Disassembly .................................................................................................................. 9

1.6. Document Organization ...........................................................................................9

1.7. Text Conventions ...................................................................................................10

1.8. Related Documents................................................................................................11

1.9. Document History...................................................................................................11

Added 3.2.2 Initialization and Activation state ...................................................................... 11

Updated 3.2.3 Turning Off the CC864-DUAL .......................................................................... 11

Updated 3.2.4 Hardware Reset ............................................................................................... 11

Added 3.2.5 Summary of Turning ON and OFF the CC864-DUAL ........................................... 11

Updated 3.9.1 Input lines (microphone)................................................................................... 11

Added 3.9.2 Output lines (Speaker) ..................................................................................... 11

2. Mechanical Specifications.........................................................................................12

2.1. Module Dimensions................................................................................................12

2.2. Interface Connector................................................................................................13

2.3. Mounting ................................................................................................................15

3. Hardware Interface Description.................................................................................16

3.1. Overview ................................................................................................................16

3.2. Turning On and Off the Module..............................................................................17

3.2.1. Turning On the CC864-DUAL ..................................................................................... 17

CC864-DUAL Hardware User Guide

1vv0300791 Rev 4.4 – 2011-01-26

3.2.2. Initialization and Activation state ................................................................................. 17

3.2.3. Turning Off the CC864-DUAL ..................................................................................... 18

3.2.3.1. Hardware Shutdown............................................................................................. 19

3.2.3.2. Software Shutdown .............................................................................................. 19

3.2.4. Hardware Reset .......................................................................................................... 19

3.2.5. Summary of Turning ON and OFF the CC864-DUAL ................................................. 21

3.3. Power Supply.........................................................................................................21

3.3.1. +5V Input Source Power Supply Design Guidelines ................................................... 23

3.3.2. +12V Input Source Power Supply Design Guidelines ................................................. 23

3.3.3. Battery Source Power Supply Design Guidelines ....................................................... 25

3.3.4. Battery Charge Control Circuitry Design Guideline ..................................................... 26

3.3.4.1. Trickle Charging ................................................................................................... 27

3.3.4.2. Constant Current Charging .................................................................................. 27

3.3.4.3. Constant Voltage Charging .................................................................................. 28

3.3.4.4. Pulse Charging..................................................................................................... 28

3.3.5. Thermal Design Guidelines ......................................................................................... 29

3.3.6. Power Supply PCB Layout Guidelines ........................................................................ 29

3.4. Antenna Requirements ..........................................................................................31

3.4.1. FCC’s RF Exposure Rules and Regulations ............................................................... 32

3.4.2. Antenna Installation Guideline..................................................................................... 32

3.5. GPS path Architecture and antenna.......................................................................32

3.5.1. GPS Antenna Requirements (Path 1) ......................................................................... 33

3.5.2. Combined Cellular/GPS Antenna Requirements (Path 2)........................................... 33

3.5.3. Linear and Patch GPS Antennas (Path 1)................................................................... 33

3.5.4. Active GPS Antenna LNA and Front End Design Considerations (Path 1)................. 34

3.6. GPS Antenna – Installation Guidelines ..................................................................34

3.7. Logic Level Specification........................................................................................34

3.8. Serial Interfaces .....................................................................................................35

3.8.1. UART - Serial Interface ............................................................................................... 35

3.8.1.1. Diagnostic Monitor Port........................................................................................ 36

3.8.1.2. RS232C Interface and Level Translation ............................................................. 37

3.8.1.3. 5V UART Level Translation.................................................................................. 38

3.8.2. USB Interface .............................................................................................................. 39

3.8.2.1. USB Transceiver Specifications........................................................................... 40

3.9. Analog Audio Interface...........................................................................................41

3.9.1. Input lines (microphone).............................................................................................. 42

3.9.2. Output lines (Speaker) ................................................................................................ 43

3.9.3. General Design Rules ................................................................................................. 43

CC864-DUAL Hardware User Guide

1vv0300791 Rev 4.4 – 2011-01-26

3.9.4. Handset Interface ........................................................................................................ 44

3.9.5. Headset Interface ........................................................................................................ 45

3.9.6. Car Kit Speakerphone Interface .................................................................................. 46

