Sylvania SDVD9000 Manuel utilisateur

TABLE OF CONTENTS

Introduction

Important Safety Instructions

Main Features

The Remote Control

Unit View

Basic Operation

The Accessories

Powering and installation

Connecting to TV or another monitor

Playing Disc

System Setup

Rechargeable battery use

Specification

Troubleshooting

Connecting with USB and SD/MMC/MS card

Introduction

Thank you for choosing our portable DVD player. It includes a 9” wide screen and a DVD

player. The unit applies the latest state of art electronics and is designed for use at home,

in hotels and in offices etc for relaxation. The compact size makes carrying easier as well

as installation. Please read the manual carefully prior to use and keep it well for future

reference .

Important safety instructions

Warning: To reduce the risk of fire or electric shock, do not expose this apparatus to rain

or moisture.

1) Please read the instruction manual carefully and follow all the requirements of safe

operation to operate the device.

2) Do not use this unit near water. Do not place over the unit any container with liquid

inside.

3) Do not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including amplifiers) that produce heat.

4) Unplug this unit during lightning, storms or when unused for long time.

5) About Cleaning: Unplug the system, use only wet cloth to clean. Do not use liquid

detergent or aerosol.

6) Only use accessories specified by the manufacturer.

7) Refer all servicing to qualified service personnel, servicing is required when the unit

has been damaged in any way, such as power supply cord or plug is damaged, liquid

has been spilled or objects have fallen into the unit, exposed to moisture, does not

operate normally. Don't try to repair the machine by yourself because of the danger

of high voltage and electric shock.

8) Do not use irregular shaped discs such as heart or star-shaped discs as they may

cause the unit to malfunction.

The Main Features

Built-in rechargeable Lithium polymer battery with easier mobile feature

Support USB card

Play MP3 files

Built-in card reader to support SD/MMC/MS

Anti-shock function

Compatibility: DVD, VCD, MP3, MPEG4, CD, JPEG,etc.

Support Multi-language OSD, speed forward/backward, repeat function

Support AV input/output

The Remote Control

1. Number button

2. TITLE ( To display title information)

3. AUDIO (To select audio language)

4. SETUP (To go to or exit setup menu)

5. Previous/Next button (To go to previous/next chapter or scene during playing)

6. Fast forward/backward button (To scan forward/backward at 2, 4, 8, 16, or 32 times )

7. OSD ( To display disc information during playing)

8. Play/Pause

Unit View

OPEN

PUSH

SETUP MENU

SD/MMC/MSUSB

-VOL+ AV IN/OUT OFF/ON

PHONE

9. Stop (First time: Stop at the present playing point; Press to continue to play

Twice: Stop playing)

10. IN/OUT (To input or output video)

11. USB/SD (To activate USB/SD function when USB/SD found)

12. Menu (To enter or exit menu page)

13. Subtitle (To select subtitle language when playing DVD disc)

14. Angle (To change viewing angle when playing disc with multi-angle)

15. A-B (Repeat a specific portion from point Ato B, press it again to cancel repeat play)

16. Repeat (To repeat playing title, chapter or track)

17. Return (To return to the main menu)

18. Zoom (To zoom in or zoom out the scene during playback)

19. VOL +/- (To adjust the volume)

20. Enter (To confirm)

“ ”

1. Power button of LCD 2. AV

3. Setup 4. Menu

5. Play/pause 6.

7. 8. Enter

9. Open 10. SD/MMC/MS port

11. USB 12. DC IN 9-12V

13.

Power

ON/OFF

Switch 14.

15. Volume 16. Earphone

AV IN/OUT

DC IN 9-12V

Basic Operation

Power On/off switch: To turn on or turn off the power

Setup: To display main menu

AV: To output to TV or input outer sources

Play/Pause: To play or pause

Open: To open the tray

: To go to previous chapter or scene during playing

: To skip to next chapter or scene during playing

: To speed forward at 2, 4, 8, 16, or 32 times

: To speed backward at 2, 4, 8, 16, or 32 times

SD/MMC/MS port: To insert SD/MMC/MS card

USB port: To connect with USB

DC IN 9-12V: To connect to AC/DC power adapter

Earphone port: to connect earphone

Volume: to adjust the volume

The Accessories

The unit includes the following accessories:

1. 1 x Remote Control with battery

2. 1 x Audio/Video Cable

3. 1 x AC/DC Power Adapter

4. 1 X Cigarette Lighter Adapter

5. 1 x Instruction Manual

6. 1 X Earphone

Powering and installation

Plug one end of the AC/DC power adaptor into the DC input jack on the right side of the

machine, then plug the other end into the AC power receptacle. Please refer to the

following illustration:

SD/MMC/MS

USB

-VOL+ AV IN/OUT

PHONE OFF/ON

DC IN 9-12V

SD/MMC/MS

USB

-VOL+ AV IN/OUT

PHONE OFF/ON

If using car cigarette lighter adaptor to connect to the power:

Plug one end of the cigarette lighter adaptor into the DC input jack on the unit, plug the

other end into the car cigarette lighter socket. See illustration below.

