Technogym MB430 Manuel utilisateur

Dual Adjustable Pulley

User manual

Dual Adjustable Pulley 2

Contents

Important safety instructions.................................................................................3

Personal safety .........................................................................................................4

Identication of the manufacturer and the equipment........................................6

Description of the equipment..................................................................................7

Technical data............................................................................................................8

Accessories................................................................................................................9

Place of installation ................................................................................................10

Assembling the equipment....................................................................................11

Assembling the barbell supports .........................................................................18

Adjusting the equipment........................................................................................19

Lifting and handling the equipment.................................................................... 20

Securing the equipment.........................................................................................21

Routine maintenance............................................................................................ 22

Replacing the spring hook......................................................................................23

Technical Service ....................................................................................................24

Storage .....................................................................................................................25

Disposing of the equipment ..................................................................................25

Using the equipment ............................................................................................. 26

Dual Adjustable Pulley 3

Important safety instructions

Always consult a qualied and licensed medical professional or healthcare practitioner before beginning any nutritional or diet regime and any stretching

or training programme. Remember that it is always good practice to make full inquiries and nd out about any possible eects that actions and choices

you make may have on your health.

Please read all instructions before using the equipment. These instructions were written to ensure your safety and to protect the unit.

Do not allow children unsupervised access to the unit; parents and any other adults to whom the children are entrusted must take responsibility for

them and prevent any situations from occurring and any behaviour for which the equipment is not intended. When children are present, they must be

carefully supervised, bearing in mind their psycho-physical development in relation to the use of the equipment. The equipment is totally unsuitable for

use as a toy.

The equipment may be used by or near disabled persons only under careful supervision by qualied personnel.

Use the unit exclusively for the purposes described in the user manual; only perform the exercises for which the unit has been designed, following the

instructions given in the manual. Any other use should be considered incorrect and therefore dangerous.

The product Dual Adjustable Pulley is a xed weight training equipment unit that can be used for body-building or sculpting, physical activity aimed at

keeping in shape, physical education and training for specic competitions and sports.

The product must be installed and used in a place in which access and supervision are specically controlled by the owner.

The product Dual Adjustable Pulley is intended for commercial use.

Do not use any accessories other than those recommended by Technogym.

Keep your hands away from moving parts.

Never drop or insert any object into any opening.

Do not use outdoors. Do not leave the unit outdoors, exposed to the elements (rain, sun, wind, etc.). Do not expose the unit to water jets.

SAVE THESE INSTRUCTIONS

Dual Adjustable Pulley 4

Personal safety

Use of the unit is subject to a medical examination in relation to the type of workout exercise you intend to perform, and in compliance with the conditions

for use laid down by Technogym.

Before beginning a training plan, consult a doctor to ascertain any limitations to use of the equipment.

Persons suering from certain physical conditions may only use the unit under the strict supervision of a doctor with specic qualications.

If you feel unwell (dizziness, chest pain, etc.) while performing the training, immediately stop the exercise and consult a doctor.

Before starting any workout, make sure your position on the unit is correct, and be careful with any components that might constitute an obstruction.

Plan the workout according to your physical characteristics and state of health, beginning with less demanding workloads.

Do not overexert yourself or work to exhaustion. If you feel pain or unusual symptoms, stop training immediately and seek medical assistance.

Incorrect or excessive workout may cause physical harm.

Wear proper workout clothing and shoes during training; do not wear loose clothing. Tie long hair back. Keep garments or towels away from moving parts.

During use other people must remain at a safe distance.

Do not use the unit when children or pets are present.

Completely assemble the unit before using it. Check the equipment before each use, and check that the cable is correctly routed inside the races

of all the pulleys and the state of wear of the cable. If there are signs of wear, contact the Technogym Technical Support service. Do not continue to

operate the unit when it is not working properly.

Assemble and operate the unit on a solid, level surface.

Keep the equipment in good operating condition. If you see signs of wear, contact Technogym's technical support service.

Make sure that the load selection pin is fully inserted. Use only the pin provided by the manufacturer. Contact the sta for any questions.

Only remove the pin when the weight stack is in the rest position. The weight stack is in the rest position when both the weights and the crosspiece are

not in the air. If the weight stack is not in the rest position, contact oor sta and do NOT use the equipment.

Do not attempt to perform maintenance operations on the equipment other than those described in the user manual.

