StarTech.com SV431DPDDUA2 Manuel utilisateur

Manual Revision: 11/21/2018

User Manual

For the latest information and specications visit

www.startech.com/SV431DPDDUA2

4-Port Dual DisplayPort 1.2 KVM Switch | 4K 60 Hz

Actual product may vary from photos

SKU#: SV431DPDDUA2

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

For the State of California

WARNING: Cancer and Reproductive Harm

www.P65Warnings.ca.gov

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

Safety Measures

• Wiring terminations should not be made with the product and/or electric

lines under power.

• Product installation and/or mounting should be completed by a certied

professional as per the local safety and building code guidelines.

• Cables (including power and charging cables) should be placed and routed

to avoid creating electric, tripping or safety hazards.

Mesures de sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit

et/ou les câbles électriques sont sous tension.

• L’installation et/ou le montage du produit doit être réalisé par un

professionnel certié et dans le respect des normes locales et du code de

construction local.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent

être placés et acheminés de façon à éviter tout risque électrique, de chute ou

de sécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでくださ

い。

• 製品の設置やマウントは、使用地域の安全ガイドラインおよび建築基準に

従い、有資格の専門業者が行うようにしてください。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し

を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

にしてください。

Misure di sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le

linee elettriche sotto tensione.

• L’installazione e/o il montaggio dei prodotti devono essere eseguiti da un

tecnico professionale certicato che conosca le linee guida locali sulle norme

edilizie e sulla sicurezza.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati

e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o

pericoli per la sicurezza.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller

elledningarna är strömförda.

• Installation och/eller montering får endast göras av behöriga yrkespersoner

och enligt gällande lokala förordningar för säkerhet och byggnormer.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så

sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

Warning Statements

• Make sure to assemble this product according to the instructions. Failure to

do so might result in personal injury or property damage.

• Never use this product if parts are missing or damaged.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................1

Safety Statements..................................................................................3

Warning Statements..............................................................................4

Product Diagram (SV431DPDDUA2) ...................................................6

Front............................................................................................................................................................... 6

Back................................................................................................................................................................ 6

Package Contents...................................................................................7

Requirements .........................................................................................7

Installation ..............................................................................................7

Setting Up a PC .......................................................................................................................................... 7

Connect the console to the KVM switch........................................................................................... 8

Connect a computer to the KVM switch........................................................................................... 8

Auto Scan ................................................................................................10

Hotkey Commands.................................................................................10

About the LED Indicators......................................................................11

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram (SV431DPDDUA2)

Front

Back

Port LEDs

(4) Power LED

Port Select

Buttons (4)

Console

DisplayPort

Ports (2)

DisplayPort

Ports (8)

Power

Port

Console

Audio

Ports

USB Hub

Port (2)

PC USB

Port

PC Audio

Ports

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Package Contents

• 1 x KVM Switch

• 1 x Universal Power Adapter (NA/JP, EU, UK, ANZ)

• 4 x Rubber Feet

• 1 x Quick-Start Guide

Requirements

Requirements are subject to change. For the latest

requirements, please visit www.StarTech.com/SV431DPDDUA2.

• DisplayPort Cables

• USB-A to USB-B or USB-C to USB-B Cables

• 3.5 mm Audio Cables

• Computer System or Video Card with DisplayPort

• Computer System with USB

• Display Devicewith DisplayPort (Monitor, Projector, TV, etc.)

• USB Keyboard

• USB Mouse

Installation

Setting Up a PC

• In Standard CMOS, set Halt on Error to All But Keyboard.

• In PNP and PCI Setup, set PNP OS Installed to Yes.

• In PNP and PCI Setup, set USB IRQ to Enabled.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Connect the console to the KVM switch

1. Turn o your computer and any devices or peripherals that

are connected to it (for example, printers, external hard

drives, and so on).

2. Connect two monitors or displays to the Console DisplayPort

ports.

3. Do one of the following:

• Connect a keyboard and a mouse to the Console keyboard

and Console mouse ports.

• If you’re using a combination wireless keyboard and

mouse, connect the wireless receiver to the Console

keyboard port.

4. If necessary, do any of the following:

Connect speakers to the Console speaker port.

• Connect a microphone to the Console microphone port.

• Connect USB peripherals to the USB hub ports.

Connect a computer to the KVM switch

Notes: No software or driver installation is required.

The cables for each individual computer must be connected

to the same port set on the KVM switch.

1. Turn o the computers that you want to connect to the KVM

switch and any devices or peripherals that are connected to

the computers (for example, printers, external hard drives,

and so on).

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

2. Connect a DisplayPort video cable to each of the DisplayPort

ports on your computer and to the PC DisplayPort ports of

the same set, on the KVM switch.

3. Connect a USB cable to the USB port on the computer and to

the PC USB port on the KVM switch.

4. If you’re using audio, connect speakers to the Console

speaker port and your microphone to the Console

microphone port on the KVM switch.

5. To connect additional computers, repeat steps 1 to 4.

6. If you want to share USB peripherals between connected

computers or devices, connect the peripherals to the USB

hub ports on the KVM switch.

7. Connect the universal power adapter to a power source and

to the Power adapter port on the KVM switch. The Power LED

illuminates to conrm the switch is receiving power.

8. Turn on any devices or peripherals that are connected to

the KVM switch, then turn on the connected computer.

Wait for the computer to nish loading and then test the

functionality of the keyboard and mouse of the connected

computer.

9. If additional computers are connected to the KVM switch,

select a dierent port and repeat step 8 until you have tested

the functionality of all of the connected computers.
