StarTech.com PEX1000SFP2 Manuel utilisateur
Manual Revision: 07/03/2014
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
PEX1000SFP2
PCI Express Gigabit Ethernet Fiber Network
Card with Open SFP Slot
*actual product may vary from photos
Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.
Instruction Manual
i
Table of Contents
Product Overview ..................................................................................1
Card................................................................................................................................................................ 1
Jumper.......................................................................................................................................................... 1
Introduction............................................................................................2
Packaging Contents ................................................................................................................................. 2
System Requirements.............................................................................................................................. 2
Installation .............................................................................................2
Hardware Installation .............................................................................................................................. 2
Driver Installation...................................................................................................................................... 3
Verifying Installation................................................................................................................................ 5
Connecting to a Network......................................................................7
Network Conguration ........................................................................................................................... 7
Card to Card Direct Conguration ...................................................................................................... 8
LEDs..........................................................................................................9
Specications..........................................................................................9
Technical Support ..................................................................................11
Warranty Information............................................................................11
Instruction Manual
1
Product Overview
Card
Jumper
SFP Slot
Link LED
Activity LED
JP2 Jumper
JP2 Jumper
Note: See the “Card to Card Direct Conguration” section on the following pages for
further details on jumper conguration.
Instruction Manual
2
Introduction
Packaging Contents
• 1x 1 Port PCI Express Gigabit SFP Network Card
• 1x Low Prole Bracket
• 1x Driver CD
• 1x Instruction Manual
System Requirements
• PCI Express enabled computer with an available PCI Express slot
• Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64), Windows Server®
2012, 2008 R2, 2003, Mac OS 10.5 and up (Tested up to 10.9), Linux 2.4.x, 2.6.x and
3.5.0, Microsoft Hyper-V®
Installation
Hardware Installation
WARNING! PCI Express cards, like all computer equipment, can be severely damaged
by static electricity. Be sure that you are properly grounded before opening your
computer case or touching your PCI Express card. StarTech.com recommends that you
wear an anti-static strap when installing any computer component. If an anti-static
strap is unavailable, discharge yourself of any static electricity build-up by touching a
large grounded metal surface (such as the computer case) for several seconds. Also be
careful to handle the PCI Express card by its edges and not the gold connectors.
1. Turn your computer o and any peripherals connected to the computer (i.e. Printers,
external hard drives, etc.). Unplug the power cable from the rear of the power
supply on the back of the computer and disconnect all peripheral devices.
2. Remove the cover from the computer case. See documentation for your computer
system for details.
3. Locate an open PCI Express slot and remove the metal cover plate on the rear of the
computer case (Refer to documentation for your computer system for details).
NOTE: This card will work in PCI Express slots of additional lanes (i.e.x4, x8, or x16
slots).
Instruction Manual
3
4. Gently insert the card into the open PCI Express slot and fasten the bracket to the
rear of the case.
NOTE: If installing the card into a small form factor/low prole system, replacing the
pre-installed full prole bracket with the included low prole installation bracket
may be necessary.
5. Place the cover back onto the computer case.
6. Insert the power cable into the socket on the power supply and reconnect all other
connectors removed in Step 1.
Driver Installation
Windows
NOTE: The card may auto-install using native drivers, however it is recommended to
use the procedure below to update to the latest driver version.
1. Upon starting Windows, if the Found New Hardware dialog appears on the screen,
cancel/close the window and insert the included Driver CD into the computer’s CD/
DVD drive.
2. If AutoPlay is enabled, select the “Open folder to view les” option when the dialog
appears.
3. Open the “PEX1000MMSC2_SFP2_Driver” folder, and run the “Setup.exe” application
within the appropriate Operating System folder for the system you are using.
Instruction Manual
4
4. If AutoPlay is disabled, browse to your CD/DVD drive, open the “PEX1000MMSC2_
SFP2_Driver” folder, and run the “Setup.exe” application within the appropriate
Operating System folder for the system you are using.
5. Follow any on-screen instructions to complete the software installation.
NOTE: You may be prompted to restart your system.
Mac OS
1. Insert the provided CD into your DVD/CD-ROM drive.
2. For OS 10.7 and up, browse to the “\PEX1000MMSC2_SFP2_Driver\MacOS\MacOS
10.7\Packages” folder on the disc and then run the “dstroot.pkg” application to start
the install.
Instruction Manual
5
NOTE: For OS 10.4-10.6, please run the appropriate“.pkg” application from the
applicable OS version folder for the system you are using.
3. Follow the on-screen instructions to complete the installation.
Verifying Installation
Windows
1. From the main desktop or start menu, right-click on “Computer” (“My Computer” in
XP), then select “Manage.”
2. In the Computer Management window, select “Device Manager” from the left
window panel. Windows 8.1 users can right click on the “Start” button and click
“Device Manager.”
Instruction Manual
6
3. Under the Network Adapters category should be a “Realtek PCIe GBE Family
Controller” device. “Right-click” on the device and select “Properties” to make sure it
is installed and working correctly.
Mac OS
1. Open the “System Proler” by clicking the Apple symbol in the top left corner, select
“About this Mac”, then select “More Info.”
2. On the next screen, select “System Report” and under the“Ethernet Cards” heading
within the “Hardware” category should be an “ethernet” device.
Instruction Manual
7
Software Utility
The PCI Express Fiber Gigabit Ethernet Adapter also includes an optional monitoring
and maintenance software utility. Run the “setup.exe” le located within the
“PEX1000MMSC2_SFP2_Utility” folder on the included CD to provide access to
conguration settings as well as testing and reporting statistics.
Connecting to a Network
Network Conguration
For connector type, cabling requirements, and maximum segment distance when
connecting the PCI Express Gigabit Ethernet Adapter to your network, please refer to
the following table:
Speed Connector
Port Speed
Half/Full
Duplex
Cable Max. Distance
1000Base-SX SC, LC 2000 Mbps MMF (62.5μm) 220 m
2 km
1000Base-SX SC, LC 2000 Mbps MMF (50μm) 550 m
1000Base-LX SC, LC 2000 Mbps SMF(9, 10μm) 10, 20, 50 km
1000Base-BX SC, LC 2000 Mbps SMF(9, 10μm) 20, 40 km
