Dot Matrix Printer

SP2000 Series

Programmer’s Manual

TABLE OF CONTENTS

1. Control Codes (Star Mode) ......................................................................... 1

1-1. Control Codes List .............................................................................. 1

1-1-1. Character Selection .................................................................. 1

1-1-2. Print Position Control............................................................... 3

1-1-3. Dot Graphics Control ...............................................................4

1-1-4. Download Graphics Printing .................................................... 4

1-1-5. Peripheral Device Control ........................................................ 4

1-1-6. Auto Cutter Control (SP2500 type printers only) .................... 5

1-1-7. Commands to Set the Page Format ..........................................5

1-1-8. Other Commands...................................................................... 6

1-2. Control Code Details...........................................................................7

1-2-1. Character Selection .................................................................. 7

1-2-2. Print Position Control............................................................. 17

1-2-3. Dot Graphics Control .............................................................25

1-2-4. Download Graphics Printing .................................................. 28

1-2-5. Peripheral Device Control ...................................................... 31

1-2-6. Auto Cutter Control (SP2500 type printers only) .................. 33

1-2-7. Command to Set the Page Format.......................................... 35

1-2-8. Other Commands.................................................................... 36

2. ESC/POS Mode Commands....................................................................... 48

2-1. Control Codes List ............................................................................ 48

3. Auto Status Specifications......................................................................... 51

3-1. Auto Status ........................................................................................ 51

Appendix : Character Code Tables................................................................ 57

Please access the following URL

http://www.star-micronics.co.jp/service/sp_sup_e.htm

for the lastest revision of the manual.

1-1. Control Codes List

The following tables show the Star Mode commands that are supported by

this printer.

1-1-1. Character Selection

Control Hexadecimal Function Page

Codes Codes

<ESC> "R"

1B 52

Selects the international character set 7

<ESC> "/" "1" 1B 2F 31 Selects slash zero 7

<ESC> "/" <1> 1B 2F 01

<ESC> "/" "0" 1B 2F 30 Selects normal zero 7

<ESC> "/" <0> 1B 2F 00

<ESC> <GS> "t"

1B 1D 74

Selects the character code table 8

<ESC> "6" 1B 36 Selects character set #2 10

<ESC> "7" 1B 37 Selects character set #1 10

<ESC> "M" 1B 4D Selects the 7 X 9 (half dot) font (Default) 10

<ESC> "P" 1B 50 Selects the 5 X 9 (2 pulses per dot) font 11

<ESC> ":" 1B 3A Selects the 5 X 9 (3 pulses per dot) font 11

1B 20

Sets character spacing 11

<SO> 0E Sets the printing magnified double in 12

character width

<DC4> 14 Resets the printing magnified in 12

character width (Default)

1. Control Codes (Star Mode)

Control Hexadecimal Function Page

Codes Codes

<ESC> "W" "1" 1B 57 31 Selects double magnification in character 12

<ESC> "W" <1> 1B 57 01 width

<ESC> "W" "0" 1B 57 30 Resets magnification in character width 12

<ESC> "W" <0> 1B 57 00

<ESC> "h" "1" 1B 68 31 Selects double magnification in character 12

<ESC> "h" <1> 1B 68 01 height

<ESC> "h" "0" 1B 68 30 Resets magnification in character height 12

<ESC> "h" <0> 1B 68 00

<ESC> "-" "1" 1B 2D 31 Selects underlining 13

<ESC> "-" <1> 1B 2D 01

<ESC> "-" "0" 1B 2D 30 Cancels underlining (Default) 13

<ESC> "-" <0> 1B 2D 00

<ESC> "_" "1" 1B 5F 31 Selects upperlining 13

<ESC> "_" <1> 1B 5F 01

<ESC> "_" "0" 1B 5F 30 Cancels upperlining (Default) 14

<ESC> "_" <0> 1B 5F 00

<ESC> "4" 1B 34 Selects red color printing (SP2360/2560) 14

Selects highlight printing (SP2320/2520)

<ESC> "5" 1B 35 Cancels red color printing (SP2360/2560) 14

Cancels highlight printing (SP2320/2520)

<SI> 0F Inverted printing 14

<DC2> 12 Cancels inverted printing (Default) 15

<ESC> <RS> "i" "0" 1B 1E 96 30 Cancels rotated print mode for text 15

<ESC> <RS> "i" <0> 1B 1E 96 00 (Default)

<ESC> <RS> "i" "1" 1B 1E 96 31 Specifies rotated print mode for text with 15

<ESC> <RS> "i" <1> 1B 1E 96 01 a 270° rotation.

