TASCAM Model 12 1

Model 12

Checking the firmware version

Confirm the firmware version of your Model 12 before conducting a firmware update.

1. Turn the main unit on.

2. Press the MENU button to open the MENU Screen.

3. On the SYSTEM Screen, select INFORMATION to open the

Information Screen.

4. Turn the MULTI JOG dial to open the FIRMWARE screen.

5. Check the VERSION (system firmware version) on this

screen.

Updating is not necessary if the VERSION shown here is the

same or newer than the firmware version you intend to use

for the update.

NOTE

iThe screen shown above is an example. The actual

appearance will differ.

iFor details, see the“FIRMWARE screen”section of Chapter “10

– Settings and Information” in the Model 12 Owners Manual.

Firmware update procedures

1. Download the latest firmware from the TEAC Global Site

(http://teac-global.com/).

Decompress the downloaded file if it is in ZIP format or

another compressed file type.

2. Confirm that an SD card is loaded in the unit, turn the unit

on and connect it to the computer using a commercially-

available USB cable (Type-A - Type-C).

ATTENTION

The unit should be connected directly to the computer, not

through a USB hub. Moreover, noise could be picked up if the

cable is too long.

3. On the MENU Screen, select STORAGE to open the

STORAGE Screen.

4. To connect with the computer, press the F4 button.

The unit enters USB storage mode and connects with the

computer.

5. This unit appears on the computer as an external drive

named “TASCAM_M” (if the card was formatted by this unit).

Copy the downloaded firmware to the “UTILITY” folder on

“TASCAM_M”.

NOTE

The Model 12 firmware update file will have a name like

“Model12_XXXX.XXX”.

6. After copying, use the proper procedures for the computer

to unmount the unit.

See the computer’s operation manual for instructions about

how to unmount an external volume.

Press the F1 button to return to the Meter Screen.

Then, turn the unit off.

7. Turn the unit on while pressing the 8and mbuttons.

This will start the unit in update mode, and the update file

will appear on the display.

ATTENTION

iIf this screen does not appear, turn the power off once,

and turn the unit on again while pressing the 8and m

buttons. Keep pressing the 8and mbuttons until this

screen appears.

iIf the firmware was copied to the “UTILITY” folder from a Mac,

in addition to the firmware itself, another file with “._” before

the firmware name will also appear. Select the file without “._”

at the beginning.

NOTE

iThis screen shows a list of firmware update files in the

“UTILITY” folder in the unit. The firmware copied in step 5

above should also be shown.“No Update File”is shown if the

folder does not contain an update file.

iThe screen shown above is an example. The actual

appearance will differ.

0420.MA-3132A

2 TASCAM Model 12

Model 12

8. Turn the MULTI JOG dial to select the firmware, and press

the MULTI JOG dial. The screen shown below will appear.

The number of the current version is shown on the left and

the update version is shown on the right.

NOTE

The screen shown above is an example. The actual

appearance will differ.

9. Press the F4 button to start updating. (To cancel

updating, press the F1 button instead.)

CAUTION

iBe careful not to let the power be interrupted during the

update.

iDo not load or remove SD cards during the update.

iIf the power is interrupted or an SD card is loaded or removed

during the update, the unit might become unstartable.

10. When the update completes, the following message will

appear.

11. Press the POWER switch to turn the unit off. Then, turn it on

again.

12. Refer to“Checking the firmware version” and confirm that

the firmware has been updated to the latest version.

13. Connect the unit with a computer using USB, and delete

the firmware update file in the “UTILITY” folder.

This completes updating the unit.
