USER’S MANUAL

Wireless Optical Mouse

RX-525

Silent

Wireless

Congratulations on your purchase of the SVEN PC mouse!

Please read the following instructions carefully before connecting, operating

or adjusting this product. Besides, please keep this Manual in a safe place

for future reference.

This Manual and information contained in it are copyrighted. All rights

reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this Manual more exact, some

discrepancies may occur. The information in this Manual is given on «as is»

terms. The author and the publisher do not bear any liability to a person or

an organization for loss or damage which has arisen from the information

contained in this Manual.

CONTENTS

1. SPECIAL FEATURES ..................................................

2. PACKAGE CONTENTS ................................................

3. SYSTEM REQUIREMENTS ..........................................

4. DESCRIPTION .........................................................

5. INSTALLATION .........................................................

6. TROUBLESHOOTING ................................

.................

7. TECHNICAL SPECIFICATIONS ...........................

...........

Technical support is on www.sven.ﬁ

ENG

User’s Manual RX-525 Silent

Wireless

ENG

Wireless Optical Mouse

1. SPECIAL FEATURES

•Silent buttons

•Full-sized mouse

•BlueLED advanced optical technology

• Power saving wireless technology

•Eﬀective on most surfaces

•High operating speed

•2.4GHz USB nano receiver included (range – up to 10 m)

•Two additional Forward and Back navigation buttons

•800/1200/1600 dpi resolution switch

•Power on/oﬀswitch

•USB interface

•2 AA type batteries

•Soft Touch coating

•No drivers required for Windows XP/Vista/7/8

•Natural shape of the mouse convenient for the hand

2. PACKAGE CONTENTS

•Optical mouse — 1 рс

•2.4 GHz USB nano receiver — 1 рс

•AA type batteries — 2 рсs

•User’s Мanual — 1 рс

•Warranty card — 1 рс

3. SYSTEM REQUIREMENTS

•Windows XP/Vista/7/8.

•Free USB port.

4. DESCRIPTION

aScroll wheel

bResolution switch

cAdditional Forward and Back

navigation buttons

dPower on/oﬀswitch

eOptical sensor

fBattery compartment

gNano receiver

hUSB connector

Fig. 1. Top view

Fig. 2. Bottom view Fig. 3. Nano receiver

5. INSTALLATION

•Open the cover of the mouse battery compartment f, insert two AA

type batteries into the battery compartment, matching the polarity, and

close the cover of the battery compartment (see Fig. 4).

•Pull out the nano receiver gfrom the mouse (Fig. 5) and connect it to an

available PC USB port without switching oﬀthe PC (Fig. 6).

ENG

User’s Manual RX-525 Silent

Wireless

ENG

Wireless Optical Mouse

•Turn on the mouse with the Power on/oﬀswitch d. To activate the mouse,

press any button of the mouse or turn the scroll wheel. If the mouse is

connected correctly, it will turn on automatically.

Fig. 4. Batteries installation

Fig. 5. Extraction of the receiver

from the mouse case

Fig. 6. Receiver connection

2 × AA type batteries

Battery

compartment

Battery cover

Improper installation of

batteries can result in failure

of the mouse!

ENG

User’s Manual

•After ﬁnishing your work, shift the Power on/oﬀswitch dback to the Oﬀ

position. Then take the nano receiver out of the USB port and insert it back

into the mouse. (Fig. 7).

•Do not place the receiver in a metal conﬁned space (table drawer, box,

safe), as a metal screen does not transmit radio signals.

•If the batteries run down, the mouse works in jerks. It means that the bat-

teries should be replaced with new ones, as it is shown in Fig. 4. Always

install only identical new batteries.

Fig. 7. Fitting the receiver

into the mouse case

This device meets the highest standards of energy conservation.

Use the switch don the bottom of the mouse to switch it on/off –

it will help you extend the mouse battery life.

Important

RX-525 Silent

Wireless

ENG

Wireless Optical Mouse

6. TROUBLESHOOTING

Solution

1. Make sure that the nano receiver has been

inserted into the USB port and its distance to the

mouse is less than 10 m.

2. Check if the batteries have been installed correctly.

3. Check if the batteries have run down, replace the

batteries with new ones if necessary.

4. Check the position of the switch. Shift it to the

necessary position if needed.

5. Address nearest authorized service center.

Problem

The mouse doesn’t

work.

TECHNICAL SPECIFICATIONS

Parameter, measurement unit

OS compatibility

Type of mouse

Resolution, dpi

Q-ty of buttons

Interface

Operating range, m

Dimensions, mm

Weight, g

Value

Windows XP/Vista/7/8

Wireless 2.4 GHz

800/1200/1600

5 + 1 (scroll wheel)

USB

85 × 40 × 120

Notes:

• Technical speciﬁcations given in this table are supplemental infor-

mation and cannot give occasion to claims.

• Technical speciﬁcations are subject to change without notice due to

the improvement of SVEN production.

Модель:

RX-525 Silent Wireless

Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,

РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии:

ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха

Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите

вгарантийном талоне или на сайте www.sven.ﬁ.

Гарантийный срок: 12 мес. Срок службы: 2 года.

Производитель: «СВЕН ПТЕ. Лимитед»,

176 Джу Чиат Роуд, №02-02, Сингапур, 427447.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,

№02-02, Singapore, 427447. Produced under the

control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,

Kotka, Finland, 48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.

RX-525

Silent

Wireless

Wireless Optical Mouse
