Supermicro SAS 828TQ Manuel utilisateur

Rev. 1.0a

SAS 828TQ BACKPLANE

USER'S GUIDE

C84

C5C45

JP18

JP40

JP50

JP29

JP38

JP41

JP25

JP43

JP37

JP36

JP42

JP34

JP33

JP44

JP45

JP13

JP10

JP46

JP26

JP51

J18

J10

J12

31 42

+5V+12V GNDGND

64 49

3217

131

BAR CODE

SAS828TQ

REV 1.01

SIDEBAND#1

I C#2

ACT0

ACT1

ACT5

ACT4

ACT2

ACT3

JP42:BPID_SDIN#1

JP43:BPID_SDIN#2

1-2:SGPIO

2-3:I2C

2-3:ID#1

JP34:BP_ID#1

1-2:ID#0

JP37:BP_ID#2

JP36:CTRL_ID#2

JP41:I2CRST_SDOUT#2

JP38:I2CRST#2

UPGRADE

SIDEBAND#2

JP18:BUZZER RESET

JP29:9072 RESET

JP25:OH TEMPERATURE

OPEN:45

1-2:50

2-3:55

I C#1

JP33:CTRL_ID#1

1-2:SGPIO

2-3:I2C

JP40:I2CRST_SDOUT#1

ON:SGPIO

OFF:I2C

JP50:I2CRST#1

ON:I2C

OFF:SGPIO

ACT IN

Backplane User's Guide

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of

this manual, please see our web site at www.supermicro.com.

SUPERMICRO COMPUTER reserves the right to make changes to the product described in this

manual at any time and without notice. This product, including software, if any, and documenta-

tion may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any

medium or machine without prior written consent.

IN NO EVENT WILL SUPERMICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,

INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE

OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, THE VENDOR SHALL NOT HAVE

LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE

PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING

OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all

claims will not exceed the price paid for the hardware product.

Manual Revision 1.0

Release Date: August 21, 2007

Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not

copy or otherwise reproduce/distribute any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

iii

Safety Information and Technical Speciﬁcations

Table of Contents

SAS 828TQ BACKPLANE

Contacting SuperMicro ..................................................................................................iv

Chapter 1: Safety Guidelines

1-1 ESD Safety Guidelines ................................................................................... 1-1

1-2 General Safety Guidelines .............................................................................. 1-1

1-3 An Important Note to Users ............................................................................ 1-1

Chapter 2: Jumper Settings and Pin Deﬁnitions

2-1 Front Connectors and Jumpers ........................................................................... 2-1

Front Connectors ............................................................................................ 2-1

SAS Ports ........................................................................................................ 2-1

2-2 Front Connector and Pin Deﬁnitions ............................................................... 2-2

2-3 Front Jumper Locations and Pin Deﬁnitions ................................................... 2-4

Explanation of Jumpers .............................................................................. 2-4

I2C and SGPIO Modes and Jumper Settings ................................................. 2-5

2-4 Rear Connectors and LED Indicators ............................................................. 2-6

Backplane User's Guide

Contacting SuperMicro

Headquarters

Address: SuperMicro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: +1 (408) 503-8000

Fax: +1 (408) 503-8008

Email: [email protected] (General Information)

[email protected] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: SuperMicro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: +31 (0) 73-6400390

Fax: +31 (0) 73-6416525

Email: [email protected] (General Information)

[email protected] (Technical Support)

[email protected] (Customer Support)

Asia-Paciﬁc

Address: SuperMicro, Taiwan

4F, No. 232-1, Liancheng Rd.

Chung-Ho 235, Taipei County

Taiwan, R.O.C.

Tel: +886-(2) 8226-3990

Fax: +886-(2) 8226-3991

Web Site: www.supermicro.com.tw

Technical Support:

Email: [email protected]

Tel: 886-2-8228-1366, ext.132 or 139

1-1

Safety Information and Technical Speciﬁcations

Chapter 1:

Safety Guidelines

To avoid personal injury and property damage, carefully follow all the safety steps

listed below when accessing your system or handling the components.

1-1 ESD Safety Guidelines

Electric Static Discharge (ESD) can damage electronic components. To prevent dam-

age to your system, it is important to handle it very carefully. The following measures

are generally sufﬁcient to protect your equipment from ESD.

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing a component from the antistatic

bag.

• Handle the RAID card by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the card and peripherals back into their antistatic bags when not in use.

1-2 General Safety Guidelines

• Always disconnect power cables before installing or removing any components

from the computer, including the backplane.

