ECUSB3S254F
2-Port Flush Mount ExpressCard/54 USB 3.0 Card
*actual product may vary from photo
Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and
Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.
Instruction Manual i
Table of Contents
Introduction ............................................................................................1
Packaging Contents .................................................................................................................................1
System Requirements .............................................................................................................................. 1
Installation ..............................................................................................2
Hardware Installation .............................................................................................................................. 2
Driver Installation ...................................................................................................................................... 2
Specications ..........................................................................................3
Technical Support ..................................................................................4
Warranty Information ............................................................................4
Instruction Manual 1
Introduction
The ECUSB3S254F 2-Port Flush Mount USB 3.0 ExpressCard Adapter uses a unique
form factor design that allows it to sit fully in a standard 54mm laptop ExpressCard slot
without sticking out; the ports sit ush with the sides of the laptop, creating a seamless
add-on that can be left installed, even while on the move, without fear that it will get
snagged or hit against which could cause damage to the card or slot.
The SuperSpeed USB 3.0 Card supports data transfer rates up to 5 Gbps, and is still
backward compatible with USB 2.0 at up to 480 Mbps, or USB 1.1/1.0 at up to 12/1.5
Mbps respectively. This makes it the perfect accessory for laptops so users can connect
USB devices both new and old.
Packaging Contents
• 1 x ExpressCard/54 USB 3.0 Card
• 1 x USB to DC Power Adapter Cable
• 1 x Driver CD
• 1 x Instruction Manual
System Requirements
• ExpressCard enabled computer system with available ExpressCard/54 slot
• Microsoft® Windows® 2000/XP/Server 2003/Vista/Server 2008 R2/7 (32/64-bit)
Instruction Manual 2
Installation
Hardware Installation
The ExpressCard adapter will simply slide into the ExpressCard slot on any compatible
system. Push the card all the way in, until it ‘clicks’ and locks into place. To eject the
card, simply push the card further into the slot until it clicks, and then release and it will
then be automatically ejected from the slot.
Turning the computer o to insert/remove ExpressCard adapters is not necessary as
they are hot-pluggable, however, ensure any USB peripherals are safely disconnected
before removing the ExpressCard adapter.
OPTIONAL: For some high-powered USB devices, additional power may be required
from the USB port. A power jack is provided for connecting the included USB to DC
Power Adapter Cable or an external power adapter (not included), to help support
such devices.
Driver Installation
Windows 2000/XP/Server 2003
1. Upon starting Windows, if the “Found New Hardware” wizard appears on the screen,
cancel/close the window and insert the included Driver CD into the computer’s CD/
DVD drive.
2. AutoPlay should automatically launch and display all of the folders on the CD. If not,
open “My Computer” and double-click on the CD/DVD drive.
3. Double-click the driver installation le.
4. This should launch the driver Installation wizard. Continue through the wizard and
once complete, all the necessary drivers will be installed.
Windows Vista/7/Server 2008 R2
1. Upon starting Windows, if the “Found New Hardware” wizard appears on the screen,
cancel/close the window or choose not to install the drivers and insert the included
Driver CD into the computer’s CD/DVD drive.
2. AutoPlay should automatically launch and display all of the folders on the CD. If not,
open “Computer” and double-click on the CD/DVD.
3. Double-click the driver installation le.
4. This should launch the driver Installation wizard. Continue through the wizard and
once complete, all the necessary drivers will be installed.
Instruction Manual 3
Specications
Interface USB 3.0 base specication 1.0
Intel xHCI specication 0.95
Host Interface ExpressCard 2.0
Form Factor ExpressCard/54 (54mm)
Chipset ID NEC uPD720200
External Connectors 2 x USB 3.0 type A female
1 x DC Power
LEDs N/A
Power Adapter (Optional) 5VDC, center positive, type A plug
Maximum Data Transfer Rate USB 3.0: 5 Gbps
Operating Temperature 0°C ~ 85°C (32°F ~ 185°F)
Storage Temperature -65°C ~ 125°C (-85°F ~ 257°F)
Dimensions 74.0mm x 54.0mm x 5.0mm
Weight 23.8g
Compatible Operating Systems Windows 2000/XP/Server 2003/Vista/
Server 2008 R2/7 (32/64-bit)
* If used with ExpressCard 1.0 enabled computer systems, the max throughput is
limited to 2.5 Gbps. If used with ExpressCard 2.0 enabled computer systems, the max
throughput is 5 Gbps.
Instruction Manual 4
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
Warranty Information
This product is backed by a one year warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase.
During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
StarTech.com has been making “hard-to-nd easy” since 1985, providing high
quality solutions to a diverse IT and A/V customer base that spans many channels,
including government, education and industrial facilities to name just a few. We
oer an unmatched selection of computer parts, cables, A/V products, KVM and
Server Management solutions, serving a worldwide market through our locations in
the United States, Canada, the United Kingdom and Taiwan.
Visit www.startech.com today for complete information about all our products and
to access exclusive interactive tools such as the Cable Finder, Parts Finder and the
KVM Reference Guide. StarTech.com makes it easy to complete almost any IT or A/V
solution. Find out for yourself why our products lead the industry in performance,
support, and value.
