technetix AIMA3000.FT5X Manuel d'exploitation
May/2016 - Version 1.0
AIMA3000.FT5X
1550 nm Forward Transmitter - Externally Modulated
Product User Manual
AIMA3000.FT5X Product User Manual
Technetix Group Limited
AIMA3000.FT5X
1550 nm Forward Transmitter - Externally Modulated
Product User Manual
AIMA3000.FT5X Product User Manual
Technetix Group Limited
Contents
1 About This Manual....................................................................................................................................................5
1.1 Chapter Overview ..................................................................................................................................................................................5
1.2 Related Documentation........................................................................................................................................................................5
1.3 Document Conventions........................................................................................................................................................................6
1.4 Technical Support...................................................................................................................................................................................6
2 Precautions.................................................................................................................................................................7
3 Overview.....................................................................................................................................................................8
3.1 Product Description ...............................................................................................................................................................................8
3.2 Product Key Features............................................................................................................................................................................9
3.3 Specifications...........................................................................................................................................................................................10
3.4 Block Diagram .........................................................................................................................................................................................12
3.5 Order Details............................................................................................................................................................................................13
4 Module Characteristics ............................................................................................................................................15
4.1 Module Appearance and Port Layout..............................................................................................................................................15
4.1.1 Overview ..........................................................................................................................................................................................15
4.1.2 Front Panel Layout ........................................................................................................................................................................16
4.1.3 Rear Panel Layout..........................................................................................................................................................................18
5 Installation ..................................................................................................................................................................19
5.1 Preparatory Work for Installation .......................................................................................................................................................19
5.2 Unpacking.................................................................................................................................................................................................19
5.3 Module Installation .................................................................................................................................................................................20
5.4 Connecting Optical Cables .................................................................................................................................................................21
5.4.1 Using the Sliding Fibre Guide....................................................................................................................................................21
5.4.2 Using the Fibre Tray......................................................................................................................................................................23
5.4.3 Cleaning the Fibre Connector Ends and Front-panel Optical Ports .............................................................................25
5.4.4 Connecting the Optical Fibres ..................................................................................................................................................26
5.5 Check Module LEDs ..............................................................................................................................................................................26
5.6 Test the Optical Output Signal............................................................................................................................................................27
AIMA3000.FT5X Product User Manual
Technetix Group Limited
5.7 FT5X Initial Setup....................................................................................................................................................................................28
6 Module Configuration & Alarm setup....................................................................................................................30
6.1 Port Configuration screen....................................................................................................................................................................30
6.1.1 Confirming Input Signal ...............................................................................................................................................................33
6.1.2 Alarm Status Pages .......................................................................................................................................................................34
6.1.3 Module operating voltage and temperature alarm ............................................................................................................35
6.1.4 Module Port Alarms.......................................................................................................................................................................36
6.1.5 Alarm Monitoring Configuration................................................................................................................................................37
6.1.6 Input / Output Status Monitoring...............................................................................................................................................39
6.2 Logs Management..................................................................................................................................................................................42
6.3 Device Upgrade......................................................................................................................................................................................43
6.4 Restoring Factory Defaults ..................................................................................................................................................................44
6.5 Reboot........................................................................................................................................................................................................45
7 Troubleshooting.........................................................................................................................................................47
8 Declaration of Conformity .......................................................................................................................................49
Appendix A: Default Alarm Limit Settings ...................................................................................................................50
Appendix B: Factory Default Settings...........................................................................................................................51
AIMA3000.FT5X Product User Manual
Technetix Group Limited
1 About This Manual
1.1 Chapter Overview
1. About This Manual: Preface
2. Precautions
3. Overview: Application module overview, including the module features, technical specifications, and
ordering information.
4. Module characteristics: The appearance of the equipment, port and introduction of other components
5. Installation procedure
6. Module Configuration & Alarms: Web management configuration instructions.
7. Troubleshooting
8. Product Warranty
9. Declaration of Conformity.
Appendix A: Default Alarm Limit Parameters
Appendix B: Factory Default Settings
1.2 Related Documentation
The following documents may be used in conjunction with this manual:
• Technetix.AIMA3000 - Product User Manual
• Technetix.AIMA ASMM - Product User Manual
• AIMA3000 NMS Web Management System Product User Manual
- Technetix.NMS3-EPSM - Basic Inventory Management
- Technetix.NMS3-EPSM - Basic Alarm Management
- Technetix.NMS3-EPSM - Basic System Management
- Technetix.NMS3-EPSM - Basic Template Management
AIMA3000.FT5X Product User Manual
Technetix Group Limited
1.3 Document Conventions
Before you use the manual, please familiarise yourself with the format used in this manual.
‘*’ Asterisk: Points marked with an asterisk means there is a corresponding note on the page
1.4 Technical Support
If you need help in the process of setting up and maintaining an FT5X, please contact Technetix’s technical
support sta:
Europe:
Technetix BV
Kazemat 5
NL-3905 NR Veenendaal
P.O. Box 385
NL-3900 AJ Veenendaal
The Netherlands
Phone: +31 318 58 59 59
Email: customer.service.[email protected]
AIMA3000.FT5X Product User Manual
Technetix Group Limited
2 Precautions
WARNING!