• Disconnect the power cable before installing or removing any cables from the

backplane.

• Make sure that the backplane is securely and properly installed on the mother-

board to prevent damage to the system due to power shortage.

1-3 An Important Note to Users

• All images and layouts shown in this user's guide are based upon the latest

PCB Revision available at the time of publishing. The card you have received

may or may not look exactly the same as the graphics shown in this manual.

1-2

Backplane User's Guide

Notes

2-1

Safety Information and Technical Speciﬁcations

C84

C5C45

JP18

JP40

JP50

JP29

JP38

JP41

JP25

JP43

JP37

JP36

JP42

JP34

JP33

JP44

JP45

JP13

JP10

JP46

JP26

JP51

J18

J10

J12

31 42

+5V+12V GNDGND

64 49

3217

131

BAR CODE

SAS828TQ

REV 1.01

SIDEBAND#1

I C#2

ACT0

ACT1

ACT5

ACT4

ACT2

ACT3

JP42:BPID_SDIN#1

JP43:BPID_SDIN#2

1-2:SGPIO

2-3:I2C

2-3:ID#1

JP34:BP_ID#1

1-2:ID#0

JP37:BP_ID#2

JP36:CTRL_ID#2

JP41:I2CRST_SDOUT#2

JP38:I2CRST#2

UPGRADE

SIDEBAND#2

JP18:BUZZER RESET

JP29:9072 RESET

JP25:OH TEMPERATURE

OPEN:45

1-2:50

2-3:55

I C#1

JP33:CTRL_ID#1

1-2:SGPIO

2-3:I2C

JP40:I2CRST_SDOUT#1

ON:SGPIO

OFF:I2C

JP50:I2CRST#1

ON:I2C

OFF:SGPIO

ACT IN

C84

C5C45

JP18

JP40

JP50

JP29

JP38

JP41

JP25

JP43

JP37

JP36

JP42

JP34

JP33

JP44

JP45

JP13

JP10

JP46

JP26

JP51

J18

J10

J12

31 42

+5V+12V GNDGND

64 49

3217

131

BAR CODE

SAS828TQ

REV 1.01

SIDEBAND#1

I C#2

ACT0

ACT1

ACT5

ACT4

ACT2

ACT3

JP42:BPID_SDIN#1

JP43:BPID_SDIN#2

1-2:SGPIO

2-3:I2C

2-3:ID#1

JP34:BP_ID#1

1-2:ID#0

JP37:BP_ID#2

JP36:CTRL_ID#2

JP41:I2CRST_SDOUT#2

JP38:I2CRST#2

UPGRADE

SIDEBAND#2

JP18:BUZZER RESET

JP29:9072 RESET

JP25:OH TEMPERATURE

OPEN:45

1-2:50

2-3:55

I C#1

JP33:CTRL_ID#1

1-2:SGPIO

2-3:I2C

JP40:I2CRST_SDOUT#1

ON:SGPIO

OFF:I2C

JP50:I2CRST#1

ON:I2C

OFF:SGPIO

ACT IN

Chapter 2:

Jumper Settings and Pin Deﬁnitions

2-1 Front Connectors and Jumpers

SAS Ports

Front Connectors

1. CD-ROM/Floppy Drive Power:

JP17 and J18

2. Upgrade Connector JP46

3. SideBand Connector#1 JP51

4. SideBand Connector#2 JP52

5. I2C Connector#1 JP44

6. I2C Connector#2 JP45

7. MG9072 CHIP

8. ACT_IN JP26

9. Power Connectors (4-pin): JP10

and JP13

10. SAS Port #0 J5

11. SAS Port #1 J6

12. SAS Port #2 J7

13. SAS Port #3 J8

14. SAS Port #4 J10

15. SAS Port #5 J12

15 13

2-2

Backplane User's Guide

2-2 Front Connector and Pin Deﬁnitions

3 and 4. Sideband Headers

The sideband headers are designated JP51

and JP52. For SES-2 to work properly, you

must connect an 8-pin sideband cable. See

the table to the right for pin deﬁnitions.

1. CD-ROM/Floppy 4-Pin Connectors

The 4-pin connectors, designated JP105

and JP106, provide power to the CD-ROM

and ﬂoppy drives. See the table on the right

for pin deﬁnitions.

CD-ROM/

FDD Power

4-Pin Connector

(JP17 and JP18)

Pin# Deﬁnition

1 +5V

2 and 3 Ground

4 +12V

5 and 6. I2C Connectors

The I2C Connectors, designated JP44 and

JP45, are used to monitor HDD activity and

status. See the table on the right for pin

deﬁnitions.

