StarTech.com RK419WALVS Manuel utilisateur

Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 08/30/2011

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1xRKx19WALVSwallmountrack

• 16x#10-32CageNutsandScrews(RK419WALVS)

• 24x#10-32CageNutsandScrews(RK619WALVS)

• 1xSetofkeys

• 1xInstallationGuide

RK419WALVS / RK419WALVSGB

RK619WALVS / RK619WALVSGB

4U/6U 19in Secure Horizontal Wall-Mountable Server Rack with Fans

Installation

1. Toaxthewall-mountableracktoawall,thereare4anchor

pointsontherear.Openuptheenclosedrackbyunlockingthe

sidelockwiththeprovidedkey,thenreleasingthesidelatch.

*RK419WALVS shown

Thetwohalvesoftherackshouldnowswingaparthorizontally

viathesidehinges.Allfouranchorpointsshouldnowbeeasily

accessible.

2. Usetheappropriatescrewsorboltsformountingheavy

equipmenttothespecictypeofwall/surface.Pleaseobserve

propersafetyproceduresandusetheappropriatetools.

3. Oncesecurelyfastenedtoawall/surface,equipmentcanbe

mountedintotherack.Somecagenutsandscrewsareprovided

formountingequipmentintotherack.Cables,includingthe

powercableforthecoolingfans,canberoutedthroughthe

bottom/rearoftherack.

Additionalcagenutsandscrewscanbepurchasedfrom

www.startech.com.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)

towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall

trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.

Technical Support

StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess

ourcomprehensiveselectionofonlinetools,documentation,anddownloads.

Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads

Warranty Information

Thisproductisbackedbyalifetimewarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned

forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom

misuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,

consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow

theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.

Specications

RK419WALVS RK619WALVS

Description 4U19inSecureHorizontalWall-

MountableServerRackwithFans

6U19inSecureHorizontalWall-

MountableServerRackwithFans

Material SPCC

Color Black

Mounting Holes Square

Cooling Fans 2x120mm

Fan Air Flow Rate 92CFM

Fan Noise 42dBa

Maximum Weight Capacity 68kg

Available Internal Height 4U 6U

External Dimensions

(WxDxH) 643.0mmx725.0mmx224.0mm 643.0mmx725.0mmx308.0mm

Net Weight 20.12kg 22.52kg

Standards EIARS-310D

Certications UL,CE,RoHS

4. Thetopcovercanbeopenedviakey,asaquickwaytocheckthe

statusofequipmentinsidetherackorjustextraventilation.
