StarTech.com SATDOCKU3E Manuel utilisateur

Manual Revision: 05/11/2012

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

SATDOCKU3E

USB 3.0/eSATA Hard Drive Docking Station

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use ofTrademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Diagram ...................................................................................................2

Installation ..............................................................................................3

Hardware Installation ............................................................................................................................. 3

Driver Installation ..................................................................................................................................... 3

Using the Storage Device......................................................................4

Windows 2000/XP/Vista/7/8 ................................................................................................................. 4

Specications..........................................................................................5

Technical Support ..................................................................................6

Warranty Information............................................................................6

Instruction Manual

Introduction

The SATDOCKU3E USB 3.0/eSATA to SATA Hard Drive Docking Station provides quick

and easy access to a 2.5in or 3.5in SATA hard disk drive (HDD) or solid state drive (SSD)

through either eSATA or USB connectivity, making it compatible with almost any

system. Large capacity drives (tested with up to 4TB 3.5” and 1TB 2.5” drives) can be

used to greatly enhance your computer’s storage/backup capabilities. The hard drive

dock supports eSATA with up to 3 Gbps of data bandwidth, and USB 3.0 (with up to 5

Gbps of data bandwidth) while backward compatible with USB 2.0 (up to 480 Mbps).

The top slot-loading HDD dock design allows for fast, hassle-free installation and

swapping of SATA drives. Backed by a 2-year StarTech.com warranty and free lifetime

technical support.

Packaging Contents

• 1x Hard Drive Docking Station

• 1x USB 3.0 Cable

• 1x eSATA Cable

• 1x Universal Power Adapter

• 3x Power Adapter Plug (NA/UK/EU)

• 1x Instruction Manual

System Requirements

• USB enabled computer system with available USB port

• SATA enabled computer system with available eSATA port

• Available AC electrical outlet

• Microsoft® Windows® XP/ Server 2003/ Vista/ Server 2008 R2/ 7/ 8 (32/64-bit), or

Apple® Mac OS® X, or Linux®

Instruction Manual

Diagram

Power LED

Drive Status

LED

DC Power

Connector

USB 3.0

Port

eSATA

Port

Instruction Manual

Installation

WARNING! Hard drives and storage enclosures require careful handling, especially

when being transported. If you are not careful with your hard drive, loss of data may

result. Always handle your hard drive and storage device with caution. Be sure that

you are properly grounded by wearing an anti-static strap when handling computer

components or discharge yourself of any static electricity build-up by touching a large

grounded metal surface (such as the computer case) for several seconds.

Hardware Installation

1. Connect the external power adapter from the hard drive dock to a power outlet.

2. Insert a 2.5” or 3.5” hard drive into the top loading slot. Make sure that the

connectors on the hard drive are facing the same corner of the slot that has a cutout

in the door. The label on the drive should be facing the power button and LEDs on

the drive dock.

3. Connect the included USB 3.0 cable from the hard drive dock to an available USB 3.0

or 2.0 port on the computer system. The computer can be on or o. NOTE: A USB 2.0

A-B cable could be used as a substitute on the hard drive dock but will be restricted

to USB 2.0 speeds.

Connect the included eSATA cable from the hard drive dock to an available eSATA port

on the computer system. The computer can be on or o.

NOTE: It is not recommended that both USB and eSATA be connected at the same

time, however eSATA will be the default connection if both are connected.

4. Press the power button on the top of the hard drive dock. The Power LED under the

power button should light up.

5. If the SATA drive is detect, the Drive Status LED will light up solid blue. The red LED

will ash when there is activity on the drive.

6. To remove the SATA drive, make sure it is currently not being accessed by the

computer then unmount or uninstall the disk drive from the operating system (see

documentation for your operating system). Press the power button to turn o the

hard drive dock and wait for the drive to power down. Gently yet rmly pull the

drive from the slot.

Driver Installation

No driver installation is required for the supported operating systems, as the hard drive

docking station is natively supported, so the drivers are already installed.

Instruction Manual

Using the Storage Device

Windows 2000/XP/Vista/7/8

If you are using a brand new hard drive that does not contain any data, then you will

rst need to prepare the hard drive for use. From the main desktop, right-click on

“My Computer” (“Computer” in Vista/7), then select Manage. In the new Computer

Management window, select Disk Management from the left window panel.

Locate the Disk that says it is “Unallocated” (check hard drive capacity to conrm it’s the

correct hard drive) and then right-click in the section that says“Unallocated” and select

“New Partition”.

