USER’S MANUAL

Wireless Optical Mouse

LX-630

Wireless

ENG

User’s Manual LX-630

Wireless

Congratulations on your purchase of the SVEN PC mouse!

Please read the following instructions carefully before connecting, operating

or adjusting this product. Besides, please keep this Manual in a safe place

for future reference.

This Manual and information contained in it are copyrighted. All rights

reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this Manual more exact, some

discrepancies may occur. The information in this Manual is given on “as is”

terms. The author and the publisher do not bear any liability to a person or

an organization for loss or damage which has arisen from the information

contained in this Manual.

CONTENTS

1. SPECIAL FEATURES ..................................................

2. PACKAGE CONTENTS ................................................

3. SYSTEM REQUIREMENTS ..........................................

4. DESCRIPTION .........................................................

5. INSTALLATION .........................................................

6. TROUBLESHOOTING ................................

.................

7. TECHNICAL SPECIFICATIONS ...........................

...........

Technical support is on www.sven.ﬁ

ENG

Wireless Optical Mouse

1. SPECIAL FEATURES

•Power saving colorless sensor

• Slim and compact design suited for laptops

•2.4GHz USB nano receiver included (range – up to 10 m)

•High-precision optical technology

•Eﬀective on most surfaces

•1000/1500/2000 dpi resolution switch

•USB interface

•2 AAA type batteries

•Long life battery-fed operation

•Soft Touch coating

•No drivers required for Windows XP/Vista/7/8

•Natural shape of the mouse convenient for the hand

2. PACKAGE CONTENTS

•Optical mouse — 1 рс

•2.4 GHz USB nano receiver — 1 рс

•AAA type batteries — 2 рсs

•User’s manual — 1 рс

•Warranty card — 1 рс

3. SYSTEM REQUIREMENTS

•Windows XP/Vista/7/8.

•Free USB port.

Fig. 1. Top view

4. DESCRIPTION

aScroll wheel

bResolution switch

cIR sensor

dNano receiver

eUSB connector

fBattery compartment lock

gBattery compartment

Fig. 2. Bottom view

5. INSTALLATION

•Open the battery compartment cover by sliding the lock f(see Fig. 3).

•Insert two AAA type batteries into the battery compartment g, matching the

polarity.

Important! Improper installation of batteries can result in failure of

the mouse!

•Pull out the nano receiver dfrom the mouse (Fig. 4) and connect it to an

available PC USB port without switching oﬀthe PC (Fig. 5).

ENG

User’s Manual LX-630

Wireless

ENG

Wireless Optical Mouse

•Сlose the cover of the mouse battery compart-

ment.

•To activate the mouse, press any button of the

mouse or turn the scroll wheel. If the mouse is

connected correctly, it will turn on automatically.

•After ﬁnishing your work, take the nano recei-

ver out of the USB port and insert it back into

the mouse (Fig. 6).

•Do not place the receiver in a conﬁned metal

space (table drawer, box, safe), as a metal

screen does not transmit radio signals.

Fig. 4. Extraction of the receiver

from the mouse case

Fig. 5. Receiver

connection

Fig. 3. Opening the

battery compartment cover

This device meets the highest standards of energy conservation.

During long pauses in operation the mouse enters the economical

Sleep mode. To enter the working mode, just press any button or

scroll the wheel.

Important

•If the batteries run down, the mouse works in jerks. It means that the

batteries should be replaced with new ones. Always install only identical new

batteries.

Fig. 6. Fitting the receiver

into the mouse case

ENG

User’s Manual LX-630

Wireless

ENG

Wireless Optical Mouse

6. TROUBLESHOOTING

Solution

1. Make sure that the nano receiver has been inserted

into the USB port and its distance to the mouse is

less than 10 m.

2. Check if the batteries have been installed correctly.

3. Check if the batteries have run down, replace the

batteries with new ones if necessary.

Install the software to coordinate the mouse and

the receiver. The software can be downloaded from

Support on www.sven.ﬁ

Problem

The mouse doesn’t

work.

Batteries are in good

order, but the mouse

still does not work.

TECHNICAL SPECIFICATIONS

Parameter, measurement unit

OS compatibility

Type of mouse

Resolution, dpi

Q-ty of buttons

Interface

Operating range, m

Dimensions, mm

Weight, g

Value

Windows XP/Vista/7/8

Wireless 2.4 GHz

1000/1500/2000

3 + 1 (scroll wheel)

USB

60 × 25 × 100

Notes:

• Technical speciﬁcations given in this table are supplemental infor-

mation and cannot give occasion to claims.

• Technical speciﬁcations are subject to change without notice due to

improvement of SVEN production.

Модель: LX-630 Wireless

Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,

РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии:

ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха

Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите

вгарантийном талоне или на сайте www.sven.ﬁ.

Гарантийный срок: 12 мес. Срок службы: 2 года.

Производитель: «СВЕН ПТЕ. Лимитед»,

176 Джу Чиат Роуд, №02-02, Сингапур, 427447.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,

№02-02, Singapore, 427447. Produced under the

control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,

Kotka, Finland, 48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
