StarTech.com CBUSB220 Manuel utilisateur

CardBus USB 2.0 Card

CBUSB220 Instruction Manual

Actual product may vary from photo

2 Port USB 2.0 CardBus USB Card

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Verifying Your Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting Devices to Your USB Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Safely Removing Your USB 2.0 Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com USB 2.0 CardBus card. Now you can add

three USB 2.0 ports to your notebook computer. With data transfer speeds up to 480

Mbits/sec., this card allows you to easily connect and use high-performance USB

peripherals like DVD drives, video conferencing cameras, or high resolution scanners.

USB 2.0 is also backwards-compatible with USB 1.0/1.1, meaning your existing

peripherals will still function perfectly with no additional configuration.

Features

• Provides you with three high-speed USB 2.0 ports on your notebook computer or

other portable device

•Complies with USB 2.0 specifications and is backwards-compatible with USB 1.0/1.1

•Reaches transfer speeds of up to 480Mbits/sec. (40x faster than USB 1.1)

•Complies with Plug and Play standards

•Backed by StarTech.com’s lifetime warranty

Before You Begin

System Requirements

•Anotebook computer with an available CardBus slot

•Minimum Operating System Requirements: Windows 98SE/ME/2000/XP/2003 or

later, Mac OS X or later

•Minimum Processor Requirements:

Intel Pentium II (400 MHz or faster)

Intel Pentium III or higher (any speed)

Intel Celeron (900 MHz or faster)

AMD Athlon (any speed)

G3 (original processor, not an upgrade)

Contents

This package should contain:

•1x CardBus USB 2.0 Card

•1x Installation CD

•1x Instruction Manual

Instruction Manual

Installation

Windows 98SE/ME

1. Do not insert the CardBus card into the notebook computer until you have completed

the steps below. Allow the computer to start normally and remove any existing

CardBus devices from the slot, if necessary.

2. Insert installation CD that came with the card into your CD-ROM or other

optical drive.

3. Open My Computer and right-click the icon for your CD-ROM. Choose Explore.

4. Double click the Setup.exe file. The program will now copy the appropriate driver files

onto your system; simply follow the on-screen prompts. When the process is

complete, restart the computer.

5. Once your system reboots, insert the USB 2.0 card into the CardBus slot. Windows

will detect the new hardware and configure the card automatically.

Windows 2000/XP/2003

Windows 2000/XP/2003 includes native support for USB 2.0 and will install the drivers

automatically when the card is inserted in the CardBus slot. Ensure you have the current

Microsoft Service Pack installed.

Verifying Your Installation

Windows 98SE/ME

1. Go to Start >Settings >Control Panel.

2. Double click System.

3. Click the Hardware tab.

4. If the card and related components do not appear with a red xor yellow exclamation

point (!) next to them, Windows has not detected a problem with the installation and

the card should function normally.

Windows 2000/XP/2003

1. Go to Start >Settings >Control Panel.

2. Double click System.

3. Click the Hardware tab and choose Device Manager.

4. If the card and related components do not appear with a red xor yellow exclamation

point (!) next to them, Windows has not detected a problem with the installation and

the card should function normally.

Instruction Manual

Connecting Devices to Your USB Card

When you install a USB device to one of your USB ports, Windows will automatically

detect it and you will be prompted to install the drivers for the device. If you ever plug

this device into a different port on your USB 2.0 card, you will be prompted to install the

drivers again. If possible, you should plug the device into each port on your USB card

and install the drivers for each port the first time your connect your peripheral. Later on,

with the drivers already installed for each port, you can unplug and move your USB 2.0

devices around your card without having to worry about finding your driver disk.

Safely Removing the USB 2.0 Card

While the card can be removed with the computer running and Windows started (a

process commonly referred to as “hot-plugging”), Windows does offer a “safe removal”

feature that ensures that the card is inactive before it is removed from the CardBus slot.

It is strongly recommended that you follow this procedure when removing the card from a

computer to avoid data loss or equipment damage.

To use the safe removal feature:

1. Locate the hardware ejection icon in the System Tray (next to

the clock).

2. Left click the icon once to activate the device

menu.

3. Highlight the card from the list and click it once.

4. After a momentary pause, Windows will display a message informing you the card

can be safely removed.

