StarTech.com PCI1394B_3 Manuel utilisateur

PCI FireWire 800 Card

PCI1394B_3 Instruction Manual

Actual product may vary from photo

3 Port IEEE-1394B FireWire 800 PCI Card with Multiple Connector Support

and Digital Video Editing Kit

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing the Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing the Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing and Using Your VideoStudio Software . . . . . . . . . . . . . . . . . . . . . .2

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com FireWire 800 card. Now you don’t have to

worry about having the right kind of FireWire port or fumbling with adapters for your

devices: this card features 9-pin FireWire 800 ports, as well as a 6-pin FireWire 400 port

to support the the full range range of FireWire devices. For even greater flexibility, this

card allows you to use your existing FireWire 400 devices while taking advantage of the

new 800 Mbits/sec. speed of the FireWire 800 standard for new devices.

Features

• Supports the FireWire 800 standard for the next generation of FireWire devices.

• Built-in ports for a range of FireWire connections: 6-pin (FireWire 400) and 9-pin

(FireWire 800).

• Fully Plug and Play compatible for easy installation.

• Includes Ulead VideoStudio software for a complete video editing solution.

Before You Begin

Package Contents

1 x FireWire 800 PCI Card

1 x FireWire 9-pin to 6-pin cable

1 x Installation CD

1 x Instruction Manual

1 x Ulead VideoStudio Software CD

System Requirements

• OS Support: Windows 98SE/ME/2000/XP or MacOS 8.6+ (supports FireWire 400

standard only), MacOS X 10.2.4+ (supports FireWire 400 and 800)

• An available PCI slot (supports 32 and 64-bit, and 3.3v and 5v interfaces)

Note: A 64-bit PCI slot is required for a 800 Mbits/sec. data transfer rate

• Optical drive (CD or DVD-ROM) for software installation

Instruction Manual

Installation

WARNING! PCI cards, like all computer equipment, can be severely damaged by static

electricity. Be sure that you are properly grounded before opening your computer case or

touching your PCI card. StarTech.com recommends that you wear an anti-static strap

when installing any computer component. If an anti-static strap is unavailable, discharge

yourself of any static electricity build-up by touching a large grounded metal surface

(such as the computer case) for several seconds. Also be careful to handle the PCI card

by its edges and not the gold connectors.

Installing the Card

1. Make sure that your computer power cord is unplugged and you are grounded.

2. Remove the cover of your system (see your computer's user manual for details, if

necessary) and gently turn your computer onto its side.

3. Locate an empty PCI slot (usually white in color; a 64-bit slot will be longer than a

32-bit slot) and remove the metal plate that covers the rear bracket. You may need a

Phillips screwdriver to perform this step. Retain this screw! You will need it to

secure the card later.

4. Gently insert the card into the empty slot, making sure it is firmly seated.

NOTE: If you are using the PCI1394B_3 card in a 32-bit slot, make sure that the

exposed end of the card is not in contact with any conducting parts on your

motherboard. Not all motherboards allow 64-bit cards to fit into 32-bit slots.

5. Secure the card in place using the screw you removed in Step 3.

6. Put the computer case back on.

Installing the Drivers

Windows (all versions)

Insert the driver CD into your CD-ROM or other optical drive. Go to My Computer and

double click the icon that represents your CD drive. Double click the ubCorexxx.exe file.

When prompted, choose the Typical Install option. Follow the on-screen prompts until

you receive a message stating the installation is complete.

MacOS users

Your operating system includes support for the FireWire card without the installation of

additional software, with the limitations noted under “System Requirements” on page 1.

The operating system will automatically detect and configure the FireWire card.

Installing and Using Your VideoStudio Software

For detailed instructions on the installation and use of the digital editing software, consult

the Ulead VideoStudio manual available on the CD. From My Computer right click the

icon for your CD-ROM or other optical drive and select Explore. Open the Manual

folder and select your language. (Note: To view the manual, you will need Adobe Acrobat

Reader, which is available as a free download from the Adobe Web site,

www.adobe.com.) StarTech.com recommends carefully reading the instructions supplied

by Ulead before attempting to install or use the software.

Instruction Manual

Specifications

*The card must be placed in a 64-bit PCI slot for a 800 Mbits/sec. data transfer speed.

In a 32-bit PCI slot, the card defaults to 400 Mbits/sec. as the data transfer speed for all

attached peripherals, including FireWire 800 devices.

Accessory Products from StarTech.com

Contact your local StarTech.com dealer or visit www.startech.com for cables or other

accessories that will help you get the best performance out of your new product.

10 ft 1394b FireWire Cable 9-4 Pin M-M

1394_94_10

6 ft 1394b FireWire Cable 9-4 Pin M-M

1394_94_6

10 ft 1394b FireWire Cable 9-6 Pin M-M

1394_96_10

6 ft 1394b FireWire Cable 9-6 Pin M-M

1394_96_6

10 ft 1394b FireWire Cable 9-9 Pin M-M

1394_99_10

6 ft 1394b FireWire Cable 9-9 Pin M-M

1394_99_6

Instruction Manual

Form Factor/Interface PCI 32-bit or 64-bit (full size)

3.3v or 5v compatible

PCI standard ver. 2.2 compliant

Standards Supported FireWire 400 (IEEE 1394A)

FireWire 800 (IEEE 1394B)

Maximum Data Transfer Speed 400 Mbits/sec. (FireWire 400)

800 Mbits/sec.* (FireWire 800)

Connectors 1 x FireWire 6-pin female (FireWire 400)

2 x FireWire 9-pin female (FireWire 800)

Cables Included 1 x FireWire 9-pin to 6-pin (male/male)

Regulatory Certifications FCC Class B, CE, UL

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

Warranty Information

This product is backed by a lifetime warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Instruction Manual

Revised: 18 August 2004 (Rev. B)
