Subaru 2011 Forester Manuel utilisateur
Forester 2011
Quick Reference Guide.
784214_11a_Subaru_Forester_QRG_110410.indd 2 11/4/10 8:21 AM
Complete U.S. specications and illustrations may
not have been available at time of publication.
Specications are based on the latest product
information available at time of publication. Some
images shown are for illustration purposes only.
Some equipment shown may be optional at
extra cost. Specic options may be available
only in combination with other options. Specic
combinations of equipment or features may vary
from time to time and by geographic area. Certain
accessories and equipment may not be available at
the time of publication.
This Quick Reference Guide applies to all Forester
models. Therefore, some explanations may be for
equipment not installed on your vehicle. Subaru
of America, Inc., reserves the right to change or
discontinue at any time, without notice, prices,
colors, materials, equipment, accessories,
specications, models and packages without
incurring any obligation to make the same or
similar changes on vehicles previously sold. Colors
shown may vary due to reproduction process.
For detailed operating and safety information,
please consult the Owner’s Manual.
Subaru, Outback, Legacy, Forester, Impreza,
WRX, WRX/STI, BOXER, SPORTSHIFT, SI-DRIVE,
Lineartronic, Alcantara, Circle Surround, Audyssey
MultiEQ, HD Radio, XM and Sirius are
registered trademarks.
All rights reserved. Contents may not be reprinted or
electronically reproduced in whole or in part without
prior written approval of Subaru of America, Inc.
© 2010 Subaru of America, Inc.
784214_11a_Subaru_Forester_QRG_110410.indd 3 11/4/10 8:21 AM
784214_11a_Subaru_Forester_QRG_110410.indd 4 11/4/10 8:21 AM
Table of Contents
Getting Started
Instrument Panel
Gauges
Personalize
Controls
While Operating
Safety/In Case of Emergency
Additional Information
2 - 3
4 - 5
6 - 9
10 - 11
12 - 27
28 - 29
30 - 31
32 - 33
784214_11a_Subaru_Forester_QRG_110410.indd 5 11/4/10 8:21 AM
2
Remote Keyless Entry
Lock/Arm
• Press to lock all doors and
rear gate.
• If any of the doors or the rear
gate are not fully closed, an
electronic chirp will sound ve
times and the hazard lights will
ash ve times to alert you that
the doors or the rear gate are
not properly closed.
• To activate the vehicle nder
function, press three times
(within ve seconds). If you are
within 30 feet of the vehicle,
the horn will sound one time
and the hazard lights will ash
three times.
Unlock/Disarm
• Press once to unlock the
driver’s door.
• Press twice (within ve
seconds) to unlock all doors.
• When the “Unlock/Disarm”
button is pressed, the dome
and map lights will illuminate
if the dome light switch is in
the middle position.
Unlocking the
Rear Gate
Press the button to unlock
the rear gate.
784214_11a_Subaru_Forester_QRG_110410.indd 2 11/4/10 8:21 AM
3
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
3
Getting
Started
Seating
10-Way Power Driver’s Seat
(if equipped)
1. Forward/Backward, Angle and Height
Move the switch toward the front or rear to move
the seat forward or backward. Pull the switch up
or push down on the front of the switch to adjust
the angle of the seat cushion. Pulling the switch
up or pushing down on the rear of the switch will
adjust the height of the seat cushion.
2. Seatback
Move the switch in the corresponding direction
to adjust the angle of the seatback.
3. Lumbar
Press the front part of the switch to increase
lumbar support; press the rear part of the switch
to decrease lumbar support.
Heated Seats
(if equipped)
Press the switch in the
corresponding direction for
the desired seat temperature.
To turn off the seat heater,
slightly press in the opposite
direction of the current position.
Folding the
Rear Seat
Lower the headrests. Pull up on
the release knob on the seat side
that you want to fold down. To
return the seatback to its original
position, raise the seatback until
it locks into place and make sure
that it is securely locked.
1
2
3
Getting
Started
784214_11a_Subaru_Forester_QRG_110410.indd 3 11/4/10 8:22 AM
4
Instrument Panel
pg. 12 pg. 6-9 pg. 27pg. 28pg. 10 pg. 26pg. 12
784214_11a_Subaru_Forester_QRG_110410.indd 4 11/4/10 8:22 AM
5
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
5
pg. 14-19 pg. 20-25pg. 13
Clock
Press the “+” button to advance time or the
“–” button to reverse the time. Vehicles with a
navigation system please refer to the separate
“Operating Instructions for Navigation System.”
Instrument
Panel
784214_11a_Subaru_Forester_QRG_110410.indd 5 11/4/10 8:22 AM
6
Gauges Immediate Attention
Speedometer
Caution Informational
Seatbelt warning
Front passenger
seatbelt warning
SRS airbag system
Security indicator light
Door open
Charge warning
Oil pressure warning
Brake system
Hot coolant temperature /
Cold coolant temperature
High beam indicator light
AT OIL TEMP
(AT models)
ABS warning
Low fuel
All-Wheel Drive
(AT models)
Forester 2.5X
Forester 2.5X Premium
Forester 2.5X Limited
Tachometer
784214_11a_Subaru_Forester_QRG_110410.indd 6 11/4/10 8:22 AM
7
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
Gauges
Trip meter A/B selection and trip meter reset knob
Trip meter and odometer
Speedometer
Informational
Fuel Gauge
Vehicle Dynamics
Control/Vehicle Dynamics
Control operation
Vehicle Dynamics Control OFF
CHECK ENGINE /
Malfunction indicator
Tire pressure warning light
Front passenger airbag ON
Front passenger airbag OFF
Incline Start Assist warning
(MT models)
Turn signals
Front fog light indicator
light (if equipped)
Headlight indicator light
SPORT mode
(AT models)
Cruise control
indicator light
Cruise control set
indicator light
784214_11a_Subaru_Forester_QRG_110410.indd 7 11/4/10 8:22 AM
