Safety Precaution

Warning: To reduce the risk of fire or electric shock, do not expose this

apparatus to rain or moisture.

1) Please read the instruction manual carefully and follow all the requirements

of safe operation to operate the device.

2) Do not use this unit near water. Do not place over the unit any container

with liquid inside.

3) Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including amplifiers) that produce heat.

4) Unplug this unit during lightning storms or when unused for long time.

5) About Cleaning: Unplug the system, use only wet cloth to clean. Do not use

liquid detergent or aerosol.

6) Only use accessories specified by the manufacturer.

7) Refer all servicing to qualified service personnel, servicing is required when

the unit has been damaged in any way, such as power supply cord or plug

is damaged, liquid has been spilled or objects have fallen into the unit,

exposed to moisture, does not operate normally. Don't try to repair the

machine by yourself because of the danger of high voltage and electric

shock.

8) Do not use irregular shaped discs such as heart or star-shaped discs as

they may cause the unit to malfunction.

Thank you for choosing our portable DVD player.

The unit applies the latest state of art electronics and is designed for use at

home, in hotels and in offices etc for relaxation. The compact size makes

carrying easier as well as installation. Please read the manual carefully prior

to use and keep it well for later consultation.

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful

interference, and (2) This device must accept any interference received,

including interference that may cause undesired operation.

Warning: Changes or modifications to this unit not expressly approved by the

party responsible for compliance could void the user's authority to operate the

equipment.

NOTE: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Package

Main Features

High brightness color 7" LCD screen

Compatible with disc of DVD, VCD, MP3,

Built-in stereo speaker

Support PAL/NTSC system

Support Multi-language OSD, speed forward/backward,repeat function

MPEG4, CD, JPEG, etc.

Zoom in/out function

7'' LCD Monitor & DVD Player

Remote Control with battery

DC+Audio/Video Cable

AC/DC Power Adapter

Cigarette Lighter Adapter

User Manual

Earphone

Mounting Straps

DC OUT

AV OU T

5678

ON OFF

Main Unit Controls

1. Open knob

2. Power ON/OFF switch

3. SETUP button

4. MODE button

6.OK button (Function same as

"ENTER" on Remote control)

7. Play/Pause

8. STOP button

9. DC IN 9-12V

10. DC OUT

11. AV OUT

12. Earphone jack

13. Volume knob

14. SD card slot

15. USB Port

16. Rating Label Position

Monitor View

1. Power ON/OFF

2. Volume knob

3. Earphone jack

4. AV IN

5. DC IN 9-12V

6. Brightness Knob

ON OFF

BRIGHTNESS

DC OUT

AV O U T

DC OUT

AV O U T

DC OUT

AV O U T

Plug one end of the AC/DC power adaptor into the DC IN9-12V jack on the

right of the machine, then plug the other end into the AC power receptacle.

Please refer to the following illustration.

If using car cigarette lighter adaptor to connect to the power: Plug one end of

the cigarette lighter adaptor into the DC IN 9-12V jack on the unit, plug the

other end into the car cigarette lighter socket. See illustration below.

System Connection

Powering And Installation

Note

1. Car cigarette lighter adaptor is available to use only when the car cigarette

lighter with DC 12V negative grounding.

2. The mains plug is used as the disconnect device, the disconnect device

should remain readily operable.

Using SD/MMC card

Upon using an SD or MMC card, insert it into the corresponding slot flatly with

label side upward until you hear a click.

Using USB

Upon using an USB, insert it into the USB slot directly.

Connecting To The Monitor

The unit can also be connected to the external LCD monitor.

Connect the unit to power by AC/DC adapter or cigarette lighter adapter.

Then connect the unit DC OUT jack to DC IN 9-12V Jack of the LCD Monitor

by a DC/AV cable. Also use this DC/AV cable to connect the AV OUTjack of

the unit to AV IN jack of the Monitor.

Please refer to the illustration below.

Note: You're advised to supply both units the power by the cigarette lighter

adapter only. TheAC/DC adapter is used to supply power of one unit only

and as the charger to charge the main unit if it's with built-in battery.

ON OFF

DC OUT

AV O U T

1. Fit the straps to the DVD Player / Monitor as required.

In Car Installation

Please install the units with strap A (long)

and strap B (short) together.

Turn the player around so the backs are facing you.

Strap A through the unit from right clip first, then

across the loop in Strap B, last Strap A through

the unit left clip.