<ESC> <RS> "i" "2" 1B 1E 96 32 Specifies rotated print mode for text with 15

<ESC> <RS> "i" <2> 1B 1E 96 02 a 90° rotation.

<ESC> "E" 1B 45 Selects emphasized printing 15

<ESC> "F" 1B 46 Cancels emphasized printing (Default) 15

<ESC> "U"

1B 55

Selects print direction 16

1-1-2. Print Position Control

Control Hexadecimal Function Page

Codes Codes

<LF> 0A Line feed 17

<VT> 0B Vertical tab 17

<FF> 0C Form feed 17

<CR> 0D Carriage Return 18

<ESC> "a"

1B 61

Feeds paper

lines 18

<HT> 09 Horizontal tab 18

<ESC> "A"

1B 41

Defines

/72-inch line spacing 19

<ESC> "2" 1B 32 Sets

/72-inch line spacing 19

<ESC> "z" "0" 1B 7A 30 Sets line spacing to 1/12-inch 19

<ESC> "z" <0> 1B 7A 00

<ESC> "z" "1" 1B 7A 31 Sets line spacing to 1/6-inch (Default) 19

<ESC> "z" <1> 1B 7A 01

<ESC> "0" 1B 30 Sets line spacing to 1/8-inch 19

<ESC> "1" 1B 31 Sets line spacing to 7/72-inch 20

<ESC> "J"

1B 4A

One time

/72-inch feed 20

<ESC> "3"

1B 33

Sets line spacing to

/216-inch 20

approximately

<ESC> "y" 1B 79

Sets line spacing to

/144-inch 20

<ESC> "D"

n1 n2

... <0> 1B 44

n1 n2

... 00 Sets horizontal tab stops 21

<ESC> "l"

1B 6C

Sets left margin 21

<ESC> "Q"

1B 51

Sets right margin 22

<ESC> <GS> "a" "0" 1B 1D 61 30 Left justification (Default) 23

<ESC> <GS> "a" <0> 1B 1D 61 00

<ESC> <GS> "a" "1" 1B 1D 61 31 Centering 23

<ESC> <GS> "a" <1> 1B 1D 61 01

<ESC> <GS> "a" "2" 1B 1D 61 32 Right justification 23

<ESC> <GS> "a" <2> 1B 1D 61 02

<ESC> "B"

n1 n2

... <0> 1B 42

n1 n2

... 00 Set vertical tab stops 24

1-1-3. Dot Graphics Control

Control Hexadecimal Function Page

Codes Codes

<ESC> "K"

<0> 1B 4B

m1 m2

8 dot normal density graphics 25

m1 m2 ... ...

<ESC> "L"

2 1B 4C

m1 m2

8 dot high density graphics 26

m1 m2

... ...

1-1-4. Download Graphics Printing

Control Hexadecimal Function Page

Codes Codes

2 .. 1B 26 00

2 .. Defines download characters 28

<ESC> "%" "1" 1B 25 31 Enables download character set 29

<ESC> "%" <1> 1B 25 01

<ESC> "%" "0" 1B 25 30 Disables download character set 29

<ESC> "%" <0> 1B 25 00 (Default)

1-1-5. Peripheral Device Control

Control Hexadecimal Function Page

Codes Codes

2 1B 07

2 Defines drive pulse width for peripheral 31

device #1

<BEL> 07 Controls peripheral device #1 31

<FS> 1C Controls peripheral device #1 immediately 32

<EM> 19 Controls peripheral device #2 immediately 32

<SUB> 1A Controls peripheral device #2 immediately 32

1-1-6. Auto Cutter Control (SP2500 type printers only)

Control Hexadecimal Function Page

Codes Codes

<ESC> "d" "0" 1B 64 30 Full-cut command to the auto cutter 33

<ESC> "d" <0> 1B 64 00

<ESC> "d" "1" 1B 64 31 Partial-cut command to the auto cutter 33

<ESC> "d" <1> 1B 64 01

<ESC> "d" "2" 1B 64 32 Full-cut command to the auto cutter 33

<ESC> "d" <2> 1B 64 02 after paper feed

<ESC> "d" "3" 1B 64 33 Partial-cut command to the auto cutter 34

<ESC> "d" <3> 1B 64 03 after paper feed

1-1-7. Commands to Set the Page Format

Control Hexadecimal Function Page

Codes Codes

<ESC> "C"

