Tektronix WVR7200 Instructions d'installation et d'entretien

WVR7200 Waveform Rasterizer

Declassiﬁcation and Security

ZZZ

Instructions

www.tektronix.com

*P077067200*

077-0672-00

or suppliers, and are protected by national copyright laws and international treaty provisions.

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication

supersedes that in all previously published material. Speciﬁcations and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc.

14150 SW Karl Braun Drive

P.O. Box 500

Beaverton, OR 97077

USA

For product information, sales, service, and technical support:

In North America, call 1-800-833-9200.

Worldwide, visit www.tektronix.com to ﬁnd contacts in your area.

Table of Contents

Preface.............................................................................................................. iii

Clear and Sanitize Procedures................ .............. .............................................. ......... 1

Memory Devices............................................................................................... 1

Data Export Devices........................................................................................... 5

Troubleshooting..................................................................................................... 5

How to Clear or Sanitize a Non-Functional Instrument .............. .......... .............. ............. 5

How to Recover from Clearing or Removing the Instrument’s Memory................................ 5

WVR7200 Declassiﬁcation and Security Instructions i

Table of Contents

ii WVR7200 Declassiﬁcation and Security Instructions

Preface

This document helps customers with data security concerns to sanitize or remove

memory devices from the WVR7200 Waveform Rasterizer.

These products have data storage (memory) devices. These instructions tell

how to clear or sanitize the memory devices. The instructions also tell how to

declassify an instrument that is not functioning.

Products This document covers all WVR7200 instruments.

Related Documents The following table lists the documentation that is available for the product and

shows where you can ﬁnd it: in a printed manual, on the product documentation

CD-ROM, or on the Tektronix Web site.

Table i: Product documentation

Item Purpose Location

User Manual

(077-0668-XX)

Provides operation and application

information. This manual is available

in English, Japanese, and Simpliﬁed

Chinese.

Product Documentation CD and available at

www.tektronix.com/downloads

Online Help In-depth instrument operation and UI

help.

On the instrument

Speciﬁcations and Performance

Veriﬁcation Technical Reference

(077-0670-XX)

Speciﬁcations and procedures for

checking instrument performance.

Product Documentation CD and available at

www.tektronix.com/downloads

WFM and WVR Series

Management Information

Database (MIB) Programmer

Manual

(077-0261-XX)

SNMP command reference for remotely

controlling the instrument.

Product Documentation CD and available at

www.tektronix.com/downloads

Service Manual

(077-0676-XX)

Provides information about adjustments,

repair, and replaceable parts.

Available at www.tektronix.com/downloads

Installation and Safety Instructions

(071-3024-XX)

Provides safety and compliance

information along with hardware

installation instructions to present

the associated safety warnings.

This manual is available in English,

Japanese, and Simpliﬁed Chinese.

Printed manual and also available in electronic

format at www.tektronix.com/downloads

WVR7200 Declassiﬁcation and Security Instructions iii

Preface

Terms The following termsmaybeusedinthisdocument:

Clear. This removes data on media/memory before reusing it in a secured

area. All reusable memory is cleared to deny access to previously stored

information by standard means of access.

Erase. This is equivalent to clear.

Media storage/data export device. Any of several devices that can be used

to store or export data from the instrument, such as a USB port.

Nonvolatile memory. Data is retained when the instrument is powered off.

Power off. Some instruments have a “Standby” mode, in which power is

still supplied to the instrument. For the purpose of clearing data, putting the

instrument in Standby mode does not qualify as powering off. For these

products, you will need to either press a rear-panel OFF switch or remove the

power source from the instrument.

Remove. Thisisaphysicalmeanstoclearthedatabyremovingthememory

device from the instrument. Instructions are available in the product Service

Manual.

Sanitize. This eradicates the data from media/memory so that the data cannot

be recovered by other means or technology. This is typically used when the

device will be moved (temporarily or permanently) from a secured area to a

non-secured area.

Scrub. This is equivalent to sanitize.

User-modiﬁable. The user can write to the memory device during normal

instrument operation, using the instrument interface or remote control.

Volatile memory. Data is lost when the instrument is powered off.

iv WVR7200 Declassiﬁcation and Security Instructions

Clear and Sanitize Procedures

Memory Devices

The following tables list the volatile and nonvolatile memory devices in the

standard instrument and listed options. Detailed procedures to clear or sanitize

these devices, if any, are shown following each table.

