PRODUCT OVERVIEW

Building upon decades of manufacturing reliable recording devices TASCAM introduces the “first”

combination Compact Flash / CD recording/playback device; all in single rack space.

The SS-CDR1 utilizes the latest in solid-state technology combined with the traditional CD player/recorder.

This rack-mountable combination recorder/playback device supports MP3 file recording and playback to/from

CD and Memory. Record, play, and edit (divide, combine, erase, rename) WAV files to and from Memory

Card.

Traditional source device features include pitch and key control, auto cue and auto ready, instant start, sync

record, auto track increment, and manual track increment. Rear panel analog I/O (balanced / unbalanced) and

S/PDIF (coaxial / optical) are provided in addition to RS-232 and Parallel control.

The SS-CDR1 is easy to use and provides enough record/playback time (based on CF card size) to meet the

demands of a wide range of installation applications where extended record and playback times are required.

MSRP - $1,249.00

1U Rack-Space Solid-State Combination Recorder

Memory Recorder Media: Compact Flash Card

Applicable CD-RW Recorder Media: CD-R, CD-RW,

CD-R-DA, CD-RW-DA.

MP3 file recording/playback to/from CD & CF memory

card

WAV file recording to/from memory.

Disc format for CD-RW: CD-DA, ISO9660 for MP3

CD to memory (copying and ripping) and memory to CD

(MP3: copy in ISO9660, WAV: CD-DA)

WAV File Edit functions for CF memory recorder:

divide, erase, combine, rename.

Instant Start

Power on play (front panel selectable)

S/PDIF Digital In/Out (Coaxial & Optical)

Headphone Jack w/level control

Pitch control and key control

RS-232 serial control (D-sub 9pin)

Parallel control (D-sub 25pin)

Sync Record, auto track increment (level, DD, time)

manual track increment.

Mono mix output

PS/2 keyboard input for folder/file name editing and

remote control.

Wired remote control (included)

TASCAM 7733 Telegraph Road Montebello, CA 90640 (323) 726-0303 http://www.tascamcontractor.com

TASCAM, a division of TEAC Corporation. All features, pricing, and specifications are subject to change without notice.

TASCAM SS-CDR1

Preliminary Information

RS-232

Shipping March 2008

SS-CDR1

Technical Documentation

ANELS

TASCAM SS-CDR1

TASCAM 7733 Telegraph Road Montebello, CA 90640 (323) 726-0303 http://www.tascamcontractor.com

TASCAM, a division of TEAC Corporation. All features, pricing, and specifications are subject to change without notice.

Specifications (Subject to change without notice)

Applicable Recording Media: CD-R, CD-RW, CD-R-DA, CD-RW-DA

Compact Flash

Recording Format:

MP3 Sampling Frequency 48/44.1 kHz

Data length 16-bit

Bit rate 64/128/192/256/384 kbps

WAV Sampling Frequency 48/44.1 kHz

Data length 16-bit

CD-DA Sampling Frequency 44.1 kHz

Data length 16-bit

ANALOG INPUT (Unbalance)

Connector: RCA

Input Impedance: >22kohm

Reference Input Level: -10dBv

Maximum Input Level +6dBv

ANALOG INPUT (Balance)

Connector: XLR-3-31 (1: GND, 2: HOT, 3: COLD)

Input Impedance: >22kohm

Reference Input Level +4dBu

Maximum Input Level +20dBu ( +15dBu, +18dBu, +22dBu, +24dBu)

LINE OUTPUTS (Unbalanced)

Connector: RCA

Output impedance: 200ohm

Nominal output level: -10dBV

Maximum output level: +6dBV

LINE OUTPUTS (Balanced)

Connector: XLR-3-32 (1:GND, 2:HOT, 3: COLD)

Output impedance: 100ohm

Nominal output level: +4dBu

Maximum output level: +20dBu( +15dBu, +18dBu, +22dBu, +24dBu)

HEADPHONE OUTPUT:

Connector: 1/4” Stereo Phone Jack

Maximum output level: 38.5mW+38.5mW (at 32ohm loaded)

DIGITAL INPUT

Connector: RCA

Output Impedance: 75ohm

Format: IEC60958-3

Quantization: 16-bit

DIGITAL OUTPUT

Connector: RCA

Output Impedance: 75ohm

Format: IEC60958-3

Quantization: 16-bit

RS-232C

Connector: D-sub 9 pin

Parallel Control

Connector: D-sub 25 pin

PS/2 Keyboard

Connector: PS2

Power requirements:

AC Adapter AC Input 100-240V ACV50-60Hz

Dimensions (W x H x D): 483 x 44 x 300(mm)

SPECIFICATIONS

TASCAM 7733 Telegraph Road Montebello, CA 90640 (323) 726-0303 http://www.tascamcontractor.com

TASCAM SS-CDR1
