StarTech.com ECESAT32 Manuel utilisateur

ExpressCard Serial ATA

Adapter Card

2-Port SATA 6Gbps ExpressCard

to eSATA Controller Card

ECESAT32

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction..................................................................... 1

Packaging Contents.....................................................................1

System Requirements .................................................................1

Installation....................................................................... 2

Hardware Installation...................................................................2

Driver Installation.........................................................................2

ECESAT32 View ..........................................................................2

Verifying Installation.....................................................................3

Speciﬁcations.................................................................. 4

Technical Support........................................................... 5

Warranty Information...................................................... 5

Introduction

The StarTech.com 2-Port eSATA ExpressCard Controller Cards offers

simple connectivity between a laptop computer system and eSATA

revision 3.0 devices. A cost-effective solution for connecting high

RPM hard drives and Solid State Drives (SSD), which in turn allows

for easier data backups and archiving. With full support for SATA

revision 3.0 hard drives and data transfer speeds of up to 6 Gbps, as

well as backwards support for SATA revision 2.0 devices, the adapter

card features a native PCI Express single chip design that provides

enhanced compatibility, reliability and performance.

Packaging Contents

1 x ECESAT32 controller card•

1 x 34mm to 54mm Stabilizer Bracket•

1 x Driver Installation CD•

1 x Instruction Manual•

System Requirements

ExpressCard enabled computer system•

Microsoft• ®Windows®XP/Server 2003/Vista/Server 2008 R2/7

(32/64-bit), or Linux®

Installation

Hardware Installation

The ExpressCard adapter will simply slide into the ExpressCard slot

on any compatible system. Push the card all the way in, until it ‘clicks’

and locks into place. To eject the card, simply push the card further into

the slot until it clicks, and then release and it will then be automatically

ejected from the slot.

NOTE: Some ExpressCard/54 slots do not ﬁrmly hold an

ExpressCard/34 module, so the 34mm to 54mm stabilizer bracket may

be necessary.

Driver Installation

Windows XP/Server 2003/Vista/Server 2008 R2

After installing the card into the computer system, boot up the1.

computer.

Once logged into Windows, the Hardware/Driver installation wizard2.

should appear. Insert the Driver Installation CD into the CD/DVD

drive when prompted.

Windows should automatically start to search the CD for the3.

appropriate drivers. This may take several minutes.

eSATA

connector

ECESAT32 View

Once Windows has located the drivers and installed them, the card4.

should be ready for use.

Windows 7

No driver installation is required for Windows 7, as the controller card is

natively supported, so the drivers are already installed.

Verifying Installation

Windows XP/Server 2003/Vista/Server 2008 R2/7

From the main desktop, right-click on “My Computer” (“Computer”

in Vista or later), then select “Manage”. In the new Computer

Management window, select Device Manager from the left window

panel.

Under the “SCSI and RAID Controllers” category (“Storage Controllers”

in Vista or later), should be a “Marvell 91xx” device. Right-click on the

device and select “Properties” to make sure it is installed and working

correctly.

For Windows 7, if using the native drivers, the card will instead be listed

under the “IDE ATA/ATAPI Controller” category as a “Standard AHCI”

device.

Specications

Bus Interface ExpressCard 2.0

SATA revision 3.0

Connectors 2 x 7-pin eSATA

Chipset ID Marvell 9128

Maximum Data Transfer Rate SATA: 6Gbps

RAID Support 0, 1, JBOD (single)

Operating Temperature 5°C to 50°C (41°F to 122°F)

Storage Temperature -25°C to 70°C (-13°F to 158°F)

Humidity 15~90% RH

Compatible Operating

Systems

Windows XP/Server 2003/Vista/

Server 2008 R2/7 (32/64-bit),

Linux

Technical Support

StarTech.com’s lifetime technical support is an integral part of our

commitment to provide industry-leading solutions. If you ever need

help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial

date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion.

The warranty covers parts and labor costs only. StarTech.com does

not warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy” since 1985,

providing high quality solutions to a diverse IT and A/V customer

base that spans many channels, including government, education

and industrial facilities to name just a few. We offer an unmatched

selection of computer parts, cables, A/V products, KVM and Server

Management solutions, serving a worldwide market through our

locations in the United States, Canada, the United Kingdom and

Taiwan.

Visit www.startech.com today for complete information about all

our products and to access exclusive interactive tools such as the

Cable Finder, Parts Finder and the KVM Reference Guide.
