StarTech.com PCIIDE2 Manuel du système

2 Port PCI IDE Controller Adapter Card

StarTech ID: PCIIDE2

This 2 Port IDE (Ultra ATA/133) Controller Card can be installed in a PCI slot, to add more IDE storage capability to

your PC.

Providing two IDE drive channels with support for two drives per channel and data transfer rates of up to 133 MBps,

this adapter card can act as the primary boot device and replace built-in IDE ports, or provide 2 additional high-

speed ports to the system. Designed to perform with high-speed IDE/133 drives, the adapter card also supports

100 MBps hard drives, 66 MBps hard drives, 33 MBps hard drives, CD-ROMS, CDRW drives, and other ATA

peripherals.

To ensure hassle-free installation, the IDE Controller Card includes Bus-Master drivers for Windows 98/ME/NT

4/2000/XP and Vista™.

Applications

Replace a failed IDE port on the motherboard

Connect legacy hard drives, CD/DVD drives, ZIP drives, etc to a newer computer system

Features

Two dual channel IDE connectors

Support for up to Ultra ATA/133 hard drives with transfer rates up to 133 MBps

28-bit LBA

Compliant with PCI specification revision 2.2

intrl.startech.com

Technical Specifications

Warranty Lifetime

Interface IDE

Ports 2

Bus Type PCI / PCI-X (5 / 3.3V)

Card Type Standard Profile

Industry Standards ATA/ATAPI-6

Chipset ID ITE - IT8212F

Connector Type(s) 1 - PCI / PCI-X (Universal 3.3 & 5V; 32-bit) Male

Internal Ports 2 - IDE (40 Pin; EIDE/PATA) Male

Maximum Data Transfer

Rate

133 MBps

LBA support 28-bit

Max Drive Capacity Up to 132 GB

OS Compatibility Windows 98SE/ ME/ 2000/ XP (32/64-bit)/ Server 2008 R2/ Vista (32/64-bit)/ 7 (32/64-

bit)/ 8 (32/64-bit)

Linux

Product Length 4.7 in [120 mm]

Product Width 0.7 in [18 mm]

Product Height 3.3 in [85 mm]

Product Weight 2.6 oz [73 g]

Shipping (Package)

Weight

0.5 lb [0.2 kg]

Included in Package 1 - 2 Port IDE PCI Controller Card

Included in Package 1 - IDE Cable

Included in Package 1 - Driver CD

Included in Package 1 - Instruction Manual

intrl.startech.com

Certifications, Reports and Compatibility

intrl.startech.com
