Consumer Electronics/
Bluetooth® & Audio Technology
793593_11a_Bluetooth_QRG_072310.indd 2 7/23/10 11:20 AM
793593_11a_Bluetooth_QRG_072310.indd 3 7/23/10 11:20 AM
793593_11a_Bluetooth_QRG_072310.indd 4 7/23/10 11:20 AM
Table of Contents
Bluetooth Basics
Bluetooth without
Navigation System
Bluetooth with Harmon Kardon
Audio System
BlueConnect®
Bluetooth with Navigation System
Media Hub
2 - 3
8 - 11
12 - 13
14 - 21
22 -24
4 - 7
793593_11a_Bluetooth_QRG_072310.indd 1 7/23/10 11:20 AM
2
Bluetooth Basics
• The Hands-free system may not operate properly under the following conditions:
o The cell phone is turned off.
o The cell phone is not connected to the Hands-free system.
o The cell phone is not in the phone call area.
o The battery of the cell phone has run down.
o The cell phone is behind the seat or in the glove box.
o A metal material covers or touches the cell phone.
• Depending on the type of cell phone that is used, the screen on the cell phone may remain
illuminated while the ignition switch is in the “ON” position. If this occurs, consult your cell
phone manual to adjust the cell phone settings.
• Depending on the setting of the cell phone, the dial lock function may be activated after
making a call. Deactivate the automatic dial lock function of the cell phone before using the
Hands-free system. Do not perform this operation while driving.
• Depending on the type of cell phone that is used, operation and the sound volume may be
different from those of cell phones currently used.
• When the ignition switch is turned to the “LOCK/OFF” position during a call, the call may
be disconnected or continued on the cell phone depending on the type of cell phone that is
used. Note that operation of the cell phone may be necessary if the call is continued on the
cell phone.
793593_11a_Bluetooth_QRG_072310.indd 2 7/23/10 11:20 AM
3
Bluetooth Basics Bluetooth without
Navigation System
Bluetooth with
Harmon Kardon
BlueConnect Bluetooth with
Navigation System
Media Hub
• Do not speak at the same time as the other party during a call. If you and
the other party speak at the same time, it may be difcult for the other party
to hear your voice and vice versa. This is normal.
• The receiver sound volume should be set as low as possible. Otherwise,
the party you are calling may notice an undesirable echo sound.
• Speak clearly and loudly.
• Your voice may be difcult to be heard by the receiving party under the
following conditions:
o Driving on a rough road.
o Driving at a high speed.
o Driving with a window open.
o When air from the ventilator blows directly towards the microphone.
o When the sound coming from the ventilator is loud.
o When the cell phone is positioned too closely to the microphone.
• The sound quality may degrade due to the inuence of the cell phone that is
connected to the system or the circumstances of the Bluetooth network.
• When another Bluetooth device is simultaneously connected, noise may be heard
in the voice coming from the hands-free phone.
Bluetooth
Basics
793593_11a_Bluetooth_QRG_072310.indd 3 7/23/10 11:20 AM
4
Bluetooth without Navigation System
(Impreza)
Pairing Your Cell Phone
Press the phone off hook button and listen to phone prompts.
Press the talk button and name your phone.
Phone off
hook button
Phone on
hook button
Talk button
793593_11a_Bluetooth_QRG_072310.indd 4 7/23/10 11:20 AM
5
Bluetooth Basics Bluetooth without
Navigation System
Bluetooth with
Harmon Kardon
BlueConnect Bluetooth with
Navigation System
Media Hub
Press the talk button and say “conrm.”
Put your phone into Bluetooth pairing mode and pair your phone to the system using
the pass-key provided. When phone is successfully paired you will hear “The phone is
paired and ready for use.”
Pass-key will be given audibly as well as be displayed on the radio display.
Bluetooth
without
Nav. System
793593_11a_Bluetooth_QRG_072310.indd 5 7/23/10 11:20 AM
6
Press the talk button again and say the number.
Making a Call
Press phone off hook button. Press the talk button then say “Dial by number.”
793593_11a_Bluetooth_QRG_072310.indd 6 7/23/10 11:21 AM
7
Bluetooth Basics Bluetooth without
Navigation System
Bluetooth with
Harmon Kardon
BlueConnect Bluetooth with
Navigation System
Media Hub
To end the call, press the phone on hook button.
Receiving a Call
When a call comes in you will be notied. The audio system will mute and a voice
prompt will inform you. Press the phone off hook button to accept the call.
Press the off hook button to dial or press the talk button to add more numbers.
The phone will start dialing.
If you want to put the call on hold, press the phone on hook button. If you want to
decline the incoming call, press and hold the on hook button. If you want to adjust
the volume of the call, use the plus or minus switch on the steering wheel switches.
Bluetooth
without
Nav. System
793593_11a_Bluetooth_QRG_072310.indd 7 7/23/10 11:21 AM