5. You can now physically remove the card from the slot.

Specifications

Instruction Manual

Form Factor/Interface CardBus, 32-bit

Standards Supported Universal Serial Bus ver. 2.0 (EHCI)

Universal Serial Bus ver. 1.1 (OHCI)

Maximum Data Transfer Rate 480 Mbits/sec. (USB 2.0)

12 Mbits/sec. (USB 1.1)

Connectors 2 x USB Type “A” female (external)

Maximum Number of Devices 127 (via daisychained hubs)

OS Support Windows 98SE/ME/2000/XP/2003

Fully Plug and Play compliant

Regulatory and Other Certifications FCC Class B, CE, UL

Accessory Products from StarTech.com

Contact your local StarTech.com dealer or visit www.startech.com for cables or other

accessories that will help you get the best performance out of your new product.

6 ft. High Speed Certified USB 2.0 Cable

USB2HAB6

10 ft. High Speed Certified USB 2.0 Cable

USB2HAB10

15 ft. High Speed USB 2.0 Cable

USB2HAB15

6 ft. Transparent USB 2.0 Cable A-B M/M

USB2HAB6T

10 ft. Transparent USB 2.0 Cable A-B M/M

USB2HAB10T

15 ft. Transparent USB 2.0 Cable A-B M/M

USB2HAB15T

Mutant Mods 6 ft. Blue LED USB 2.0 Cable A-B M/M

USB2HAB6LEDB

Mutant Mods 6 ft. Red LED USB 2.0 Cable A-B M/M

USB2HAB6LEDR

Mutant Mods 6 ft. Yellow LED USB 2.0 Cable A-B M/M

USB2HAB6LEDY

Mutant Mods 6 ft. Blue - Green Lava Lamp LED USB 2.0 Cable A-B M/M

USBHAB6FLBG

Mutant Mods 6 ft. Red - Yellow Lava Lamp LED USB 2.0 Cable A-B M/M

USBHAB6FLRY

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

Warranty Information

This product is backed by a lifetime warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Instruction Manual

Revised: 20 August 2004 (Rev. B)

About StarTech.com

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer

Parts”. Since 1985, we have been providing IT professionals with the

quality products they need to complete their solutions. We offer an

unmatched selection of computer parts, cables, server management

solutions and A/V products and serve a worldwide market through our

locations in the United States, Canada, the United Kingdom and Taiwan.

Table des matières

Autres manuels StarTech.com Matériel informatique

StarTech.com

StarTech.com PEXUSB311EI Manuel utilisateur

StarTech.com

StarTech.com UE1205CB Manuel

StarTech.com

StarTech.com ECUSB3S254F Manuel utilisateur

StarTech.com

StarTech.com ST10GPEXNDPI Manuel utilisateur

StarTech.com

StarTech.com 2P6GR-PCIE-SATA-CARD Manuel utilisateur

StarTech.com

StarTech.com PCISATA2P4 Manuel utilisateur

StarTech.com

StarTech.com PEX1S552LP Manuel

StarTech.com

StarTech.com PEXUSB312A2 Manuel utilisateur

StarTech.com

StarTech.com PEX2PCI4 Manuel utilisateur

StarTech.com

StarTech.com SM22BU31C3R Manuel utilisateur

StarTech.com

StarTech.com PEXUSB312C2 Manuel utilisateur

StarTech.com

StarTech.com EC1394B2 Manuel utilisateur

StarTech.com

StarTech.com M2E4BTB3 Manuel utilisateur

StarTech.com

StarTech.com SATABAY3 Manuel

StarTech.com

StarTech.com 4K30-HDMI-CAPTURE Manuel utilisateur

StarTech.com

StarTech.com VSEDIDHD Manuel utilisateur

StarTech.com

StarTech.com PEX8S952 Manuel utilisateur

StarTech.com

StarTech.com EC230USB Manuel utilisateur

StarTech.com

StarTech.com CF2IDE18 Manuel utilisateur

StarTech.com

StarTech.com VSEDIDHD Manuel utilisateur

StarTech.com

StarTech.com ATXPOW430HS Manuel

StarTech.com

StarTech.com PCISOUND5CH Manuel utilisateur

StarTech.com

StarTech.com PEXSAT34RH Manuel utilisateur

StarTech.com

StarTech.com EC13942 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
