Swann A851 Manuel utilisateur

A851 Vari-Focal HD

Dome Security Camera

For use with Swann 4400 Series HD DVRs

INSTRUCTION MANUAL

Congratulations on your purchase of this A851

Vari-Focal HD Dome Security Camera. A highly

versatile surveillance camera with manually ad-

justable zoom and focus to suit any environment.

It has a variable focal length of 2.8 – 12mm and

offers up to 4x optical zoom on your target area.

This lets you adjust the field of view from 27° -

65° for the perfect frame. The 720p (1 Megapixel)

resolution is perfect for close up detail such as

license plates, facial detail, clothing and more.

With the latest infrared cut filter, it has amazing

night vision to 65ft/20m and excellent clarity in

low light.

Important note - All jurisdictions have specific

laws and regulations relating to the use of cam-

eras. Before using any camera for any purpose,

it is the buyer’s responsibility to be aware of all

applicable laws and regulations that prohibit or

limit the use of cameras and to comply with the

applicable laws and regulations.

Important safety instructions

1) Make sure product is fixed correctly and sta-

ble if fastened in place.

2) Do not operate if wires and terminals are ex-

posed.

3) This camera can only be used in combination

with Swann’s DVR4-4400, DVR8-4400 or DVR16-

4400 digital video recorders.

4) Use a small flat-head screwdriver to adjust the

zoom and focus settings. Do not overexert when

adjusting both settings.

Warning - Modifications not approved by the

party responsible for compliance could void us-

er’s authority to operate the equipment.

Important safety instructions.s

Introduction

Choosing a location for your Camera

With a vari-focal camera, you have some flexibility on

where the camera can be mounted. Some things to

consider when choosing a location -

1) What you want to monitor and where you’ll get the

best view of it.

2) How you’re going to connect the camera to your

DVR; remember that cables and connections should

be kept out of the weather.

3) It’s recommended to mount your cameras at an

elevated position to keep out of harm’s way.

4) Make sure your camera has minimal sky in it as

the light in daylight can make the foreground of the

image darker.

5) Think about the most likely way a potential offender

may approach your home.

6) The camera’s casing is resistant to water and

tampering. However, the cable and connector are

vulnerable and require protection.

7) Even though the camera is weather and water-

resistant, prolonged exposure to adverse weather

conditions such as sunlight or excessive moisture,

may eventually damage the internal components of

the camera and adversely affect its performance.

8) When running your cable, try to avoid bending it at

sharp angles.

9) Don’t put your cable near live electrical wiring. AC

electricity generates radio “noise” which can interfere

with the signal from your camera.

10) A vari-focal camera allows you to adjust between

its top and bottom limits on its view angle. This means

that you have the ability to manually set both the view

angle and level of zoom. Have a scenario where you

need to zoom in on a gate or other access point?

Use the 12mm setting (27° and about 4x zoom).

Need a wide angle view? Go with 2.8mm (65°). Need

something in between? Try 6mm (43°) or 9mm (30°).

Connecting your Camera

1. Connect the video output and power

input connection on the camera to the

corresponding connections on the video

& power cable.

2. Connect the video connection

on the other end of the video &

power cable to one of the video

inputs on the DVR.

3. Connect the power adapter

to the power input on the video

& power cable then connect

the power connection to a

spare wall socket.

4. Use the zoom

function to adjust the

viewing angle and

the focus function to

sharpen the image.

PTZ

75 3 1

86 4 2

eSATA

HDMI LAN & USB B A DC 12V

VGAVIDEO IN AUDIO OUT

AUDIO IN

Video & Power Cable

Power Input

Video Output

ZOOM

FOCUS

Zoom

Focus

Power Adapter

1 2

Mounting your Camera

The camera can be mounted onto a flat, vertical

or horizontal surface using the supplied mounting

screws. The surface must have sufficient strength

to hold the camera. Hardwood, brick or masonry

surfaces are recommended.

• Remove the three screws located at the base

of the camera. Position the base in the location

you want to mount it, and mark the screw holes

on the surface to position the screws. Secure

the base using the appropriate screws for the

surface you are mounting to.

• If you’re mounting to a wooden surface, screw

the base directly to the surface.

• When mounting to a masonry surface, you’ll

need to use the included wall plugs.

• Screw the camera module to the base but don’t

overly tighten each screw.

Aiming the camera:

• The dome cover can be rotated left or right.

• The camera module can be aimed in almost any

direction from wherever you choose to mount it.

• Use the zoom function to adjust the viewing

angle and the focus function to sharpen the

image.

• After you’ve finished adjusting the viewing angle,

tighten each screw to lock the camera module’s

position in place.

Positioning the cables:

• Avoid bending the cable at sharp angles.

• Avoid positioning the cable near live electrical

wiring. AC electricity generates radio noise

which can interfere with the signal from the

camera.

Limited Warranty - Terms & Conditions

Swann Communications warrants this product

against defects in workmanship and material for

a period of one (1) year from its original purchase

date. You must present your receipt as proof of

purchase for warranty validation. Any unit which

proves defective during the stated period will be

repaired without charge for parts or labour or re-

placed at the sole discretion of Swann. The end

user is responsible for all freight charges incurred

to send the product to Swann’s repair centres. The

end user is responsible for all shipping costs in-

curred when shipping from and to any country

other than the country of origin.

The warranty does not cover any incidental, acci-

dental or consequential damages arising from the

use of or the inability to use this product. Any costs

associated with the fitting or removal of this prod-

uct by a tradesman or other person or any other

costs associated with its use are the responsibility

of the end user. This warranty applies to the origi-

nal purchaser of the product only and is not trans-

ferable to any third party. Unauthorized end user

or third party modifications to any component will

render all warranties void. By law some countries

do not allow limitations on certain exclusions in

this warranty. Where applicable by local laws,

regulations and legal rights will take precedence.

For Australia: Our goods come with guarantees

which cannot be excluded under Australian Con-

sumer Law. You are entitled to a replacement

or refund for a major failure and for compensa-

tion for any other reasonably foreseeable loss or

damage. You are also entitled to have the goods

repaired or replaced if the goods fail to be of ac-

ceptable quality.

FCC Verification

This equipment has been tested and found to comply with the limits for Class B digital device, pursu-

ant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and the receiver

• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-

nected

• Consult the dealer or an experienced radio/TV technician for help

These devices comply with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) These devices may not cause harmful interference.

(2) These devices must accept any interference received, including interference that may cause unde-

sired operation.

MA851V_300315E | © Swann 2015

Helpdesk/Technical Support

Technical Support E-mail: [email protected]om

Telephone Helpdesk

USA Toll Free 1-800-627-2799

USA Parts & Warranty 1-800-627-2799

(M-F, 9am-5pm US PT)

AUSTRALIA 1800 788 210

NEW ZEALAND Toll Free 0800 479 266

UK 0203 027 0979
