ST STM32F030 Manuel utilisateur

September 2013 DocID025097 Rev 1 1/39

UM1658

User manual

Discovery kit for STM32F030 Value Line microcontrollers

Introduction

The STM32F030 Value Line Discovery kit (32F0308DISCOVERY) helps you to discover the

device features and to develop your applications easily. It is based on STM32F030R8T6, an

STM32 F0 series 32-bit ARM®Cortex™-M0 microcontroller, and includes an ST-LINK/V2

embedded debug tool, LEDs, push buttons and a prototyping board.

Figure 1. 32F0308DISCOVERY

www.st.com

Contents UM1658

2/39 DocID025097 Rev 1

Contents

1 Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2 Quick start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.1 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.2 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.3 Development toolchains supporting the 32F0308DISCOVERY . . . . . . . . . 6

2.4 Order code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

4 Hardware and layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4.1 STM32F030R8T6 microcontroller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

4.2 Embedded ST-LINK/V2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.2.1 Using ST-LINK/V2 to program/debug the STM32 F0 on board . . . . . . . 14

4.2.2 Using ST-LINK/V2 to program/debug an external STM32 application . . 15

4.3 Power supply and power selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4.4 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4.5 Push buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4.6 JP2 (Idd) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4.7 OSC clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.7.1 OSC clock supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.7.2 OSC 32 KHz clock supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.8 Solder bridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4.9 Extension connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

5 Connecting modules on the prototyping board . . . . . . . . . . . . . . . . . . 25

5.1 Mikroelektronica accessory boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

5.2 ST MEMS “adapter boards”, standard DIL24 socket . . . . . . . . . . . . . . . . 28

5.3 Arduino shield boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6 Mechanical drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

7 Electrical schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

8 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

DocID025097 Rev 1 3/39

UM1658 List of tables

List of tables

Table 1. ON/OFF conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Table 2. Jumper states . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table 3. Debug connector CN3 (SWD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Table 4. Solder bridge settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Table 5. MCU pin description versus board function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Table 6. Connecting using mikroBUS™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Table 7. Connecting using IDC10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Table 8. Connecting with a DIL24 board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Table 9. Supported MEMS adapter boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Table 10. Connecting with Arduino shields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Table 11. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

List of figures UM1658

4/39 DocID025097 Rev 1

List of figures

Figure 1. 32F0308DISCOVERY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Figure 2. Hardware block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Figure 3. Top layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Figure 4. Bottom layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Figure 5. STM32F030R8T6 package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Figure 6. STM32F030R8T6 block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Figure 7. Typical configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Figure 8. 32F0308DISCOVERY connections image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Figure 9. ST-LINK connections image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Figure 10. Using IDC10 and mikroBUS™ connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Figure 11. DIL24 socket connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Figure 12. Arduino shield board connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Figure 13. 32F0308DISCOVERY mechanical drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Figure 14. 32F0308DISCOVERY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Figure 15. ST-LINK/V2 (SWD only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Figure 16. MCU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

DocID025097 Rev 1 5/39

UM1658 Conventions

1 Conventions

Table 1 provides the definition of some conventions used in the present document.

Table 1. ON/OFF conventions

Convention Definition

Jumper JP1 ON Jumper fitted

Jumper JP1 OFF Jumper not fitted

Solder bridge SBx ON SBx connections closed by solder

Solder bridge SBx OFF SBx connections left open

Quick start UM1658

6/39 DocID025097 Rev 1

2 Quick start

The STM32F030 Value Line Discovery kit is a low-cost and easy-to-use development kit to

quickly evaluate and start development with an STM32 F0 series microcontroller.

Before installing and using the product, please accept the Evaluation Product License

Agreement from www.st.com/stm32f0-discovery.

For more information on the STM32F030 Value Line Discovery kit and for demonstration

software, visit www.st.com/stm32f0-discovery.