SD/MMC/MS

USB

-VOL+ AV IN/OUT

PHONE OFF/ON

Connecting to TV or another monitor

You can also connect the unit to a TV to enjoy high quality picture and stereo sound. Please

refer to the following illu str ati on:

Playing disc

1. After connecting power to the unit, turn on the unit with the ON/OFF switch. The power

indicator will light up.

2. Open the disc tray by "OPEN", and place a disc into the tray with the label side facing

up.

3. Close the tray. The unit will load the disc and start playing.

Playing JPG file

1. Place a JPG disc into the tray.

2. Press “ ” and “ ENTER” button to select a JPG file. To return to

main menu, press

“ ” button.

3. Preview the file selected and press “ ” or “ ENTER” to play.

4. To rotate the picture counter-clockwise, press “ ”; Press “ ” to rotate the picture

Clockwise.

DC IN 9-12V

5. Press OSD button when viewing pictures, you can select different refresh mode as

follows:

a. from top to bottom

b. from bottom to top

c. from left side to right side

d. from right side to left side

e. from left top to right bottom

f. from right top to left bottom

g. from left bottom to right top

h. from right bottom to left top

i. from horizontal center to both sides

j. from vertical center to both sides

k. from top and bottom to center.

l. from right and left to center.

m. from four window's top side to bottom side.

n. from four window's left side to right side.

o. From four edges to center.

6. During viewing files, “ ”may appear when pressing "Angle” or "Subtitle" or "Audio" or

“Repeat" or "Title" etc; in this situation these options are unavailable to operate.

7. When viewing JPG files, press “ ” pictures will be displayed in small size, press

“” or “ENTER” button to select one picture to view

Playing MP3 files

1. Place MP3 disc into the tray

2. Press “ ” to choose a MP3 file; press “ ” button to return to main menu

3. Press “ ”or “ENTER”button to play the file selected

00 36 03 43

Dir 001

\Ctyy\

......

Mp3 TRACK01

Mp3 TRACK02

Mp3 TRACK03

Mp3 TRACK04

Mp3 TRACK05

///

USB

Connecting with USB and SD/MMC/MS card

USB

You can play video/audio/picture files stored in an USB by inserting it into the USB

slot.(USB cable not included)

SD/MMC/MS card

You can play video/audio/picture files stored in SD/MMC/MS card by inserting it into the

SD/MMC/MS card slot with label side upward.(SD/MMC/MS card not included)

SD/MMC/MS

-VOL+ AV IN/OUT

PHONE OFF/ON

DC IN 9-12V

USB SD/MMC/MS

-VOL+ AV IN/OUT

PHONE OFF/ON

DC IN 9-12V

Note: Please do not disconnect USB devices or plug out SD/MMC/MS cards while they are

working with the unit. Functional failure may occur in case of wrong operations.

System Setup

Press “ Setup” button, the main menu will be displayed on the screen. Press “ Setup”

again to exit.

Enter the sub-menu, press to select option and press “ ENTER” to confirm

You can setup accordingly. But please pay attention to the followings:

1. Some features such as Angle Mark, may not be available because it's disc-dependent.

2. Last Memory only functions for AV IN/OUT.

3. Factory default password is 8888.

4. Preference Page Menu is only activated when no disc is loaded or disc door is open.

5. Audio and Subtitle languages are selectable only for discs available with the preferred

language recorded.

--GENERAL SETUP PAGE--

TV Display Wide

TV Type PAL

Angle Mark On

Screen Saver On

Last Memory Off

Go ToGeneral Setup Page

--Video Setup Page-- --Password Setup Page--

--Preference Page--

Quality

Panel Quality

Go To Video Setup Page

Password

Go To Password Setup Page

Audio Eng

Subtitle Off

Disc Menu Eng

Parental

Default

Go To Preference Page

--Preference Page--

Eng

Subtitle Off

Disc Menu Eng

Default

Audio

Set Parental Control

“ ”

OSD Lang ENG

Parental

1.KID SAF

2.G

3.PG

4.PG 13

5.PGR

6.R

7.NC17

8.ADULT