The New Partition Wizard will appear. Follow the instructions in the wizard to complete

setting up the drive. Once complete, the Disk should show up as “Healthy” with a drive

letter assigned (i.e. E:). This drive letter should now appear within My Computer.

If you are installing a hard drive that already has data on it, then after plugging it in, the

drive should automatically show up with a drive letter assigned within My Computer.

Instruction Manual

Specications

Chipset ID ASMedia ASM1051

Connectors

1x USB 3.0 type B female

1x eSATA female

1x DC Power

LEDs 1x Power

1x Drive Power/Activity

Compatible Hard Drives 2.5in/3.5in SATA hard disk drives or solid state drives

Maximum Data

Bandwidth

USB 3.0: 5 Gbps

eSATA: 3 Gbps

Power Adapter 12V DC, 2000mA, center positive, type M plug

Operating Temperature 5°C ~ 40°C (41°F ~ 104°F)

Storage Temperature -20°C ~ 70°C (-4°F ~ 158°F)

Humidity 8% ~ 90% RH

Dimensions 142.0mm x 80.0mm x 80.0mm

Weight 400g

Compatible Operating

Systems

Windows XP/ Server 2003/ Vista/ Server 2008/ 7/ 8

(32/64-bit), Mac OS X, Linux

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.

Autres manuels pour SATDOCKU3E

Table des matières

Autres manuels StarTech.com Station d'accueil

StarTech.com

StarTech.com SDOCK4U33E Manuel utilisateur

StarTech.com

StarTech.com DK30C2DPPD Manuel utilisateur

StarTech.com

StarTech.com TBDOCKHDPBC Manuel utilisateur

StarTech.com

StarTech.com Thunderbolt 3 Series Manuel utilisateur

StarTech.com

StarTech.com ST4300U3C1 Manuel utilisateur

StarTech.com

StarTech.com USB3SDOCKHD Manuel du système

StarTech.com

StarTech.com InfoSafe SATDOCKU2GB Manuel utilisateur

StarTech.com

StarTech.com USB3SMDOCKHV Manuel utilisateur

StarTech.com

StarTech.com USB3SDOCKDD Manuel utilisateur

StarTech.com

StarTech.com TB3DKM2HD Manuel utilisateur

StarTech.com

StarTech.com DK30CHDDPPD Manuel utilisateur

StarTech.com

StarTech.com 129N-USBC-KVM-DOCK Manuel utilisateur

StarTech.com

StarTech.com USBVGADOCK Manuel utilisateur

StarTech.com

StarTech.com DKM31C3HVCPD Manuel utilisateur

StarTech.com

StarTech.com USBA2DPGB Manuel utilisateur

StarTech.com

StarTech.com DKT31CHDVCM Manuel utilisateur

StarTech.com

StarTech.com SATADOCK22UE Manuel utilisateur

StarTech.com

StarTech.com DKWG30DPHPD Manuel utilisateur

StarTech.com

StarTech.com SATDOCK22U3S Manuel utilisateur

StarTech.com

StarTech.com 116N-USBC-DOCK Manuel utilisateur

StarTech.com

StarTech.com SATDOCK4U2E Manuel utilisateur

StarTech.com

StarTech.com SATDOCKU3S Manuel utilisateur

StarTech.com

StarTech.com DK30CHHPD Manuel utilisateur

StarTech.com

StarTech.com SATDOCK25U Manuel utilisateur

Manuels Station d'accueil populaires d'autres marques

Sony

Sony Dream Machine XDR-DS12iP Manuel utilisateur

Acer

Acer USB Type-C Dock II Manuel utilisateur

ATEN

ATEN UC-2000 Manuel utilisateur

Xcellon

Xcellon HDD-202 Manuel utilisateur

Dok

Dok CR09 Manuel utilisateur

Philips

Philips BTM630/12 Manuel utilisateur

IOGear

IOGear Travel Pro GUD3C09 Manuel utilisateur

RKI

RKI SDM-E2 Manuel utilisateur

iHome

iHome iP15 Manuel utilisateur

VITURE ONE

VITURE ONE MOBILE DOCK Manuel utilisateur

Lindy

Lindy 42984 Manuel utilisateur

CipherLab

CipherLab 8001 Manuel utilisateur

Pyle

Pyle PIPDSP2 Manuel utilisateur

Avol

Avol AS2350 Manuel utilisateur

Datalogic

Datalogic JoyaTouch Manuel utilisateur

Philips

Philips DC190/79 Manuel utilisateur

Targus

Targus DOCK315EUZ Manuel utilisateur

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manuel utilisateur
