StarTech.com PCI1PECP Manuel du système

1 Port PCI Parallel Adapter Card

StarTech ID: PCI1PECP

This high performance PCI based EPP/ECP parallel adapter card can be installed in a computer PCI slot to add

one IEEE 1284 parallel port to your PC. A cost-effective way to connect parallel devices to the computer, with data

transfer speeds of up to 1.5 Mbps (up to 3 times faster than on-board parallel ports).

The adapter card supports EPP, ECP, SPP and BPP parallel communications, and is simple to install in virtually

any PC. The card supports Windows® Vista, XP, ME, 2000, 98, 95, NT4, DOS® and Linux®, plus IRQ sharing and

plug and play capabilities guarantee convenient, hassle-free connections to any parallel peripheral.

A complete dual profile solution, the PCI parallel adapter card provides both standard bracket and low profile/half-

height brackets for adapting to slimline or small form factor system applications.

Backed by a StarTech.com Lifetime warranty and free lifetime technical support.

Applications

Connects any parallel peripheral including printers, scanners, CD-R/RWs, Zip® drives, and memory card

readers

Features

Supports EPP, ECP, SPP and BPP

Standard and low profile bracket included

Data transfer rates of up to 1.5 Mbps

IRQ sharing eliminates conflicts between multiple cards

Easy plug and play installation

Installation scripts available for Linux RedHat 7.2, SuSE 7.3 and Mandrake 8.2

intrl.startech.com

Technical Specifications

Warranty Lifetime

Ports 1

Bus Type PCI / PCI-X (5 / 3.3V)

Card Type Standard Profile (LP bracket incl.)

Port Style Integrated on Card

Industry Standards BPP

Industry Standards ECP

Industry Standards EPP

Industry Standards PCI 2.2

Industry Standards SPP

Chipset ID ASIX/MosChip - MCS9805CV

Connector Type(s) 1 - PCI / PCI-X (Universal 3.3 & 5V; 32-bit) Male

External Ports 1 - DB-25 (25 pin; D-Sub) Female

Maximum Data Transfer Rate 1.5 Mbps

OS Compatibility Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64), 2000, ME, NT, 98, 95

Linux

Microsoft WHQL Certified Yes

Product Length 4.7 in [120 mm]

Product Width 0.8 in [20 mm]

Product Height 4.7 in [120 mm]

Product Weight 2.1 oz [60 g]

Shipping (Package) Weight 0.3 lb [0.1 kg]

Included in Package 1 - 1 Port PCI Parallel Card

Included in Package 1 - Low-Profile PCI bracket

Included in Package 1 - Driver CD

Included in Package 1 - Instruction manual

intrl.startech.com

Certifications, Reports and Compatibility

intrl.startech.com