2.1 Getting started

Follow the sequence below to configure the STM32F030 Value Line Discovery kit and

launch the DISCOVER application:

1. Check jumper position on the board, JP2 on, CN2 on (Discovery selected).

2. Connect the 32F0308DISCOVERY board to a PC with a USB cable ‘type A to mini-B’

through USB connector CN1 to power the board. Red LED LD1 (PWR) and LD2 (COM)

light up and green LED LD3 blinks.

3. Press user button B1 (bottom left corner of the board).

4. Observe how the green LED LD3 blinking changes according to USER button B1

clicks.

5. Each click on USER button B1 is confirmed by the blue LED LD4.

6. To study or modify the DISCOVER project related to this demo, visit

www.st.com/stm32f0-discovery and follow the tutorial.

7. Discover the STM32F0 features, download and execute programs proposed in the list

of projects.

8. Develop your own application using available examples.

2.2 System requirements

•Windows PC (XP, Vista, 7)

•USB type A to Mini-B USB cable

2.3 Development toolchains supporting the 32F0308DISCOVERY

•Altium®, TASKING™ VX-toolset

•ARM®, Atollic TrueSTUDIO®

•IAR™, EWARM (IAR Embedded Workbench®)

•Keil™, MDK-ARM™

2.4 Order code

To order the STM32F030 Value Line Discovery kit, use the order code

STM32F0308-DISCO.

DocID025097 Rev 1 7/39

UM1658 Features

3 Features

The STM32F030 Value Line Discovery kit offers the following features:

•STM32F030R8T6 microcontroller featuring 64 KB Flash, 8 KB RAM in an LQFP64

package

•On-board ST-LINK/V2 with selection mode switch to use the kit as a standalone

ST-LINK/V2 (with SWD connector for programming and debugging)

•Board power supply: through USB bus or from an external 5 V supply voltage

•External application power supply: 3 V and 5 V

•Four LEDs:

– LD1 (red) for 3.3 V power on

– LD2 (red/green) for USB communication

– LD3 (green) for PC9 output

– LD4 (blue) for PC8 output

•Two push buttons (user and reset)

•Extension header for LQFP64 I/Os for quick connection to prototyping board and easy

probing.

•An additional board is provided with the kit which can be connected to the extension

connector for even easier prototyping and probing.

•A large number of free ready-to-run application firmware examples are available on

www.st.com/stm32f0-discovery to support quick evaluation and development.

Hardware and layout UM1658

8/39 DocID025097 Rev 1

4 Hardware and layout

The STM32F030 Value Line Discovery board is designed around the STM32F030R8T6

microcontroller in a 64-pin LQFP package.

Figure 2 illustrates the connections between the STM32F030R8T6 and its peripherals

(ST-LINK/V2, push button, LEDs and connectors).

Figure 3 and Figure 4 help you to locate these features on the STM32F030 Value Line

Discovery board.

Figure 2. Hardware block diagram

MSv31935V1

I/O

Mini

USB

LD3, PC9

RST

RESET

I/OI/O

Header

SWD

Embedded

ST-LINK/V2

STM32F030R8T6

LED

Header

USER

LD4, PC8

LED

DocID025097 Rev 1 9/39

UM1658 Hardware and layout

Figure 3. Top layout

Note: Pin 1 of CN2, CN3, P1 and P2 connectors are identified by a square.

(red/green LED) LD2

COM

CN3

SWD connector

IDD measurement

ST-LINK/V2

B1 user button

B2 reset button

LD1 (red LED)

PWR

CN2

ST-LINK/DISCOVERY

selector

(green LED) LD3

LD4 (blue LED)

STM32F030R8T6

JP2

5V power supply

input output

3V power supply

input output

SB1 (VDD)

SB3 (B1-USER)

SB4 (B2-RESET)

MS31936V1

MB1134 revA

STM32F0308-DISCO

Hardware and layout UM1658

10/39 DocID025097 Rev 1

Figure 4. Bottom layout

SB6, SB8, SB10, SB12

MS30025V1

SB5, SB7, SB9, SB11

(RESERVED)

(DEFAULT)

SB20, SB21 (X3 crystal)

SB14, SB15 (RX, TX)

SB19 (NRST)

SB16, SB17 (X2 crystal)

SB13 (STM_RST)

SB22 (T_SWO)

SB18 (MCO)