Dual Adjustable Pulley 5

Personal safety

The instruction label must be applied on the equipment. Technogym declines all responsibility in the event of the equipment being used before axing

the instruction label.

The equipment is designed and constructed in compliance with the requirements for user safety and health; however, there are some areas that may give

rise to risks that are not plainly evident. We therefore recommend taking particular care to avoid any risk of crushing upper and lower limbs.

The product has no sharp corners.

The maximum user weight is 180 kg (397 lb).

This symbol accompanies safety warnings and IS used to draw attention to potential risks of personal injury. Pay attention to all

safety warnings accompanied by this symbol to avoid possible injury.

WARNINGS

During all operations involving transport, maintenance and cleaning, pay attention to any part of the product where body parts

may become trapped.

Attention must be paid to the labels attached to the product, as they provide information about possible risks and hazards.

We recommend immediately replacing the labels when they become damaged or dicult to read.

Technogym is not responsible for any harm due to any failures or damage caused by unauthorized maintenance, misuse, accident, negligence, improper

assembly or installation, debris resulting from any construction activities in the area where the unit is used, rust or corrosion as a result of the product’s

location, alterations or modications without Technogym’s written authorization or for failure on your part to use, operate and maintain the unit as set

out in this User Manual.

Controllare periodicamente lo stato di usura

Peso MAX utente: 180 kg

Peso MX di lavoro: vedi pacco pesi

Tipo: IC EN957 - 1/2

CABLE STATIONS CB350C0 - ALK0GGGK

Maximum user’s body weight: 180 kg

Maximum training weight: see weight block

CB350C0900001 c

Dual Adjustable Pulley 6

Identication of the manufacturer and the equipment

The identication plate of the equipment and manufacturer gives the following details:

AName and address of the manufacturer

BCE Mark

CSerial number

DCautions and maximum user weight

EEquipment classication

Dual Adjustable Pulley 7

Description of the equipment

Frames (A): the load-bearing structure of the equipment.

Crosspieces (B): elements that join the two frames.

Upper handgrips (C): held by the user to perform certain exercises.

Adjustable output cable (D): their position can be adjusted in height

with the handles (E).

Weight stack(F): each pulley, operated by the user, moves the weights

along two guides by means of a cable. A pin (G) is used for selecting the

load in order to adjust the exercise eort level.

Foothold (H): to help climb on.

Barbell support (I): optional device used to support the barbell, when

not in use.

Tray (L): used to place accessories, or anything else, during the workout.

Power mode (M): eliminates the weight stack inertia in order to perform

power and explosive strength exercises. Push the knob forward to

activate the mechanism; pull the knob back to disable it.

1450 mm

(57")

1196 mm

(47")

MB430

2324 mm

(91")

513 kg (1140 lb)

648 kg (1430 lb)

2 x 140 kg (2 x 309 lb)

2 x 200 kg (2 x 441 lb)

MB436

Dual Adjustable Pulley 8

Technical data

A0000510

A0000511

A0000515

A0000514 A0000513

A0000516 A0000517

Dual Adjustable Pulley 9

Accessories

The equipment’s standard outt comprises:

- user manual

- warranty certicate

- two handles A0000510

- two handles A0000511

- one ankle strap A0000515

The following are optional:

- belt A0000514

- thigh strap A0000513

- barbell with relative supports A0000516

- bar A0000517.

Dual Adjustable Pulley 10

Place of installation

To guarantee safe, comfortable and eective use of the equipment, the place of installation must comply with certain specic requirements; in particular,

before choosing where to install the equipment it is recommended to check the following:

- temperature between +10°C and +25°C;

- sucient ventilation to maintain a humidity level between 20% and 90%, when the equipment is in use;

- adequate lighting, so that the physical exercise takes place in pleasant and relaxing conditions;

- sucient clearance on all sides of the product, taking into account its maximum dimensions when in use, to ensure safety; and a space at least 60

cm wide on the side where the product is accessed;

- a at, stable and vibration-free oor surface, with adequate carrying capacity for the equipment’s weight.

If the equipment is installed in a public recreational area, the place must conform to all the requirements prescribed by the regulations in force.

WARNINGS

The equipment must be installed and used in a place whose access and supervision are specically controlled by the owner.

When installing the equipment, use suitable personal protective equipment.