This equipment is intended for indoor applications. To prevent fire or electrical shock, or
damage to the equipment, do not expose units to water or moisture.
• You should carefully read and thoroughly understand the contents of the manual before
installing and using this equipment.
• A typical connector is the SC/APC 8°. Note: An 8 ° angle polished optical connectors must
be used.
• At any time, there may be dangerous voltage inside the device.
• Do not power up before the cover and the panels of the equipment are installed and the
enclosure is closed
Cleaning
Only use a damp cloth for cleaning the front panel. Use a soft dry cloth to clean the top of the unit.
DO NOT use any spray cleaners or chemicals of any kind.
Outage or overload requiring service and repairs
Unplug the unit and refer the servicing to Technetix qualified service personnel only.
Servicing and repairs
DO NOT attempt to service this unit yourself. Refer all servicing needs to Technetix qualified service
personnel only.
WARNING!
Exposure to class 3A laser radiation is possible. Access should be restricted to
trained personnel only. Do not view exposed fibre or connector ends when handling
optical equipment.
AIMA3000.FT5X Product User Manual
Technetix Group Limited
3 Overview
3.1 Product Description
The 1550 nm Forward Transmitter - Externally Modulated (FT5X) is designed to plug into Technetix latest Advanced
Intelligent Multi-services Access platform (AIMA3000). Technetix wavelength-tunable FT5X series is available in single,
dual and quad transmitter variants.
This series of modules includes Monolithic Distributed Bragg Reflector (DBR) laser with a Silicon Optical Amplifier and an
Indium- Phosphide (InP) Mach-Zehnder Modulator provide AIMA with a cost-eective system for 1550 nm transmissions for
DWDM applications when used for optical ITU frequency grids.
Technetix AIMA3000 FT5X series transmitter is designed for multi-service operators (MSOs) to increase network
capacity to satisfy an ever-growing subscriber demand for more bandwidth. The FT5X can be used with Erbium Doped
Fibre Amplifiers (EDFA) in short haul Fibre-to-the-Home (FTTH) applications and medium haul set-ups with a high RF
performance of up to 60 km.
All FT5X models can also be conveniently monitored and controlled through a computer connected to one of the Ethernet
ports via the ASMM module. All module settings are retained in non-volatile memory to ensure trouble-free operation. Bulk
updating, automatic uploading and downloading of configuration files can be done when using Technetix NMSE web-
based management system.
AIMA3000.FT5X Product User Manual
Technetix Group Limited
3.2 Product Key Features
• Plug-and-play AIMA3000 platform module with up to 4 independent forward path transmitters
• Suitable for DWDM applications supporting ITU optical frequency grid wavelength channels 21 to 51 (1560.61 nm
to 1536.61 nm)
• Tunable wavelength between channel 21 and 51 in 200 GHz increments, reducing the quantity of transmitters at
dierent fixed wavelengths
• All-digital QAM loading from 45 MHz to 1200 MHz
• Link distance of up to 60 kilometers without any dispersion compensation required
• High-density up to 64 transmitters in a 4RU chassis
• Automatic gain control (AGC) for a consistent optical modulation index (OMI)
• Automatic laser power control for consistent optical output
• Comprehensive alarm reporting and monitoring
• Remote firmware upgrade and auto upload/download of configuration files through ASMM web interface or
using Technetix NMSE
• FCC, CE and RCM (1) compliant
(1) See Declaration of Conformity for current status.
AIMA3000.FT5X Product User Manual
Technetix Group Limited
3.3 Specifications
Optical Performance
Optical wavelength (1) Tunable/Fixed ITU DWDM Channels 21 to 51 (1560.61 nm to 1536.61 nm)
Optical outputs 1, 2, or 4
Optical output power 5 dBm
per port 6 dBm (fixed wavelength only)
Optical connector SC / APC
(2), LC / APC, FC/APC, E2000 / APC
Centre wavelength spacing 200 GHz
SBS suppression +13 dBm
RF Performance
RF bandwidth 45 ~ 1200 MHz
RF flatness ± 0.75 dB
RF input return loss > 16 dB
RF input level, nominal (2) 15 dBmV per channel
AGC range ±3 dB
RF impedance 75 Ω
Laser Input RF level test point -20 dB ± 1 dB relative to laser input
Isolation of transmitters > 65 dB
RF connectors Single: 1 x GSK-type female
Double: 2 x GSK-type female
Quad: 4 x GSK-type female
RF test points Single: 1 x Mini-SMB(4)
Dual: 2 x Mini-SMB(4)
Quad: 4 x Mini-SMB(4)
Alarms and laser status Front-Panel LEDs, SNMP traps
Link Performance (5)
MER > 38 dB
BER < 1E-9
General
Power supply Powered via AIMA3000 backplane
Power consumption Single port: < 7.0 W
Dual port: < 13.0 W
Quad port: < 25.0 W
Operating temperature 0 ~ +50 °C
Operating humidity 90 % (Non-condensing)