3.10. PCM Digital Audio Interface................................................................................48

3.11. I2C Bus Interface (Future) ...................................................................................48

3.12. ADC/DAC Interface.............................................................................................49

3.12.1. ADC Converter ............................................................................................................ 49

3.12.1.1. Description ........................................................................................................... 49

3.12.1.2. Using ADC Converter........................................................................................... 49

3.12.2. DAC Converter ............................................................................................................ 50

3.12.2.1. Description ........................................................................................................... 50

3.12.2.2. Enabling the DAC................................................................................................. 50

3.12.2.3. Low Pass Filter Example...................................................................................... 50

3.13. General Purpose I/O...........................................................................................51

3.13.1. Using a GPIO pin as Input........................................................................................... 52

3.13.2. Using a GPIO pin as Output........................................................................................ 52

3.13.3. TGPIO_06/ALARM...................................................................................................... 52

3.13.4. TGPIO_07/BUZZER.................................................................................................... 52

3.13.5. TGPIO_08/POWER_SAVING ..................................................................................... 53

3.14. Miscellaneous Interface Signals .........................................................................53

3.14.1. VAUX1......................................................................................................................... 53

3.14.2. VRTC........................................................................................................................... 54

3.14.3. STAT_LED – Network Status LED.............................................................................. 54

3.14.4. PWRMON.................................................................................................................... 55

3.14.5. AXE ............................................................................................................................. 55

4. Development and Testing..........................................................................................56

4.1. Debug of the Module in the Final Application.........................................................56

4.2. Development Kit.....................................................................................................56

5. Acronyms and Abbreviations....................................................................................58

6. Appendix: Pin Allocation...........................................................................................59

CC864-DUAL Hardware User Guide

1vv0300791 Rev 4.4 – 2011-01-26

1. Introduction

1.1. Scope

This document describes hardware solutions for developing a product containing the

Telit CC864-DUAL module, by:

Describing the basic functions of the module

Suggesting a proper hardware solution for each function

Describing common errors to be avoided

This document is not intended to provide an overall description of all hardware

solutions and all products that may be designed.

The solutions suggested serve as a guide or starting point for developing a product

with the Telit CC864-DUAL module.

However, avoiding the most common errors described in this document should be

regarded as UA mandatory.

1.2. Audience

This manual is intended for hardware developers who design products that integrate

the CC864-DUAL module.

1.3. Contact Information, Support

For general information, technical support, to report documentation errors and to

order manuals, contact Telit’s Technical Support Center (TTSC) at:

[email protected], [email protected],

[email protected], [email protected], or use

http://www.telit.com/en/products/technical-support-center/contact.php

For detailed information about where to buy Telit modules or for recommendations on

accessories and components visit: http://www.telit.com.

To register for product news and announcements or for product questions contact

Telit's Technical Support Center (TTSC).

Our aim is to make this guide as helpful as possible. Keep us informed of your

comments and suggestions for improvements.

Telit appreciates feedback from the users of our documentation.

1.4. Product Overview

The CC864-DUAL is a CDMA-1XRTT wireless module designed to have the same

form, fit and function as its GSM/GPRS counterpart product, the GC864-QUAD.

CC864-DUAL Hardware User Guide

1vv0300791 Rev 4.4 – 2011-01-26

As a result, integrators and developers are able to design applications once and take

advantage of the global coverage and service flexibility allowed by the combination of

the most prevalent cellular technologies worldwide.

With its ultra-compact design and extended operating temperature range, the Telit

CC864-DUAL module is the perfect platform for m2m applications, mobile data and

computing devices. It also incorporates gpsOne capability for applications in mobile

environments such as telematics, personal and asset tracking.

1.4.1. General Specifications

Parameter Description

External access Code division multiple access

CDMA protocol CDMA2000 1x Rel A and Rel B

Data Rate 153.6 Kb/s (full-duplex)

GPS Standalone GPS/ SGPS/ AGPS

Vocoder EVRC, 13kQCELP, 4GV

Operating temperature -30° ~ +80°

1.4.2. Receiver Specifications

Parameters Descriptions

Frequency range Cellular: 869~894 MHz

PCS: 1930~1990 MHz

Sensitivity Better than -108 dBm

Input dynamic range -25dBm ~ -108 dBm

1.4.3. Transmitter Specifications

Parameters Descriptions

Frequency range Cellular: 824~849 MHz

PCS: 1850~1910 MHz

Power class Cellular: Class III

PCS: Class II

Nominal power 0.27 W (24.31 dBm)

1.4.4. gpsOne Receiver Specifications

CC864-DUAL Qualcomm chipset QSC6055 is a Gen 7 device.

