Tekkeon myTune IA1000 Manuel utilisateur
IA1000
User Guide
FM Transmitter and
Car Charger for iPod
myTune_UG_revsd_fnl 11/17/05 7:04 PM Page 1
myTune_UG_revsd_fnl 11/17/05 7:04 PM Page 2
USER GUIDE
Contents
Overview ............................................................ . . . . . . . . . . . . . . . . . 2
Getting Started ......................................................... . . . . . . . . . . . . 2
Unpacking myTune FM .......................................................2
Getting to Know myTune FM ................................................3
Using myTune FM ......................................................... . . . . . . . . 4
Customizing myTune FM .....................................................4
Mounting myTune FM ....................................................... . 6
Playing iPod Music on an FM Radio .......................................7
Charging iPod .......................................................... . . . . . . . . 9
Downloading Music ........................................................ . . . 9
Troubleshooting ......................................................... . . . . . . . . . 10
Limited Warranty ........................................................ . . . . . . . . 11
Customer Support ........................................................ . . . . . . . 13
Federal Communications Commission (FCC) Statement ................14
myTune_UG_revsd_fnl 11/17/05 7:04 PM Page 1
Overview
myTune™FM, a combination FM transmitter and car charger for
iPod, plays your iPod music on your car stereo, and simultaneously
charges your iPod. myTune FM cradles your iPod and mounts on
your vent to keep your iPod at eye level, without interfering with
your driving.
myTune FM is made for iPod (3rd, 4th, 5th generation), iPod mini,
and iPod photo.
Getting Started
Unpacking myTune FM
Your myTune FM package includes
the following:
2
Sizing pads (5 sets)
iPod mini mounting clip
Car power adapter
myTune FM with
mounting clip
myTune_UG_revsd_fnl 11/17/05 7:04 PM Page 2
Channel Selector FireWire Port for
Connection to
Power Adapter
Power Button USB 2.0 Port
Power Adapter
Channel Selection
Indicators
iPod Mounting Clip
Getting to Know myTune FM
3
USER GUIDE
myTune_UG_revsd_fnl 11/17/05 7:04 PM Page 3
Using myTune FM
Customizing myTune FM
To place iPod (except iPod mini) into myTune FM, you must first adhere sizing
pads that hold your specific model iPod into place. Two types of sizing pads are
provided: round sizing pads for the back plate, and rectangular sizing pads for the
arms. The table on page 5 indicates the sizing pads that should be adhered for
your iPod.
Sizing pads are not required for iPod mini as a custom arm holds the iPod mini in place.
To adhere round sizing pads:
1. Peel the paper from the appropriate sizing pads and adhere
each pad onto one of the circles on the back plate of
myTune FM.
To adhere rectangular sizing pads:
1. Peel the back of each sizing pad, and adhere it to
the inside front curve of the arm (about 2mm from
the front) as shown.
To use iPod mini arms:
1. Remove the attached arms by gently pushing one
arm toward the back of myTune FM.
2. Snap the mini arms into place.
4
Sizing
Pads
Sizing
Pads
myTune_UG_revsd_fnl 11/17/05 7:04 PM Page 4
5
Sizing Pad Label
iPod Round Pad Rectangular Pad
iPod with video, 60GB 4G 40GB 5G
iPod with video, 30GB 4G 20GB 5G
iPod with color display, 60 GB iPod photo
40GB & 60GB/
3G 30GB & 40GB
iPod with color display, 20 GB 3G 15GB & 20GB
iPod photo, 60GB iPod photo
40GB & 60GB/
3G 30GB & 40GB
iPod photo, 40GB iPod photo
40GB & 60GB/
3G 30GB & 40GB
iPod photo, 30GB 3G 15GB & 20GB
iPod U2, 20GB (iPod photo) 3G 15GB & 20GB
iPod mini, 6GB
iPod mini, 4GB
iPod, 40GB Click Wheel (4G) 4G 40GB
iPod, 20GB Click Wheel (4G) 4G 20GB
iPod Black, Special Edition, 4G 40GB
20GB(4G)
iPod, 40GB Dock Connector (3G) 3G 30GB & 40GB
iPod, 30GB Dock Connector (3G) 3G 30GB & 40GB
iPod, 20GB Dock Connector (3G) 3G 15GB & 20GB
iPod, 15GB Dock Connector (3G) 3G 15GB & 20GB
iPod, 10GB Dock Connector (3G) 3G 15GB & 20GB
USER GUIDE
myTune_UG_revsd_fnl 11/17/05 7:04 PM Page 5
Mounting myTune FM
myTune FM snaps onto the air vents in your car. To accommodate different air
vent orientations, the mounting clip on the back of myTune FM swivels to a
horizontal or vertical position. You can leave myTune FM mounted in your car,
and dock iPod in myTune FM when you’re ready to listen to your tunes on the
radio.
To mount myTune FM on your air vent:
1. If your air vents have horizontal flaps, simply
attach the mounting clip to the vent flap. If your
air vents have vertical flaps, twist the mounting
clip to the vertical position, and attach the
mounting clip to the vent flap.
2. With one end plugged into myTune FM, insert the
power adapter into the 12V power outlet (lighter
adapter) in your car. The blue light on the power
adapter will turn on to indicate that the adapter is
plugged in.
6
myTune_UG_revsd_fnl 11/17/05 7:04 PM Page 6
To dock iPod into myTune FM:
1. Slide iPod down the face of myTune FM as shown until the
iPod dock connector is firmly inserted in to the 30-pin
myTune FM connecter. The arms will hold iPod in place. The
iPod mini will slide between the frontmost brackets on the
mini clip.
2. To remove iPod, gently slide iPod up the face of myTune FM.
Playing iPod Music on an FM Radio
To play your iPod music on your car radio, you must first select the channel on
myTune FM, and then select the same channel on your FM radio. The seven
pre-set channels available on myTune FM are CH1, CH2, 88.1, 88.3, 88.5, 88.7,
and 88.9. CH1 and CH2 are market-dependent channels. The default channels for
these two selections are 87.7 (CH1) and 87.9 (CH2).
A green light indicates that the channel selected is on the top row, while an
amber light indicates the selected channel is on the bottom row.
The last channel in the bottom row is not used.
7
USER GUIDE
Top row
Bottom row
myTune_UG_revsd_fnl 11/17/05 7:04 PM Page 7
To play iPod music on your FM radio:
When myTune FM is turned on, the channel will be set to 87.7 (CH1), the default
FM channel.
1. With myTune FM mounted in your car and your car powered on, turn on your
FM radio and select 87.7 on your dial.
2. Switch the power button on the bottom of myPower FM to ON.
3. Turn on the connected iPod and play your music. You will hear the music
broadcast on your car radio.
4. If the reception on the selected channel is not clear, press the channel selector
on the bottom of myTune FM to select the next channel. An LED will light to
indicate the channel selection. Each time you press the button, the selection
will change, moving across the channels on the front of myTune FM from left
to right, top to bottom. Channels on the top row are indicated by a green LED,
while channels on the bottom row are indicated by an amber LED.
5. Change the FM radio station to the channel set on myTune FM. You will hear
the music broadcast on your car radio.
6. Repeat steps 4 and 5 until you identify the optimum FM channel in your area.
7. When you’re done listening, switch the power button to OFF. Your iPod will
continue to charge as long as myTune FM is connected to the power outlet
(and the car is on), and your iPod is not fully charged.
8
myTune_UG_revsd_fnl 11/17/05 7:04 PM Page 8