Table 1: Volatile memory devices

Type and

minimum size Function

User

modiﬁable1

Data input

method Location To clear To sanitize

FPGA 1.3 K Audio

measurement

No Programmed

by onboard

ﬂash memory

Plugs into optional

Digital Audio board, IC8

on Dolby Audio board

None Remove the power

source from the

instrument for at

least 20 seconds

FPGA 920 KB Audio

measurement

No Programmed

by onboard

serial

EEPROM

U610 on Audio board None Remove the power

source from the

instrument for at

least 20 seconds

DSP RAM 32kx8 Audio

Measurement

No Programmed

from main

board

processor at

boot up

Audio board U410 None Remove the power

source from the

instrument for at

least 20 seconds

DDR2 RAM 32M x

Microprocessor

system memory

No Written by

processor

system

Main board, U6, U36,

U53, U73

None Remove the power

source from the

instrument for at

least 20 seconds

FPGA, DSP1

4.3 MB

Mapper #1 No Programmed

by onboard

ﬂash memory

Main board, U97 None Remove the power

source from the

instrument for at

least 20 seconds

QDR2RAM

1MBX18

Mapper #1 RAM

DSP1

No Dynamic

memory for

FPGA DSP1

Main board, U4, U43 None Remove the power

source from the

instrument for at

least 20 seconds

DDR2 32M X

16 RAM

Mapper#1 RAM

DSP1

No None, Part

is unused

in current

design

Main board, U21 None Remove the power

source from the

instrument for at

least 20 seconds

FPGA DSP2

4.3 MB

Mapper #2 No Programmed

by onboard

ﬂash memory

Main board, U161 None Remove the power

source from the

instrument for at

least 20 seconds

QDR2 RAM

1MBX18

Mapper #2 RAM

DSP2

No Dynamic

memory for

FPGA DSP2

Main board, U20, U162 None Remove the power

source from the

instrument for at

least 20 seconds

DDR2 32M X

16 RAM

Mapper#2 RAM

DSP2

No None, Part

is unused

in current

design

Main board, U163 None Remove the power

source from the

instrument for at

least 20 seconds

WVR7200 Declassiﬁcation and Security Instructions 1

Clear and Sanitize Procedures

Table 1: Volatile memory devices (cont.)

Type and

minimum size Function

User

modiﬁable 1

Data input

method Location To clear To sanitize

FPGA, DSY2 5 MB Rasterizer FPGA No Programmed

by onboard

ﬂash memory

Main board, U93 None Remove the power

source from the

instrument for at

least 20 seconds

DDR2 DSY 32 MB

X32

Frame Buffer #1

for DSY FPGA

Yes User can

initiate

capture to

this memory

Main board, U23, U65 None Remove the power

source fromthe

instrument for at

least 20 seconds

DDR2 DSY 32 MB

X32

Frame Buffer #2

for DSY FPGA

Yes User can

initiate

capture to

this memory

Main board, U44, U45 None Remove the power

source from the

instrument for at

least 20 seconds

DDR2 DSY 32 MB

X80

Capture Buffer for

DSY FPGA

Yes User can

initiate

captureto

this memory

Main board, U91, U92,

U94, U95, U96

None Remove the power

source from the

instrument for at

least 20 seconds

DSY SRAMDSY FPGA

Display SRAM

yes Stores

Graphics and

text as shown

on screen

Main board, U46, U47,

U48, U49

None Remove the power

source from the

instrument for at

least 20 seconds

1During normal instrument operation.

Table 2: Nonvolatile memory devices

Type and

minimum size Function

User

modiﬁable1

Data input

method Location To clear To sanitize

Serial EPROM

256x8

Stores SDI

calibration

coefﬁcients

No Programmed

during

calibration

SDI board, U343 Recalibrate SDI None

PLD General decoding

and control

No Programmed

by software

during software

upgrade

SDI board, U641 None Reload the

system software

per the loading

instructions

Serial EPROM Stores Eye

calibration

coefﬁcients

No Programmed

during

calibration

Eye board, U343 Recalibrate Eye None

PLD General decoding

and control

No Programmed

by software

during software

upgrade

Eye board, U641 None Reload the

system software

per the loading

instructions

Flash Memory

4MB

Audio

measurement

No Programmed

by software

during software

upgrade

Plugs into optional Digital

Audio board, IC9 on Dolby

Audio board

None Reload the

system software

per the loading

instructions

Serial EEPROM

256 X 8

Stores audio

calibration

coefﬁcients

No Programmed

during

calibration

U0360 on Audio board Recalibrate Audio None

Serial EEPROM

256 X 8

Stores Composite

calibration

coefﬁcients

No Programmed

during

calibration

U12 on Composite board Recalibrate Composite None

2 WVR7200 Declassiﬁcation and Security Instructions

Clear and Sanitize Procedures

Table 2: Nonvolatile memory devices (cont.)

Type and

minimum size Function

User

modiﬁable 1

Data input

method Location To clear To sanitize

NAND Flash

256 M X 8

Not used but

is checked in

power-up self-test

No None Main board, U103 None None

NOR Flash 128 M

X16

Loads FPGAs on

power up, contains

instrument SW,

network access

parameters, and

user-deﬁned

presets

yes Programmed

by software

during software

upgrade

Main board, U101, U102 Clear Presets and

re-load instrument SW.

this does not clear the

factory-assigned MAC

address.

