Enforcer™Dome

Security Camera

4K Ultra HD for NVRs

Instruction Manual

Security Made Smarter

Introduction

Congratulations on the purchase of your Swann En-

forcer™ Dome Security Camera.

• 4K Upscaled Ultra HD video with sensor spot-

light plus red & blue flashing lights

• Microphone on camera helps capture extra de-

tail of what’s happening at your property

• True Detect™ Heat & Motion sensing for reli-

able alerts

• Powerful Night2Day™ color night vision

• Works in rain & snow all year round

Important instructions

1. Make sure the camera is fixed correctly and stable

if fastened in place.

2. Never place strain of any kind on the network ca-

ble connection. It’s designed to clip into the Ethernet

port, but it won’t support weight and can be broken.

3. Do not operate if wires and terminals are exposed.

Important Note: All jurisdictions have specific laws

and regulations relating to the use of cameras. Be-

fore using any camera for any purpose, it is the buy-

er’s responsibility to be aware of all applicable laws

and regulations that limit the use of cameras.

About this Manual: The content in this manual is for

information purposes only and is subject to change

without notice. While every effort is made to ensure

that this manual is accurate at the time of printing, no

liability is assumed for any errors occurred.

For instructions on how to configure your camera

for motion detection, changing image settings,

and other functions available, please consult the

manual for your NVR. Go to support.swann.com,

search for your model, then download.

Connecting the Camera2

To connect the camera to your NVR, simply connect the supplied Ethernet cable to the LAN connection on the

camera then plug the other end of the cable into one of the camera inputs on the back of your NVR.

Please note: The power connector is provided as an alternative power option if required. Your NVR will

provide power over the Ethernet cable when connected and a separate power adapter is not required.

CAM7CAM7 CAM5CAM5

CAM8CAM8 CAM6CAM6

CAM3CAM3

CAM4CAM4

CAM1CAM1

CAM2CAM2

WANWANAUDIO OUTAUDIO OUT VGAVGA

48V48V

LAN

Ethernet Cable

Power

The camera can be mounted onto a flat vertical or horizontal surface

and must be of sufficient strength to hold the camera.

Step 1: Press the button (1) to release the dome enclosure and the

dome camera from the mounting bracket.

Mounting the Camera3

Step 2: You will see a black cable (2) connected to the camera, which

in turn is connected to the camera bracket’s black cable.

Rotate the seal cap (3) clockwise and gently pull apart the connection

to disconnect. Remove the dome camera from the camera bracket.

Step 3: Position the mounting bracket in the location you want to

mount the dome camera to. Using a pencil or magic marker, mark

the mounting holes (4) and hole (5) for the camera’s cable.

Use a hole saw that you can attach to a drill to make a hole for the

cable. A large drill bit can also be used.

(continued on next page)

Step 4: Using the appropriate screws for the surface you are

mounting to, secure the bracket in place. If mounting to a wooden

surface, screw the bracket directly to the surface. If mounting to a

masonry surface (brick or concrete), you’ll need to use the supplied

wall plugs.

Step 5: Connect the supplied Ethernet cable to the camera’s cable

(see Fitting the Weather Protector to seal the connection). Reconnect

the black cable on the camera to the black cable connected to the

bracket. Rotate the seal cap anti-clockwise to tighten.

Sit the dome camera onto the camera bracket (as shown above right),

then place the dome enclosure into the camera bracket and lock it

in place. The camera can be rotated left or right (rotate the camera

bracket left or right as well) or up and down. Check the image on your

NVR and make adjustments as necessary.

Mounting the Camera4

Fitting the Weather Protector5

The weather protector provides a weather-resistant shield for the camera’s Ethernet connector to prevent

damage from moisture, dust, and other external factors that could interfere with the electrical connection. We

also recommend you seal the joins with electrical tape to ensure a more weatherproof seal.

Camera Ethernet

Connector

RJ45 Connector

Seal Tube

Rubber O-seal Foam Weather Seal

Seal Cap

Ethernet Cable

1. Place the Rubber-O-ring around the Camera

Ethernet Connector.

2. Carefully push the Ethernet Cable through the Seal

Cap and then the Seal Tube.

3. Connect the RJ45 Connector on the Ethernet Cable

to the Camera Ethernet Connector ensuring the

locking tab securely clicks in.

4. Align the lugs inside the Seal Tube to the Camera

Ethernet Connector, then rotate the Seal Tube to

lock it in place. The Rubber O-ring should become

slightly bulged when the Seal Tube has been correctly

connected.

5. Gently open the pre-cut slit of the Foam Weather

Seal and wrap it around the Ethernet Cable between

the Seal Tube and the Seal Cap. Push this into the

Seal Tube until it is almost all the way in.

6. Firmly push the Seal Cap over the end of the Seal

Tube and rotate it clockwise to screw it on to the Seal

Tube. Continue to tighten until the Foam Weather

Seal bulges slightly from the end.

Camera Location Tips6

1. Take into consideration what you want to monitor

and where you’ll get the best view of it.

2. How you’re going to connect the camera to your

monitoring system; remember that cables and con-

nections should be kept out of the weather.

3. How to keep the camera out of harm’s way. We

recommended mounting your camera at an elevated

position.

4. Place your camera as close to the area of inter-

est as practicable. The best position is from about

13ft/4m above looking slightly down, keeping in mind

the details you are looking for.

5. Although the sky looks nice when you look at the

live view from your camera, it is an unlikely direction

for an offender to approach. Make sure your camera

has minimal sky in it as the light in daylight can make

the foreground of the image darker.

6. Think about the most likely way a potential offender

may approach your home, use your camera to give

you the best coverage of these areas.

7. The camera’s casing is resistant to different weath-

er conditions and tampering. It would take an over-

whelming event to damage the housing.

8. The camera is weather and water-resistant but,

prolonged exposure to adverse weather conditions

such as sunlight and excessive moisture can damage

the internal components.

9. Run cables inside a wall cavity or other protected

enclosure, and ensure that all wiring and connectors

are insulated and protected from moisture.

10. Don’t put your cable near live electrical wiring. AC

electricity generates radio noise, which can interfere

with the signal from your camera.

M900DECAMREV1E | © Swann 2022

Helpdesk & Resources

Security Made Smarter

Visit Swann Support Center at support.swann.com. You can register

your product for dedicated customer support, download guides, find

answers to commonly asked questions, and more.

Product Registration Customer Support

Product Manuals Frequently Asked Questions

Support Community