I2C Connector

Pin Deﬁnitions

(JP44 and JP45)

Pin# Deﬁnition

1 Data

2 Ground

3 Clock

4 No Connection

2. Upgrade Connector

The Upgrade connector, designated JP46, is

used for manufacturer's diagnostic purposes

only.

Sideband Headers

(JP51 and JP52)

Pin # Deﬁnition Pin # Deﬁnition

2SGPIO:

SDIN

I2C:

Backplane

Addressing

(SB5)

1 Controller ID

(SB6)

4SGPIO:

SDOUT

I2C: Reset

(SB4)

3 GND (SB2)

6 GND (SB3) 5 SGPIO:

SLOAD

I2C:SDA (SB1)

8 Backplane

ID (SB7)

7SGPIO:

SCLOCK

I2C:SCL (SB0)

10 No Connec-

tion

9 No Connection

2-3

Safety Information and Technical Speciﬁcations

8. Activity LED Header

The activity LED header, designated JP26,

is used to indicate the activity status of

each SAS drive. The Activity LED Header is

located on the front panel. For the Activity

LED Header to work properly, connect using

a 10-pin LED cable.

7. MG9072 Chip

The MG9072 is an enclosure management

chip that supports the SES-2 controller and

SES-2 protocols.

SAS Activity LED Header

Pin Deﬁnitions (JP26)

Pin # Deﬁnition Pin # Deﬁnition

1 ACT IN#0 6 ACT IN#4

2 ACT IN#1 7 ACT IN#5

3 ACT IN#2 8 Not Used

4 ACT IN#3 9 Not Used

5 Ground 10 Empty

Backplane

Main Power

4-Pin Connector

(JP10 and JP13)

Pin# Deﬁnition

1+12V

2 and 3 Ground

4+5V

9. Backplane Main Power Connectors

The 4-pin connectors, designated JP10, and

JP13, provide power to the backplane. See

the table on the right for pin deﬁnitions.

10-15. SAS Ports

The SAS ports are used to connect the SAS

drive cables. The six ports are designated

#0 - #5. Each port is also compatible with

SAS and SATA drives.

2-4

Backplane User's Guide

2-3 Front Jumper Locations and Pin Deﬁnitions

Explanation of Jumpers

To modify the operation of the backplane,

jumpers can be used to choose between

optional settings. Jumpers create shorts

between two pins to change the function

of the connector. Pin 1 is identiﬁed with

a square solder pad on the printed circuit

board. Note: On two pin jumpers, "Closed"

means the jumper is on and "Open" means

the jumper is off the pins.

