StarTech.com TBDOCKHDPBC Manuel utilisateur

Manual Revision: 02/18/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

TBDOCKHDPBC

Thunderbolt™ Laptop Docking Station with HDMI®

or Mini DisplayPort and Gigabit Ethernet

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View .................................................................................................................................................... 1

Rear View...................................................................................................................................................... 1

Introduction............................................................................................2

Packaging Contents ................................................................................................................................. 2

System Requirements.............................................................................................................................. 2

Installation ..............................................................................................3

Operation ................................................................................................5

Windows....................................................................................................................................................... 5

Mac OS .......................................................................................................................................................... 8

Supported Video Resolutions ..............................................................10

Specications..........................................................................................10

Technical Support ..................................................................................12

Warranty Information............................................................................12

Instruction Manual

Product Diagram

Front View

Rear View

USB 3.0

3.5mm Microphone

3.5mm Headphone

USB 3.0

Thunderbolt

HDMI

Gigabit Ethernet

DC Jack

Instruction Manual

Introduction

Packaging Contents

• 1 x Thunderbolt Docking Station

• 1 x 1m Thunderbolt Cable

• 1 x Stand (w/ screws)

• 4 x Rubber Feet

• 1 x Universal Power Adapter (NA/UK/EU)

• 1 x Installation CD

• 1 x Instruction Manual

System Requirements

• Thunderbolt-enabled computer system with available Thunderbolt port

• Available AC electrical outlet

• Windows® 8 (32/64-bit,) 7 (32/64) or Mac OS 10.8.3 or later

Instruction Manual

Installation

1. Connect the included power adapter from an AC electrical outlet to the

Thunderbolt Docking Station.

2. Connect the Docking Station to the computer using the included Thunderbolt

cable. Both Windows and Mac systems should automatically detect and install the

required drivers.

3. Connect an HDMI, Thunderbolt or Mini-DisplayPort display to the docking station

and power it on. The connected display will be detected as a secondary display to

your laptop by default (this can be adjusted in your display settings).

Note: When connected to a Thunderbolt display, the HDMI port can be used

simultaneously to add a maximum of two displays through the dock (provided

that your laptop system hardware can support dual external displays, through the

Thunderbolt connection).

For single display congurations, connect one HDMI, DisplayPort or Thunderbolt

monitor to the dock.

For dual display congurations, connect one HDMI monitor and one Thunderbolt

monitor (Not applicable for DisplayPort monitors) simultaneously to the dock.

HDMI / Mini-DisplayPort

Thunderbolt

(Cable Included)

QWERTY

UIOP

CapsLock

Enter

Shift

SDFGH

JKL

ZXCV BN

Shift

Ctrl

Alt

Esc

123

456

789+

Enter

Num

Lock

/*_

Del

EscEsc Esc

Esc Esc Esc

F1 F2 F3 F4 F1 F2 F3 F4

F1 F2 F3 F4

Backspace

Shift

Instruction Manual

4. Connect your LAN, audio, USB and Thunderbolt peripherals as desired.

Note: After following the above connection instructions, the dock should be ready

to use. In the event that some drivers are not able to auto-install on your system,

please use the following instructions to complete the installation.

Windows

1. Insert the provided CD into your CD/ DVD drive.

2. Select Open folder to view les from the Autoplay menu. If Autoplay is disabled on

your system, browse to your CD/DVD drive to view the les.

Instruction Manual

Ethernet

1. Browse to the \Windows\ethernet folder on the disc and choose either the 32bit or

64bit folder, depending on your operating system.

2. Double-click the ProWINxx.exe application.

3. Follow the on-screen instructions to complete the installation.

USB

1. Browse to the \Windows\usb\3.5.100.0a folder on the disc.

2. Double-click the FLUSB3.0-3.5.100.0.exe application.

3. Follow the on-screen instructions to complete the installation.

Mac OS

Ethernet

Note: Website drivers are designed for Mac OS 10.8.3 to 10.8.5. For OS 10.9 Mavericks

users, the drivers will be automatically installed through your operating system. Please

ensure your operating system is updated to the latest package.

If the drivers have not automatically installed in Mac OS 10.9 please contact

StarTech.com technical support (www.startech.com/support) for further installation

instructions.

1. Browse to www.startech.com/TBDOCKHDPBC

2. Click on the Drivers & Downloads Tab and download the “Intel_I210.zip” driver

3. Extract the driver package

4. Browse to the extracted \Intel_I210\Mac 10.8\ethernet folder

5. Double-click the I210_ML_131002.pkg application

6. Follow any on-screen instructions to complete the installation

Operation

Windows

Display Settings

Conguring the image being displayed by the monitor(s) that are connected to the

Thunderbolt Docking Station can be done in one of two ways:

Note: The default resolution setting in Extend mode is: 1920 x 1080p * 32-bit.

a) Right-click on a blank area of the desktop, select Screen Resolution.

Instruction Manual

b) Right-click the DisplayLink tray icon ( ) in the system notication area.

Screen Rotation

4 options are available: 0°(Normal), 90° (Left), 180° (Upside-Down), 270° (Right) when

used with the Extended or Primary display modes. It is a useful function for some

rotatable display devices.

Instruction Manual

Notebook Monitor O

Sets the monitor on the USB Docking Station to the main display and turns o the

screen of the laptop.

NOTE: This function works only when one add-on monitor is connected.

Optimize For Video

Optimize video playback when using Windows 7/8. Regular text may appear blurry

while this mode is enabled.

Fit to TV

When using Extended Mode, if the Windows Desktop screen is not completely visible

on the TV/Monitor, this option can be used to adjust the size of the Windows Desktop.

NOTE: This option will only work while using Extended Mode. If using Mirror Mode,

selecting this will automatically change the adapter to Extended Mode. This mode

cannot be used at the same time as the Screen Rotation feature.
