StarTech.com S2510BU3PWPS Manuel utilisateur

Manual Revision: 02/03/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

S2510BU3PWPS

USB 3.0 to 2.5” SATA HDD Enclosure

with Encryption

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Product Diagrams ..................................................................................2

Top View ....................................................................................................................................................... 2

Front View .................................................................................................................................................... 2

Hardware Installation............................................................................3

How to Use ..............................................................................................5

Specications..........................................................................................7

Technical Support ..................................................................................8

Warranty Information............................................................................8

Instruction Manual

Introduction

Packaging Contents

• 1x USB 3.0 to 2.5” SATA HDD Enclosure w/ Encryption

• 1x Carrying Pouch

• 1x USB 3.0 Cable

• 1x Instruction Manual

System Requirements

• Computer system with available USB 3.0 port (5 Gbit/s) or USB 2.0 port (480Mbps)

• 2.5” SATA hard drive or solid state drive (9.5mm height)

• Microsoft® Windows® 2000/XP/Server 2003/Vista/Server 2008 R2/7/8 (32/64-bit), or

Apple® Mac® OS 9.x/10, or Linux®

It is recommended that the enclosure act as a backup to important les, and

not as additional storage (unless also regularly backed up), as lost passwords or

hardware failure (SATA drive or enclosure) will result in the stored data

being unrecoverable.

Instruction Manual

Product Diagrams

Top View

Front View

Operation LEDs

USB Port

Keypad

Instruction Manual

Hardware Installation

WARNING! Hard drives and storage enclosures require careful handling, especially

when being transported. If you are not careful with your hard disk, lost data may

result. Always handle your hard drive and storage device with caution. Be sure that

you are properly grounded by wearing an anti-static strap when handling computer

components or discharge yourself of any static electricity build-up by touching a large

grounded metal surface (such as the computer case) for several seconds.

NOTE: To use encryption, the SATA drive must be initialized and formatted after setup.

This will erase all data on the drive.

1. Open the enclosure by locating the thumb ridges. Pressing down slightly, slide the

back pane away from the top edge.

2. Connect the the 2.5” SATA Hard Drive

Instruction Manual

3. Slide the back pane back into place.

4. With the enclosure fully assembled, connect the USB 3.0 cable from the enclosure to

a USB port on the host computer system using the included cable.

Instruction Manual

How to Use

Initial Setup

1. When connected to a host computer for the rst time, the“2_Input new password,

and then press `Enter`” LED will prompt. If no password is used, the enclosure will

function as a standard external hard drive enclosure without any encryption.

2. Enter your own Password (1~8 digit PIN setting) and press the ‘Enter’ button.

3. After pressing the `Enter` button, the “3_input password and then press ‘Enter’

button” LED will turn on. Re-enter the same password you entered in the previous

step and press the‘Enter’ button to apply it. (If you enter the incorrect password,

you cannot go to the next step. You must go back to the previous step.) Password

is now set.

4. Once the password has been setup, the SATA drive must be initialized and formatted

before use. From the main Windows desktop, right-click on “My Computer”

(“Computer” in Vista/ 7 / 8), then select Manage. In the new Computer Management

window, select Disk Management from the left window panel.

5. A dialog window should automatically appear, asking you to initialize the drive.

Depending on the version of Windows, it will give you the option of either creating

an “MBR” or“GPT” disk. GPT (GUID partition) is not compatible with some older

operating systems, while MBR is supported by newer and older operating systems.

Instruction Manual

6. Once initialized, locate the Disk that says it is “Unallocated” (check the listed hard

drive capacity to conrm it’s the correct hard drive) and then right-click in the

section that says “Unallocated” and select “New Partition”.

WARNING! Losing the password or hardware failure (the SATA drive or enclosure)

will result in the data stored in the enclosure becoming unrecoverable. Removing

the drive from the enclosure or placing it into another S2510BU3PWPS enclosure

will not allow access to the data. It is recommended that all data stored on the

enclosure also be backed up to another location regularly to prevent any chance

of losing your data.

Menu Options

Certain key codes will allow access to additional options for the enclosure. The features

of these Options are outlined below.

Change Password

Change the password set in Initial Setup. Once selected follow steps “2 and 3” of

initial setup.

HDD Initialization

Initial the Hard Drive, without using computer disk management software.

NOTE: the drive will still need to be partitioned using disk management software.

Press <Lock> Button <0> Button <Enter>

Press <Lock> Button <9> Button <Enter>

Instruction Manual

HDD Connection / Disconnection (Smart Mount/Un-mount function)

Press <Lock> Button over 2 seconds

Safely un-mounts the hard drive from your computer, to help prevent in data loss and

drive damage.

NOTE: Ensure there are no active data transfers prior to performing procedure.

Specications

Host Interface USB 3.0

Chipset ID Fujitsu MB86C311

External Connectors 1 x USB 3.0 female

Encryption Type AES-256bit

Power Adapter USB Powered

Enclosure Material Plastic

Maximum Data Transfer Rate USB 3.0: 5 Gbit/s

Operating Temperature 0°C ~ 60°C (32°F ~ 140°F)

Storage Temperature -20°C ~ 60°C (-4°F ~ 76°F)

Humidity > 70% RH

Dimensions 135mmx78mmx16mm

Weight 75g

Compatible Operating Systems

Windows 2000/XP/Server 2003/Vista/

Server 2008 R2/7/8 (32/64-bit), Mac OS

9/10, Linux
