StarTech.com ST121HDBTE Manuel utilisateur

Manual Revision: 02/24/2015

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

ST121HDBTE

HDMI® over Cat 5e/6 Extender - 70m

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View – Transmitter/Receiver Unit............................................................................................. 1

Rear View – Transmitter/Receiver Unit .............................................................................................. 1

Introduction............................................................................................2

Packaging Contents ................................................................................................................................. 2

System Requirements.............................................................................................................................. 2

Installation ..............................................................................................3

Preparing Your Site ................................................................................................................................... 3

Hardware Installation .............................................................................................................................. 3

Specications..........................................................................................4

Technical Support ..................................................................................5

Warranty Information............................................................................5

Instruction Manual

Front View – Transmitter/Receiver Unit

Transmitter Unit

Receiver Unit

Rear View – Transmitter/Receiver Unit

1. HDMI® IN

2. Status LED

1. Power Jack

2. LINK (RJ-45 Connector)

1. HDMI® OUT

2. Status LED

1. Power Jack

2. LINK (RJ-45 Connector)

11 2 2

Product Diagram

LED Indicator

Unit / LED Status

Power On Link OK No video source or monitor connected

Tx Green Blue Flashing Blue & Green

Rx Red Blue Flashing Blue & Red

Instruction Manual

Introduction

The ST121HDBTE HDMI® over CAT5e/6 Video Extender kit lets you extend HDMI video

and audio up to 230 feet (70 Meters) over a single Cat5 cable. For added versatility

both the Transmitter and Receiver can be powered by the same single power source

using Power Over Cable (POC).

With support for resolutions up to 1920x1080 and the accompanying digital audio, this

HDMI extender is a plug-and-play solution that can easily be installed using new or

existing Ethernet infrastructure wiring.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Packaging Contents

• 1x HDMI® over CAT5e/6 Transmitter Unit

• 1x HDMI® over CAT5e/6 Receiver Unit

• 1x Cat5e Cable

• 1x Power Adapters

• 1x Instruction Manual

• 1x Mounting Brackets

System Requirements

• HDMI® enabled video source device (i.e. computer, Blu-ray Player)

• HDMI® enabled display device (i.e. television, projector)

• Available AC electrical outlet for either the transmitter or receiver

• HDMI® cables for receiver and transmitter

Instruction Manual

Installation

Preparing Your Site

1. Determine where the local video source (i.e. computer, Blu-ray Player) will be

located and set up the device.

2. Determine where the remote display will be located and place/ mount the

display appropriately.

NOTE: This HDMI® extender kit features Power over cable, allowing both the

transmitter and Receiver to be powered from a single power source that can be

connected at either end of the connection. Please ensure that either the Transmitter

or the Receiver Unit is situated near an available AC electrical outlet. Make sure all

devices are turned o before beginning installation.

Hardware Installation

1. Install Transmitter Unit

a) Position the Transmitter Unit near the video source (i.e. Computer, Blu-ray Player).

b) Connect an HDMI® cable from the video source device (i.e. computer, Blu-ray

Player) to the “HDMI® IN” on the Transmitter Unit.

c) (Optional) If you’ve chosen to power the kit from the Transmitter side, connect the

provided power supply.

2. Install RJ45 terminated Cat5e/6 Ethernet Cable

a) Connect an RJ45 terminated Cat5e/6 Ethernet cable (not included) to the RJ45

connector on the Transmitter unit.

NOTE:

If you are using surface cabling, ensure you have enough Category 5e unshielded

twisted pair (UTP) network cabling to connect the Transmitter Unit to the Receiver

Unit’s location, and that each end is terminated with a RJ45 connector. The cabling

should not go through any networking equipment (i.e. router, switch).

If you are using premises cabling, ensure that the Category 5 unshielded twisted pair

(UTP) network cabling between the Transmitter Unit and the Receiver Unit has been

properly terminated in a wall outlet in each location and there is a patch cable long

enough to connect the Receiver Unit and the Transmitter Unit to their respective

outlets. The cabling should not go through any networking equipment (i.e. router,

switch).

b) Connect the other end of the Cat5e/6 cable run to the RJ45 connector on the

Receiver Unit.

Instruction Manual

3. Install Receiver Unit

a) Position the Receiver Unit near the video display (i.e. television, projector).

b) Connect the video source to the HDMI® OUT on the Receiver Unit using an

HDMI® cable.

c) (Optional) If you’ve chosen to power the kit from the Receiver side, connect the

provided power supply.

4. Your source video image will now appear on the remote video display.

Specications

AV Input HDMI®

AV Output HDMI®

Interface HDMI®

Cabling Cat 5e/Cat 6 UTP

Audio Yes

Audio Specications 5.1 Surround Sound

Maximum Cable Length 10m

Max Distance 70m / 230ft

Max Resolution 1080p

Wide Screen Supported Yes

Power Adapter Included Two

Input Voltage 110~240 AC

Input Current 0.3A A

Output Voltage 12 DC V

Output Current 1A

Power Consumption 3W Max Watts

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