CC864-DUAL Hardware User Guide

1vv0300791 Rev 4.4 – 2011-01-26

Parameters Range Notes

Frequency range L1,1575.42

MHz 

Acquisition Sensitivity -

MSA Asynchronous A-

GPS (dBm)

-158

*QCT GPS RF Conducted Sensitivity

is defined at the measurement level:

the lowest GPS signal level (S,in

dBm) at the antenna port for which

the device can still detect an "in view"

satellite 50% of the time.

*Acquisition / Tracking Sensitivity

performance figures assume open

sky w/antenna and 2.5dB Noise

Figure.

Acquisition Sensitivity -

MSA Synchronous A-GPS

(dBm)

-159

Acquisition Sensitivity -

MSA Synchronous A-GPS

(dBm) w/ Sensitivity

Assistance (dBm)

-160

Cold Start Sensitivity

(dBm) -145

Tracking Sensitivity

Standalone or MSB (dBm) -160

Accuracy in Open Sky <2m CEP-50 Open sky, 1Hz tracking

Standalone TTFF

(Super Hot /Warm / Cold) 1s/29s/35s

Total number of SV

available ~30 SVs

Support of Predicted

Orbits Yes

Predicted Orbit CEP-50

Accuracy 5m 1-2 days age

1.5. Safety Recommendations

1.5.1. Local regulations

Verify that the use of this product is permitted in the country intended and in the

required product environment.

The use of this product may be dangerous and thus must be avoided where:

Interfacing with other electronic devices in environments such as hospitals,

airports, etc. is a concern.

A risk of explosion exists, such as in the proximity of gasoline, oil refineries,

etc.

CC864-DUAL Hardware User Guide

1vv0300791 Rev 4.4 – 2011-01-26

The integrator is responsible for enforcing local and specific environmental

regulations on the product. For further details refer to Chapter 1.7 for related

documents.

1.5.2. Wiring and Installation

Always follow the instructions in this guide when wiring the product.

The module must be supplied with a stabilized voltage source, and the wiring must

conform to security and fire prevention regulations.

The installation of external components must be well designed in order to ensure the

proper functioning of the module.

1.5.3. Electrostatic Discharge

Avoid any contact with the pins because electrostatic discharge can damage the

product.

1.5.4. Antennas

Every module must be equipped with a compatible antenna.

The antenna must be installed in a manner which avoids interference with other

electronic devices.

Reusing the Telit FCC ID for the end product may be possible if the antenna is

greater than 20cm from the human body when in use. Otherwise additional FCC

testing such as SAR is required. The system integrator must assess the final product

against the applicable FCC regulations.

1.5.5. Disassembly

Do not disassemble the product.

Any evidence of tampering will void the warranty.

1.6. Document Organization

This manual contains the following chapters:

“Chapter 1: Introduction” provides the scope for this manual, target audience, contact

and support information, and text conventions.

“Chapter 2: Mechanical Specifications” contains information on the dimensions of the

module, the interface connector and the RF connector, and instructions for designing

the module into external applications.

“Chapter 3: Hardware Interface Description” describes the hardware interfaces of the

product and provides guidelines for using the module in various applications.

“Chapter 4: Development and Testing” provides information on operating the module

with the Telit Evaluation Kit (EVK).

CC864-DUAL Hardware User Guide

1vv0300791 Rev 4.4 – 2011-01-26

“Chapter 5: Acronyms and Abbreviations” provides definitions for all acronyms and

abbreviations used in this guide.

“Appendix: Pin Allocation” specifies the allocation of the pins on the module

connector.

1.7. Text Conventions

Danger – This information MUST be followed or catastrophic equipment failure or

bodily injury may occur.

Caution or Warning – Alerts the user to important points about integrating the

module. If these points are not followed, the module and end user equipment may fail

or malfunction.

Tip or Information – Provides advice and suggestions that may be useful when

integrating the module.

All dates are in ISO 8601 format, i.e. YYYY-MM-DD.
