USER’S MANUAL

Wireless Optical Mouse

RX-300

Wireless

Congratulations on your purchase of the SVEN PC mouse!

Please read the following instructions carefully before connecting, operating

or adjusting this product. Besides, please keep this Manual in a safe place

for future reference.

This Manual and information contained in it are copyrighted. All rights

reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this Manual more exact, some

discrepancies may occur. The information in this Manual is given on “as is”

terms. The author and the publisher do not bear any liability to a person or

an organization for loss or damage which has arisen from the information

contained in this Manual.

CONTENTS

1. SPECIAL FEATURES ..................................................

2. PACKAGE CONTENTS ................................................

3. SYSTEM REQUIREMENTS ..........................................

4. DESCRIPTION .........................................................

5. INSTALLATION .........................................................

6. TROUBLESHOOTING ................................

.................

7. TECHNICAL SPECIFICATIONS ...........................

...........

Technical support is on www.sven.ﬁ.

ENG

User’s Manual RX-300

Wireless

1. SPECIAL FEATURES

•BlueLED advanced optical technology

•Power saving wireless technology

•Stylish ergonomic design

• Eﬀective on most surfaces

•USB nano receiver included (range up to 10 m)

•DPI resolution switch

•Resolution 600/1000 dpi

•USB interface

•Powered by 2 AAA batteries

•Long life battery-fed operation

•Drivers installation is not required for Windows XP/Vista/7/8

2. PACKAGE CONTENTS

•Optical mouse – 1 рс

•2.4 GHz USB nano receiver – 1 рс

•AAA batteries – 2 рсs

•User’s Мanual – 1 рс

•Warranty card – 1 рс

3. SYSTEM REQUIREMENTS

•Windows XP/Vista/7/8.

•Free USB port.

ENG

Wireless Optical Mouse

ON OFF

4. DESCRIPTION

aScroll wheel

bDpi resolution switch

cPower switch

dOptical sensor

eBattery compartment

fNano receiver

gUSB connector

Fig. 1. Top view

Fig. 2. Bottom view Fig. 3. Nano receiver

5. INSTALLATION

•Open the cover of the mouse battery compartment e, insert 2 AAA

batteries into the battery compartment matching the polarity, and close the

cover of the battery compartment (see Fig. 4).

•Сonnect the included nano receiver fto a free PC USB port (Fig. 5).

ENG

User’s Manual RX-300

Wireless

ON OFF

ААА batteries

Battery

compartment Battery compartment

cover

Fig. 4. Battery installation

Fig. 5. Receiver connection

Improper installation of

batteries can result in failure

of the mouse!

•Turn on the mouse with the on/oﬀswitch c(the ON position). To activate

the mouse, press any button of the mouse or turn the scroll wheel. If the

mouse is connected correctly, it will turn on automatically.

ENG

Wireless Optical Mouse

ON OFF

SVEN

ON OFF

SVEN

Fig. 6. Fitting the receiver

into the mouse case

Fig. 7. Extraction of the receiver

from the mouse case

•After ﬁnishing work

turn oﬀthe mouse with the power switch c(the OFF

position)

After this, you can pull out the receiver ffrom the PC USB port

and insert it into the mouse (Fig. 6). When using the receiver again, pull it

out from the mouse (Fig. 7) and connect it to the PC USB port again.

•Do not place the receiver into a conﬁned metal space (table drawer, box,

safe), as a metal screen does not transmit radio signals.

•If the batteries run down, the mouse works in jerks. It means that the

batteries should be replaced with new ones, as it is shown in Fig. 4. Always

install only identical new batteries.

This device meets the highest standards of energy conservation.

Use the switch con the bottom of the mouse to switch it on/off –

it will help you extend the mouse battery life.

Important

ENG

User’s Manual RX-300

Wireless

Notes:

• Technical speciﬁcations given in this table are supplemental infor-

mation and cannot give occasion to claims.

• Technical speciﬁcations are subject to change without notice due to

the improvement of SVEN production.

TECHNICAL SPECIFICATIONS

Parameter

OS compatibility

Type of mouse

Resolution, dpi

Q-ty of buttons

Interface

Dimensions, mm

Weight, g

Value

Windows XP/Vista/7/8

wireless 2.4 GHz

600/1000

3 + 1 (scroll wheel)

USB

103 × 66 × 38

6. TROUBLESHOOTING

Solution

1. Make sure that the nano receiver has been

inserted into the USB port and its distance to

the mouse is less than 10 m.

2. Check whether the batteries have been

installed correctly.

3. Check if the batteries have run down, replace

the batteries with new ones if necessary.

4. Address nearest authorized service center.

Problem

The mouse does not

work.

ENG

Wireless Optical Mouse

Модель:

RX-300 Wireless

Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,

РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии:

ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха

Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите

вгарантийном талоне или на сайте www.sven.ﬁ.

Гарантийный срок: 12 мес. Срок службы: 2 года.

Производитель: «СВЕН ПТЕ. Лимитед»,

176 Джу Чиат Роуд, №02-02, Сингапур, 427447.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,

№02-02, Singapore, 427447. Produced under the

control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,

Kotka, Finland, 48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
