StarTech.com SATDOCKU3E Manuel utilisateur

SATA Hard Drive Docking Station eSATA USB 3.0 to SATA HDD Dock for 2.5in / 3.5in

StarTech ID: SATDOCKU3E

The SATDOCKU3E USB 3.0/eSATA to SATA Hard Drive Docking Station provides quick and easy access to a

2.5in or 3.5in SATA hard disk drive (HDD) or solid state drive (SSD) through either eSATA or USB connectivity,

making it compatible with almost any system.

The HDD docking station supports large capacity drives (tested with up to 4TB 3.5" and 1TB 2.5" drives), which

enables you to greatly enhance your computer's storage/backup capabilities.

The hard drive dock offers eSATA or USB 3.0 host connections (3Gbps, 5Gbps bandwidth respectively), and is

backward compatible with USB 2.0 (up to 480 Mbps) connections to the host computer.

To simplify HDD installation and swapping drives in and out of the dock, the SATDOCKU3E features a top slot-

loading design, for easy access.

Backed by a 2-year StarTech.com warranty and free lifetime technical support.

Applications

Data recovery specialists who need quick access to drives for imaging

Backup data quickly to an external data archiving

Technicians who regularly test or benchmark different hard drives and need to swap between them

uk.startech.com

0800 169 0408

Features

Supports 2.5" and 3.5" form factor SATA hard drives (HDD) and solid state drives (SSD)

SuperSpeed USB 3.0 compliant host interface, with up to 5 Gbps of data bandwidth

SATA revision 2 compliant eSATA host interface, with up to 3 Gbps of data bandwidth

Separate power switch and status LED

Compatible with SATA revision 1/2/3 (1.5/3.0/6.0 Gbps) drives

Compact, desktop-style form factor

Plug-and-Play and Hot-Swap compatible

uk.startech.com

0800 169 0408

Technical Specifications

Warranty 2 Years

Drive Installation Removable

Drive Size 2.5in & 3.5in

Fan(s) No

Interface USB 3.0 & eSATA

Number of Drives 1

Drive Type SATA

Chipset ID ASMedia ASM1051

Drive Connectors 1 - SATA Data & Power Combo (7+15 pin) Receptacle

Host Connectors 1 - eSATA (7 pin; Data) Receptacle

Host Connectors 1 - USB 3.0 B (9 pin; SuperSpeed) Female

Hot Swap

Capability

Yes

Max Drive Capacity Currently tested with up to 4TB 5400 RPM 3.5" hard drives and 1TB 5400 RPM 2.5" hard

drives

RAID No

Temperature Alarm No

Type and Rate USB 3.0 - 5 Gbit/s

Type and Rate SATA II (3 Gbps)

Insertion Rating 15,000 cycles

OS Compatibility Windows XP(32/64-bit)/ Server 2003(32/64-bit)/ Vista(32/64-bit)/ 7(32/64-bit)/ 8(32/64-bit)/

Server 2008 R2, and Mac OS 10.2~10.7, and Linux 2.6.31 and up

Color Black

Enclosure Type Plastic

Product Length 142 mm [5.6 in]

Product Width 80 mm [3.1 in]

Product Height 80 mm [3.1 in]

Product Weight 414 g [14.6 oz]

LED Indicators 1 - Power (Blue)

LED Indicators 1 - Drive Status (Blue - Powered On, Flashing Red - Activity)

Power Adapter

Included

Yes

Input Voltage 110 ~ 240 AC

Output Voltage 12 DC

Output Current 2A

uk.startech.com

0800 169 0408

Center Tip Polarity Positive

Plug Type M

Operating

Temperature

5°C to 40°C (41°F to 104°F)

Storage

Temperature

-20°C to 70°C (-4°F to 158°F)

Humidity 8 ~ 90% RH

System and Cable

Requirements

Available USB or eSATA port

Note The Apple Mac OS operating systems currently do not support USB 3.0, so this device will

function in USB 2.0 mode only.

Shipping

(Package) Weight

960 g [33.9 oz]

Included in

Package

1 - Hard Drive Docking Station

Included in

Package

1 - USB 3.0 Cable

Included in

Package

1 - eSATA Cable

Included in

Package

1 - Universal Power Adapter

Included in

Package

3 - Power Adapter Plug (NA/UK/EU)

Included in

Package

1 - Instruction Manual

uk.startech.com

0800 169 0408