None

NVSRAM plus

Real Time Clock

Stores time set by

user and Network

parameters,

Option Key,

Instrument Type,

Diagnostic log and

last instrument

state.

Yes User Interface Main board, U11 SettimetoGMT.

Clear diagnostic log,

Clear network settings,

restore factory preset

then power down.

None

PLD, Glue Programs DSP

and DSY FPGAs

and and general

control and

decoding.

No Programmed

by software

during software

upgrade

Main board, U19 None Reload the

system software

per the loading

instructions

Serial Flash DSP1

32 M

Unused, Possible

FPGA code

storage for DSP

No None Main board, U16 None Reload the

system software

per the loading

instructions

Serial Flash DSP2

32 M

Unused, Possible

FPGA code

storage for DSP

No None Main board, U164 None Reload the

system software

per the loading

instructions

Parallel Flash

DSY32M

Unused, Possible

FPGA code

storage for DSY

No None Main board, U63 None Reload the

system software

per the loading

instructions

1During normal instrument operation.

Clear Presets Procedure 1. Press the PRESET button.

2. Use the arrow buttons to navigate to Recall Preset >Recall Factory Preset

and press the SEL button.

3. Press the PRESET button.

4. Use the arrow buttons to navigate to Save Preset >Select Group A >Save

A1 and press the SEL button.

5. Repeat step 4 for all eight presets (1 through 8) for each of the four groups (A

through D).

6. Use the arrow buttons to navigate to Rename Preset >Select Group (named

preset).

WVR7200 Declassiﬁcation and Security Instructions 3

Clear and Sanitize Procedures

7. Rename all Preset Groups and all Presets to generic names.

8. Press the PRESET button to exit the menu.

Clear Diagnostic Log

Procedure

1. Press the CONFIG button. Then select Utilities >View Diagnostic Log.

Press SEL to display the log.

2. Press >until the box by “Erase Log” is highlighted. Then press SEL to

remove all entries in the diagnostic log.

3. Press >until the box by “Exit” is highlighted. Then press SEL to exit the

log display.

4. Press the CONFIG buttontoexittheconﬁguration menu.

Clear IP and SNMP

Address Fields Procedure

1. Press the CONFIG button. Then select Network Settings.

2. Select IPConﬁgModeand set it to Manual to display the IP address.

3. Navigate to IP Address.Thenpress>to enter the edit mode. Enter

“000.000.000.000” for the IP address.

4. Repeat Step 3 for the Subnet Mask, Gateway Address, SNMP Trap Address

1thro

ugh SNMP Trap Address 4, and Network Front Panel FP1 Address

through FP4 Address.

5. Select Instrument Name, navigate to Clear, and press the SEL button.

6. Repeat step 5 for SNMP Public Community, SNMP Private Community,

and Web password.

7. Press the CONFIG buttontoexittheconﬁguration menu.

4 WVR7200 Declassiﬁcation and Security Instructions

Autres manuels pour WVR7200

Table des matières

Autres manuels Tektronix Instrument de mesure

Tektronix

Tektronix P6022 Manuel utilisateur

Tektronix

Tektronix GeoProbe G10 Manuel utilisateur

Tektronix

Tektronix 3177 Manuel utilisateur

Tektronix

Tektronix MTS4EAV7 Instructions de fonctionnement

Tektronix

Tektronix TIVH Series Manuel utilisateur

Tektronix

Tektronix Keithley 6517-RH Manuel utilisateur

Tektronix

Tektronix DC503a Manuel utilisateur

Tektronix

Tektronix KEITHLEY 2450-EC Manuel utilisateur

Tektronix

Tektronix RSA6100A Series Manuel d'utilisation et d'entretien

Tektronix

Tektronix 1502 Manuel utilisateur

Tektronix

Tektronix TCP312 Manuel utilisateur

Tektronix

Tektronix 7D20 Manuel utilisateur

Tektronix

Tektronix PRISM Manuel utilisateur

Tektronix

Tektronix Keithley 2182A Manuel utilisateur

Tektronix

Tektronix 067-0599-00 Manuel utilisateur

Tektronix

Tektronix P6417 Manuel utilisateur

Tektronix

Tektronix 7D01 Manuel utilisateur

Tektronix

Tektronix TLA715 Series Manuel utilisateur

Tektronix

Tektronix SPECMON3 Manuel utilisateur

Tektronix

Tektronix AA5001 Manuel utilisateur

Tektronix

Tektronix CSA8000B Series Manuel utilisateur

Tektronix

Tektronix VM5000 Series Manuel du propriétaire

Tektronix

Tektronix TAP1500 Manuel utilisateur

Tektronix

Tektronix 7D01 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
