Subaru 2011 Tribeca Manuel utilisateur
Tribeca 2011
Quick Reference Guide.
782335_11_Tribeca_QRG_102010b.indd 2 10/20/10 3:07 PM
Complete U.S. specications and illustrations may
not have been available at time of publication.
Specications are based on the latest product
information available at time of publication. Some
images shown are for illustration purposes only.
Some equipment shown may be optional at
extra cost. Specic options may be available
only in combination with other options. Specic
combinations of equipment or features may vary
from time to time and by geographic area. Certain
accessories and equipment may not be available at
the time of publication.
This Quick Reference Guide applies to all Tribeca
models. Therefore, some explanations may be for
equipment not installed on your vehicle. Subaru
of America, Inc., reserves the right to change or
discontinue at any time, without notice, prices,
colors, materials, equipment, accessories,
specications, models and packages without
incurring any obligation to make the same or
similar changes on vehicles previously sold. Colors
shown may vary due to reproduction process.
For detailed operating and safety information,
please consult the Owner’s Manual.
Subaru, Outback, Legacy, Forester, Impreza,
WRX, WRX/STI, BOXER, SPORTSHIFT, SI-DRIVE,
Lineartronic, Alcantara, Circle Surround, Audyssey,
MultiEQ, XM and Sirius are registered trademarks.
All rights reserved. Contents may not be reprinted or
electronically reproduced in whole or in part without
prior written approval of Subaru of America, Inc.
© 2010 Subaru of America, Inc.
782335_11_Tribeca_QRG_102010b.indd 3 10/20/10 3:07 PM
Table of Contents
Getting Started
Instrument Panel
Gauges
Personalize
Controls
While Operating
Safety/In Case of Emergency
Additional Information
2 - 3
4 - 5
6 - 7
8 - 9
10 - 17
18 - 19
20 - 21
22 - 23
782335_11_Tribeca_QRG_102010b.indd 5 10/20/10 3:07 PM
2
Remote Keyless Entry
Lock/Arm
• Press to lock all doors
and rear gate.
• If any of the doors or the
rear gate are not fully closed,
an electronic chirp will
sound ve times and the
hazard lights will ash ve
times to alert you that the
doors or the rear gate are
not properly closed.
• To activate the vehicle nder
function, press three times
(within ve seconds). If you
are within 30 feet of the
vehicle, the horn will sound
one time and the hazard
lights will ash three times.
Unlock/Disarm
• Press once to unlock
the driver’s door.
• Press twice (within ve
seconds) to unlock all doors.
• When the “Unlock/Disarm”
button is pressed, the dome
and map lights will illuminate
if the dome light switch is in
the middle position.
Unlocking the
Rear Gate
Press to unlock the rear gate.
An electronic chirp will sound
twice and the hazard lights will
ash twice.
Panic Alarm
• Press once and the horn
will sound and the hazard
lights will ash.
• Press any button on the
remote to deactivate.
Immobilizer
When the security alarm is
activated, the immobilizer
interrupts the starter motor
to prevent an intruder from
starting your vehicle without
a registered key.
782335_11_Tribeca_QRG_102010b.indd 2 10/20/10 3:07 PM
3
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
3
Getting
Started
Seating
Power Driver’s Seat:
Memory (if equipped)
You can memorize two seat positions.
To memorize seat positions:
3. Press the “SET” button.
4. Within ve seconds after pressing the
“SET” button, press the “1” or “2” button.
A buzzer will sound one time to inform
you that the memorizing is nished.
To move the seat to a memorized position
with the vehicle selector lever in “P” (Park)
position, press either the “1” or “2” button.
The seat will move to the stored position.
Power Driver Seat:
8-way Adjust
1. Forward/Backward, Angle
and Height
Move the switch toward the front or rear
to move the seat forward or backward.
Pull the switch up or push down on the
front of the switch to adjust the angle of
the seat cushion. Pulling the switch up or
pushing down on the rear of the switch
will adjust the height of the seat cushion.
2. Seatback
Move the switch in the corresponding
direction to adjust the angle of
the seatback.
Midway Stopping Feature
for 2nd Row Seats
The 2nd row seats are equipped with
a midway stopping feature on the
sliding mechanism. Release the midway
stopping feature by pushing the lever
located on the outside of the 2nd row
seat forward and slide the seat.
Getting
Started
1
2
34
782335_11_Tribeca_QRG_102010b.indd 3 10/20/10 3:08 PM
4
Instrument Panel
pg. 10 pg. 17pg. 6-7pg. 11 pg. 8pg. 10 pg. 16
782335_11_Tribeca_QRG_102010b.indd 4 10/20/10 3:08 PM
5
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
5
pg. 12-13 pg. 14-15pg. 16 pg. 11
Instrument
Panel
782335_11_Tribeca_QRG_102010b.indd 5 10/20/10 3:08 PM
6
Gauges Immediate Attention
Trip meter A/B selection and trip
meter reset knob
Tachometer
Temperature Gauge
Caution Informational
Seatbelt warning
Front passenger
seatbelt warning
SRS airbag system
Security indicator light
Door open
Charge warning
Oil pressure warning
Brake system
Rear Differential oil
temperature warning
High beam indicator light
AT OIL TEMP warning
ABS warning
Low fuel
All-Wheel Drive warning
782335_11_Tribeca_QRG_102010b.indd 6 10/20/10 3:08 PM
7
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
Gauges
Trip meter and odometer
Speedometer
Fuel Gauge
Informational
Vehicle Dynamics
Control/Vehicle Dynamics
Control operation
Vehicle Dynamics Control OFF
CHECK ENGINE /
Malfunction indicator
Tire pressure warning light
Front passenger frontal
airbag ON
Front passenger frontal
airbag OFF
Low windshield
washer uid
Turn signals
Front fog light indicator
light (if equipped)
Headlight indicator light
Cruise Control
indicator light
Cruise control set
indicator light
SPORT mode
782335_11_Tribeca_QRG_102010b.indd 7 10/20/10 3:09 PM
8
Personalize
Steering Column
Push the lever down rmly to adjust the
vertical and lengthwise position of the column.
Firmly push the lever back up to lock the
column in place. Do not adjust while driving.
Power Exterior Mirrors
Turn knob to the “L” side to adjust the
left-hand mirror or to the “R” side to adjust
the right-hand mirror. Move the knob in the
direction you want to move the mirror,
then return the knob to the neutral position.
The mirrors can also be adjusted manually.
HomeLink® (if equipped)
Three buttons on the driver’s side sun visor
control indoor or outdoor devices (such as a
garage door) from inside your vehicle.
782335_11_Tribeca_QRG_102010b.indd 8 10/20/10 3:09 PM