Connector

Pins

Jumper

Setting

3 2 1

Jumper Settings

Jumper Jumper Settings Note

JP18 Open: Enabled

Closed: Disabled Buzzer Reset

JP25

Open:45ºC

1-2:50ºC

2-3:55ºC

Overheat Temperature

JP29 Open: Default

Closed: Reset MG 9071 Chip Reset

C84

C5C45

JP18

JP40

JP50

JP29

JP38

JP41

JP25

JP43

JP37

JP36

JP42

JP34

JP33

JP44

JP45

JP13

JP10

JP46

JP26

JP51

J18

J10

J12

31 42

+5V+12V GNDGND

64 49

3217

131

BAR CODE

SAS828TQ

REV 1.01

SIDEBAND#1

I C#2

ACT0

ACT1

ACT5

ACT4

ACT2

ACT3

JP42:BPID_SDIN#1

JP43:BPID_SDIN#2

1-2:SGPIO

2-3:I2C

2-3:ID#1

JP34:BP_ID#1

1-2:ID#0

JP37:BP_ID#2

JP36:CTRL_ID#2

JP41:I2CRST_SDOUT#2

JP38:I2CRST#2

UPGRADE

SIDEBAND#2

JP18:BUZZER RESET

JP29:9072 RESET

JP25:OH TEMPERATURE

OPEN:45

1-2:50

2-3:55

I C#1

JP33:CTRL_ID#1

1-2:SGPIO

2-3:I2C

JP40:I2CRST_SDOUT#1

ON:SGPIO

OFF:I2C

JP50:I2CRST#1

ON:I2C

OFF:SGPIO

ACT IN

C84

C5C45

JP18

JP40

JP50

JP29

JP38

JP41

JP25

JP43

JP37

JP36

JP42

JP34

JP33

JP44

JP45

JP13

JP10

JP46

JP26

JP51

J18

J10

J12

31 42

+5V+12V GNDGND

64 49

3217

131

BAR CODE

SAS828TQ

REV 1.01

SIDEBAND#1

I C#2

ACT0

ACT1

ACT5

ACT4

ACT2

ACT3

JP42:BPID_SDIN#1

JP43:BPID_SDIN#2

1-2:SGPIO

2-3:I2C

2-3:ID#1

JP34:BP_ID#1

1-2:ID#0

JP37:BP_ID#2

JP36:CTRL_ID#2

JP41:I2CRST_SDOUT#2

JP38:I2CRST#2

UPGRADE

SIDEBAND#2

JP18:BUZZER RESET

JP29:9072 RESET

JP25:OH TEMPERATURE

OPEN:45

1-2:50

2-3:55

I C#1

JP33:CTRL_ID#1

1-2:SGPIO

2-3:I2C

JP40:I2CRST_SDOUT#1

ON:SGPIO

OFF:I2C

JP50:I2CRST#1

ON:I2C

OFF:SGPIO

ACT IN

C84

C5C45

JP18

JP40

JP50

JP29

JP38

JP41

JP25

JP43

JP37

JP36

JP42

JP34

JP33

JP44

JP45

JP13

JP10

JP46

JP26

JP51

J18

J10

J12

31 42

+5V+12V GNDGND

64 49

3217

131

BAR CODE

SAS828TQ

REV 1.01

SIDEBAND#1

I C#2

ACT0

ACT1

ACT5

ACT4

ACT2

ACT3

JP42:BPID_SDIN#1

JP43:BPID_SDIN#2

1-2:SGPIO

2-3:I2C

2-3:ID#1

JP34:BP_ID#1

1-2:ID#0

JP37:BP_ID#2

JP36:CTRL_ID#2

JP41:I2CRST_SDOUT#2

JP38:I2CRST#2

UPGRADE

SIDEBAND#2

JP18:BUZZER RESET

JP29:9072 RESET

JP25:OH TEMPERATURE

OPEN:45

1-2:50

2-3:55

I C#1

JP33:CTRL_ID#1

1-2:SGPIO

2-3:I2C

JP40:I2CRST_SDOUT#1

ON:SGPIO

OFF:I2C

JP50:I2CRST#1

ON:I2C

OFF:SGPIO

ACT IN

JP18

JP25

JP37

JP43

JP36

JP41 JP38

JP42 JP29

JP40

JP33

JP34

JP50

Table des matières

Autres manuels Supermicro Matériel informatique

Supermicro

Supermicro AOC-A25G-i4SM Manuel utilisateur

Supermicro

Supermicro SBI-7127R-S6 Manuel utilisateur

Supermicro

Supermicro SuperWorkstation SYS-551A-T Manuel utilisateur

Supermicro

Supermicro SuperServer SYS-510T-M Manuel utilisateur

Supermicro

Supermicro C9Z790-CG Manuel utilisateur

Supermicro

Supermicro AOC-SLG3-4E4T Manuel utilisateur

Supermicro

Supermicro AOC-SLG3-2M2-O Manuel utilisateur

Supermicro

Supermicro BPN-SAS3-116A-N10 Manuel utilisateur

Supermicro

Supermicro AOC-SLG3-2H8M2 Manuel utilisateur

Supermicro

Supermicro SuperServer SYS-E302-12D-4C Manuel utilisateur

Supermicro

Supermicro BPN-SAS2-936EL Series Manuel utilisateur

Supermicro

Supermicro AOC-STG-i4S Manuel utilisateur

Supermicro

Supermicro BPN-SAS3-836EL Manuel utilisateur

Supermicro

Supermicro H13SSH Manuel utilisateur

Supermicro

Supermicro SuperWorkstation 5038A-I Manuel utilisateur

Supermicro

Supermicro BPN-SAS3-846EL Manuel utilisateur

Supermicro

Supermicro AOC-SLG2-2TM2 Manuel utilisateur

Supermicro

Supermicro SuperWorkstation SYS-531A-IL Manuel utilisateur

Supermicro

Supermicro BPN-SAS3-119A-N12 Manuel utilisateur

Supermicro

Supermicro SuperStorage SSG-1129P-ACR10N4L Manuel utilisateur

Supermicro

Supermicro AOC-A100G-b2CM Manuel utilisateur

Supermicro

Supermicro SuperBlade SBA-4114S-C2N Manuel utilisateur

Supermicro

Supermicro AOC-B25G-6CVL Manuel utilisateur

Supermicro

Supermicro R12SPD-A Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
