StarTech.com PCI1394_4 Manuel utilisateur

Manual Revision: 01/30/2012

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

For the most up-to-date information, please visit: www.startech.com

PCI1394_4

4 Port PCI 1394a FireWire Card

with Video Editing Kit

*actual product may vary from photos

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com.

Where they occur these references are for illustrative purposes only and do not represent an

endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to

which this manual applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges

that all trademarks, registered trademarks, service marks, and other protected names and/or

symbols contained in this manual and related documents are the property of their respective

holders.

Instruction Manual i

Table of Contents

Introduction........................................................................................................................................................1

Packaging Contents ................................................................................................................................1

System Requirements ............................................................................................................................1

Installation............................................................................................................................................................2

Hardware Installation..............................................................................................................................2

Driver Installation......................................................................................................................................2

Installing and Using Your VideoStudio Software...................................................................2

Specications.....................................................................................................................................................3

Technical Support...........................................................................................................................................4

Warranty Information....................................................................................................................................4

Instruction Manual 1

Introduction

This card allows you to instantly connect your video camera, image scanner, digital still

camera, or any other IEEE-1394a FireWire device to your PC. With the included Ulead®

VideoStudio®digital editing software, you can easily edit video sequences.

Packaging Contents

• 1 x PCI FireWire card

• 1 x FireWire 4 to 6-pin cable

• 1 x ULEAD VideoStudio Software CD

• 1 x Instruction Manual

System Requirements

• Available Full Prole PCI expansion slot

• Windows 2000/ XP(32/64-bit)/ Server 2003(32/64-bit)/ Vista(32/64-bit)/ 7(32/64-bit), or

Mac OS 8.6 and up, or Linux

Instruction Manual 2

Installation

WARNING! PCI cards, like all computer equipment, can be severely damaged by static electricity.

Be sure that you are properly grounded before opening your computer case or touching your PCI

card. StarTech.com recommends that you wear an anti-static strap when installing any computer

component. If an anti-static strap is unavailable, discharge yourself of any static electricity build-

up by touching a large grounded metal surface (such as the computer case) for several seconds.

Also be careful to handle the PCI card by its edges and not the gold connectors.

Hardware Installation

1. Turn your computer o and any peripherals connected to the computer (ie. Printers, external

hard drives, etc.). Unplug the power cable from the rear of the power supply on the back of

the computer.

2. Remove the cover from the computer case.

3. Locate an open PCI or PCI-X slot and remove the metal cover plate on the rear of the

computer case.

4. Insert the card into the open PCI or PCI-X slot and screw the bracket to the rear of the case.

5. Place the cover back onto the computer.

6. Insert the power cable into the socket on the power supply.

Driver Installation

Windows 2000/XP/Server 2003/Vista, Mac OS X

No driver installation is required for these operating systems, as this FireWire card is natively

supported, so the drivers are already installed.

Installing and Using Your VideoStudio Software

For detailed instructions on the installation and use of the digital editing software, consult the

Ulead VideoStudio manual available on the CD or contact Ulead Systems (www.ulead.com).

Instruction Manual 3

Specications

Host Interface 32-bit PCI v2.1 (5V)

Form Factor Full Prole

Chipset VIA VT6306

FireWire Specication IEEE1394a-2000

External Connectors 3 x 6-pin FireWire port

Internal Connectors 1 x 6-pin FireWire port*

Maximum Data Transfer Rate 400 Mbps

Compatible Operating Systems Windows 2000/XP/Server 2003/Vista/7,

Mac OS 8.6 or later

* The internal port and top external port cannot be used at the same time. Only one or the other is

active at a time.

Instruction Manual 4

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for

the periods noted, following the initial date of purchase. During this period, the products may

be returned for repair, or replacement with equivalent products at our discretion. The warranty

covers parts and labor costs only. StarTech.com does not warrant its products from defects or

damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers,

directors, employees or agents) for any damages (whether direct or indirect, special, punitive,

incidental, consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss,

arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If

such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
