StarTech.com S2510BPU337 Manuel utilisateur

Manual Revision: 01/15/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

S2510BPU337

USB 3.0 to 7mm high 2.5in SATA III

Hard Drive Enclosure w/ UASP

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected

Names and Symbols

This manual may make reference to trademarks ,registered trademarks,

and other protected names and/or symbols of third-party companies not

related in any way to StarTech.com. Where they occur these references

are for illustrative purposes only and do not represent an endorsement

of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in

the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents

are the property of their respective holders.

Instruction Manual

Table of Contents

Product Diagram................................................................1

Front View......................................................................................................................1

RearView........................................................................................................................1

Introduction....................................................................... 2

Packaging Contents.................................................................................................. 2

System Requirements...............................................................................................2

Hardware Installation........................................................3

How to Use..........................................................................5

Specications..................................................................... 8

Technical Support..............................................................9

Warranty Information........................................................9

Instruction Manual

Product Diagram

Front View

Rear View

USB 3.0 Micro

Type B port

Power/Activity

LED

Enclosure Cover Lock/Release switches

Instruction Manual

Introduction

Packaging Contents

• 1x USB 3.0 to 2.5” SSD/HDD Enclosure

• 1x USB 3.0 Cable

• 1x Installation pad for 5mm drives

• 1x Install Guide

System Requirements

• Computer system with available USB 3.0 (5 Gbit/s) port or

USB 2.0 port (480Mbps)

• 7mm 2.5” SATA Solid State Drive (SSD) / Hard Drive (HDD)

• Microsoft® Windows® 2000/XP/Server 2003/Vista/Server 2008

R2/7/8/8.1 (32/64-bit), or Apple® Mac® OS 9.x/10, or Linux®

Instruction Manual

Hardware Installation

WARNING! Hard drives and storage enclosures require careful

handling, especially when being transported. If you are not careful

with your hard disk, lost data may result. Always handle your hard

drive and storage device with caution. Be sure that you are properly

grounded by wearing an anti-static strap when handling computer

components or discharge yourself of any static electricity build-up

by touching a large grounded metal surface (such as the computer

case) for several seconds.

1. Slide each of the enclosure Lock/Release switches toward the

outside of the enclosure away from the lock indicator. Releasing

the top panel from the drive tray.

2. Slide the top panel outward away from the USB port and toward

the Lock/Release switches, and lift the top panel from the

enclosure.

Instruction Manual

3. Connect your 2.5” SATA SSD/HDD to the SATA connector on the

drive tray.

Note: The enclosure tray has built-in drive positioning pegs,

to help ensure the drives proper position within the housing.

Ensure the drive is aligned with these pegs before attempting to

replace the cover. (See picture below)

Instruction Manual

4. Place the top cover back into the drive tray in the same manor it

was removed, and slide each of the cover Lock/Release switches

back to the inside of the enclosure toward the lock indicator.

5. Complete installation by connecting the included USB cable from

the USB 3.0 Micro type B port on the enclosure to an available

USB port on the computer system.

How to Use

Connecting the Hard Drive

Once the enclosure has been attached to a computer, and the OS

has installed the necessary software, the drive will be accessible as

though it were installed within the system.

Prior to using the drive, it will need to be formatted according to

your operating system requirements. To format your newly attached

hard drive, or create partitions, please see the Initializing the Hard

Drive section.

Instruction Manual

Powering the Drive Enclosure

The hard drive enclosure requires no external power supply, as it is

capable of receiving enough power from the USB Bus to which it is

connected.

LED Indicator

The hard drive enclosure oers an LED indicator, to enable you to

monitor drive activity. When the enclosure is powered, the LED will

illuminate. While the hard drive is being accessed, the LED will blink.

Do not remove the enclosure from the host computer while the LED

is ashing, as it could damage the drive or the enclosure, resulting

in data loss.

Disconnecting the Hard Drive

Windows

1. Select the “Safely remove Hardware and Eject Media” icon, located

in the task bar.

2. Select the storage device from the list that appears.

3. Wait for the message indicating that it is now safe to remove the

device.

Note: Removing the connected drive prior to receiving

notication that it is safe to do so, could result in losing or

corrupting data stored on the drive. Once the Safe to Remove

Hardware message appears, please disconnect the enclosure

from the computer by removing the USB connection.

Mac OS X

To safely disconnect the attached drive from the host computer,

close any windows listing the contents of the removable drive. Once

Instruction Manual

all windows are closed, click on the USB storage icon on the desktop,

and drag it to the Trash Can icon on the desktop. Allow 5 seconds

before physically removing the enclosure/drive from the computer.

Initializing the Hard Drive

1. If the SATA Hard Drive is blank it may need to be initialized and

formatted before use. From the main Windows desktop, right-click

on “My Computer” (“Computer” in Vista/ 7 / 8/ 8.1), then select

Manage. In the new Computer Management window, select Disk

Management from the left window panel.

2. A dialog window should automatically appear, asking you to

initialize the drive.Depending on the version of Windows, it will

give you the option of either creating an“MBR” or “GPT” disk. GPT

(GUID partition) is not compatible with some older operating

systems, while MBR is supported by newer and older operating

systems.

3. Once initialized, locate the Disk that says it is “Unallocated” (check

the listed hard drive capacity to conrm it’s the correct hard drive)

and then right-click in the section that says “Unallocated” and

select “New Partition”.
