Philips PET940/98 Manuel utilisateur
PET940Portable DVD player
Register your product and get support at
www.philips.com/welcome
User manual Gebruikershandleiding
Manuale dell’utente
Användarhandbok
P001-035_PET940_05_Eng 2008.4.15 10:22 AM Page 1
2
P001-035_PET940_12_Eng 2008.4.11 5:43 PM Page 2
3
1
3
4
5
8
9
10
13
15
14
2
6
12
11
7
PUSH / OPENDVD DOOR
1
P001-035_PET940_05_Eng 2008.4.15 10:22 AM Page 3
4
2
2
5
3
4
1
6
7
8
9
10
11
12
13
14
15
16
P001-035_PET940_05_Eng 2008.4.15 10:22 AM Page 4
English
5
Content
1Control elements and functional components
1.1 Main unit controls
1.2 Remote Control
2 Introduction
2.1 Your portable DVD
player
2.2 Unpacking
2.3 Placement
2.4 Playable disc formats
2.5 Compatibility of the USB connection on this
portable DVD player
3General information
4Charging the units
4.1 Charge the DVD player
4.2 Powering your remote control
5Start up
5.1 Setup
5.2 Playback DVD
5.3 Playback VCD
5.4 Playback Super (S)-VCD
5.5 Playback Music CD
5.6 Playback Music MP3-CD
5.7 Playback Picture-CD
English
P001-035_PET940_05_Eng 2008.4.15 10:22 AM Page 5
6
English
5.8 Playback from USB
6Addition Functions
6.1 DISPLAY Menu
6.2 Connection
6.2.1 Headphone
6.2.2 TV
6.2.3 USB
7Troubleshooting
8Technical data
P001-035_PET940_05_Eng 2008.4.15 10:22 AM Page 6
English
7
1.1 Main unit controls (see figure 1)
1POWER Switch the player on / off
29Press once to stop playback and store the
stop position. Press twice to stop playback
completely.
32; Start / pause / resume playback
4J( / )K Skip to previous/next track or fast search
backward/forward
5
- VOL +
Volume control
6 OPTION Access additional functions
7 MENU Display MENU page
83,4,1,2Up / down / left / right cursor
OK Confirm selection
9POWER•IR•CHG
Power / Remote sensor / charging indicator
10 OPEN Open disc door to insert or remove disc
11 1p 2Headphones jacks
12 AV OUT Audio/Video output
13 DC IN 9-12V Power supply socket
14 USB port Insert USB plug
15 RESET Reset the player when it is hanged up
Congratulations on your purchase and wel-
come to Philips! To fully benefit from the
support that Philips offers, register your
product at www.philips.com/welcome.
1Control elements and functional components
(illustrations on page 4-5)
P001-035_PET940_05_Eng 2008.4.15 10:22 AM Page 7
8
English
1.2 Remote Control (see figure 2)
1 MENU Display MENU page
23,4,1,2Up / down / left / right navigation key
OK Confirm selection
VOL+ / -Volume control
3 DISPLAY Adjust the display value of the system
4J( Skip to previous chapter, track or title
52; Start / pause / resume playback
69Press twice to stop playback
70- 9Numeric keypad
8 SUBTITLE Subtitle language selector
9 RETURN For VCD menu page
10 A - B To repeat or loop a sequence in a title
11 SETUP Enter SETUP menu
12 OPTION Access additional functions
13 )K Skip to next chapter, track or title
14 sMute player volume
15 AUDIO Audio language selector
16 ZOOM Enlarge video image
P001-035_PET940_05_Eng 2008.4.15 10:22 AM Page 8
English
9
2.1 Your portable DVD player
Your portable DVD player plays digital video discs conforming
to the universal DVD Video standard.With it, you will be able
to enjoy full-length movies with true cinema picture quality,
and stereo or multichannel sound (depending on the disc and
on your playback set-up).
The unique features of DVD-Video, such as selection of
soundtrack and subtitle languages, and of different camera
angles (again depending on the disc), are all included.What’s
more, parental lock lets you decide which discs your children
will be able to see.You will find your player remarkably easy
to use with the On-Screen Display and player display in com-
bination with the remote control.
2.2 Unpacking
First check and identify the contents of your package, as listed
below:
•Portable DVD player • Remote Control
•Car adaptor • User manual
•AC power adaptor • Audio/Video cable
2.3 Placement
•Place the player on a firm, flat surface.
•Keep away from domestic heating equipment and direct
sunlight.
•If the player cannot read CDs/DVDs correctly, try using a
commonly available cleaning CD/DVD to clean the lens
before taking the player to be repaired. Other cleaning
methods may destroy the lens.
•Always keep the disc door closed to avoid dust on the
lens.
2 Introduction
P001-035_PET940_05_Eng 2008.4.15 10:22 AM Page 9
10
English
•The lens may cloud over when the player is suddenly
moved from cold to warm surroundings. It is then not pos-
sible to play a CD/DVD. Leave the player in a warm envi-
ronment until the moisture evaporates.
2.4 Playable disc formats
In addition to DVD-Video disc, you will also be able to play all
Video CDs, CDs, CDR, CDRW,DVD±R and DVR±RW.
2.4.1 DVD-Video
Depending on the material on the disc (a movie, video clips, a
drama series, etc.) these discs may have one or more Titles,
and each Title may have one or more Chapters.To make
access easy and convenient, your player lets you move
between Titles, and also between Chapters.
2.4.2 Video CD
Depending on the material on the disc (a movie, video clips, a
drama series, etc.) these discs may have one or more Tracks,
and tracks may have one or more indexes, as indicated on the
disc case.To make access easy and convenient, your player lets
you move between tracks and between indexes.
2.4.3 Audio CD / MP3 CD
Audio CDs / MP3 CD contain music tracks only.You can play
them in the conventional way through a stereo system using
the keys on the remote control and/or main unit, or via the
TV using the On Screen Display (OSD).
2.4.4 CD with JPEG files
You can also view JPEG still photos on this player.
P001-035_PET940_05_Eng 2008.4.15 10:22 AM Page 10