1B 43

Set page length i

lines 35

1B 43 00

Set page length i

inches 35

<ESC> "

1B 4E

Set bottom margi

<ESC> "O" 1B 4F Cancel bottom margin (Default) 35

1-1-8. Other Commands

Control Hexadecimal Function Page

Codes Codes

<CAN> 18 Cancels printer buffer & Initialize printer 36

<DC3> 13 Deselects printer 36

<DC1> 11 Sets select mode (Default) 36

<RS> 1E Beeps the buzzer 36

<ESC> "#

4" 1B 23

<LF> <

UL>

4 Sets memory switch 37

0A 00

<ESC> "@" 1B 40 Initialize printer 43

<EOT> 04 Transmits EOT status 44

<ENQ> 05 Transmits ENQ status 45

<ETB> 17 Confirms finish of printing 46

<ESC> <ACK> <SOH> IB 06 01 Transmits automatic status 46

<ESC> <RS> "a"

IB IE 61

Enables/disables automatic status 47

<ESC> "?" <LF> <NUL> 1B 3F 0A 00 Resets printer hardware and produce 47

a test print

1-2. Control Code Details

The following section explains the details of the printer control codes.

1-2-1. Character Selection

FUNCTION

Selects the international character set

CODE

<ESC> "R"

(1B)H (52)H

DEFINITION RANGE

(00)H

(0E)H or

= (40)H

OUTLINE

Select the international character set corresponding to the value

set for

= (00)H: U.S.A. (06)H: Italy (OC)H: LatinAmerica

(01)H: France (07)H: Spain-1 (0D)H: Korea

(02)H: Germany (08)H: Japan (0E)H: Ireland

(03)H: England (09)H: Norway (40)H: Legal

(04)H: Denmark-1 (0A)H: Denmark-2

(05)H: Sweden (0B)H: Spain-2

Default abides by memory switches 1-0 to 1-3.

FUNCTION

Selects zero style

CODE

<ESC> "/"

1B 2F

OUTLINE

Selects zero style

Causes subsequent zero characters to be printed with a slash

when

is 1 and without a slash when

is 0. The value of

can

be set to 0 (00H) or "0" (30)H or 1(0H) or "1" (31H).

The default may differ depending on the memory switch setting.

FUNCTION

Selects the character code table

CODE

<ESC> <GS> "t"

1B 1D 74

OUTLINE

Selects the character code table

This function selects a character code table (as shown below).

The default settings follow the settings of the memory switches 3-

8 to 3-5.

Autres manuels pour SP2000

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Star Micronics Imprimante

Star Micronics

Star Micronics LC-500 Manuel utilisateur

Star Micronics

Star Micronics LC-4511 Manuel utilisateur

Star Micronics

Star Micronics TSP1000 Series Manuel utilisateur

Star Micronics

Star Micronics TUP900 Series Manuel utilisateur

Star Micronics

Star Micronics SP500 Series Manuel utilisateur

Star Micronics

Star Micronics TSP2000 Series Manuel utilisateur

Star Micronics

Star Micronics TSP700 Series Manuel utilisateur

Star Micronics

Star Micronics NX-15 Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Star Micronics

Star Micronics WinType 800C Manuel utilisateur

Star Micronics

Star Micronics TSP100IIIU Instructions de montage

Star Micronics

Star Micronics TSP2000 Series Manuel utilisateur

Star Micronics

Star Micronics TSP400 Series Manuel utilisateur

Star Micronics

Star Micronics LaserPrinter 4III Manuel utilisateur

Star Micronics

Star Micronics TSP700 Series Manuel d'utilisation et d'entretien

Star Micronics

Star Micronics FVP-10U Manuel utilisateur

Star Micronics

Star Micronics MULTI-FONT NX-1000II Manuel utilisateur

Star Micronics

Star Micronics ND-10/15 Manuel utilisateur

Star Micronics

Star Micronics TSP100ECO Manuel utilisateur

Star Micronics

Star Micronics DP8340 Series Mode d'emploi

Star Micronics

Star Micronics LC-1011C Manuel utilisateur

Star Micronics

Star Micronics TSP043 Series Manuel utilisateur

Star Micronics

Star Micronics LC-7211 Manuel utilisateur

Star Micronics

Star Micronics TSP1000 Series Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
